Case Studies
Read our case studies to find out how our customers successfully use our solutions and the measurable results they achieve with them.
Case Studies | Power Supplies
At the Point of Load
26.09.2024 I Growing demands on efficiency, thermal management and transient response have led to improvements in power supply architecture. Key components of these recent advances are highly efficient PoL DC/DC converters. The job of a power supply is to provide and distribute electrical energy to electrical devices or systems. It ensures that the voltage and current supplied to connected loads are within certain tolerances. This is achieved by converting an input voltage (AC/DC) …
Case Studies | Power Supplies
Balancing miniaturisation, performance and cost
29.08.2024 I New designs and advanced manufacturing technologies are enabling the automated assembly of DC/DC converters with low power consumption and higher performance without compromising on cost. Low power PCB-mounted DC/DC converters have not followed the trend towards miniaturisation to the same extent as ICs or surface mount devices, primarily because the magnetic components required in …
Case Study | Power Supplies
DC/DC converters with programmable outputs for wide-bandgap applications
25.07.2024 I Providing precise gate drive voltages is crucial, especially for the latest generation of SiC devices. The programmable outputs of the R24C2T25 isolated DC/DC converter allow a range of devices to be evaluated and the most suitable voltage levels to be set for the best …
Case Study | Power Supplies
Power derating in practice
27.06.2024 I Increasing efficiency is leading to smaller and smaller industrial power supplies and a consistent increase in power density. But what application-dependent factors need to be taken into account with regard to the actual possible power consumption? Often, in practice, insufficient attention is paid to power derating. Most power supply makers provide information about the service life …
Case Study | Power Supplies
Power derating in practice
21.03.2024 I The growing demand for clean energy, the integration of renewable resources, and advancing electrification across a range of sectors are all driving the development of bidirectional power supply systems. We help you to find the right power supply for applications ranging from renewable energies to e-mobility and the battery industry. …
Case Study | Thermal Management
Cost-effective SUNON Eco EC fans
27.02.2024 I The axial fans in SUNON’s Eco EC series are environmentally friendly and energy efficient, integrating advanced technology that allows them to reduce their power consumption by up to 80% compared to standard AC fans. Low noise generation, long service life and more make these fans an especially attractive choice. …
Case Study | Passive and Elektromechanical
How does an exciter work?
28.05.2020 I An exciter (a.k.a. vibration transducer, bodyshaker), as a loudspeaker without a membrane, comprises three essential components: an oscillating mass (1), a contact terminal (2) for electrical connection to the amplifier, and a mounting plate (3) for fixing to the installation surface.. …
