C3D06065A
Wolfspeed THT SiC Schottky Diode 1,7V 9000mA 63000mA TO-220AC
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Item no longer available!
Planned delivery time
--- Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
EOL 08.12.2025
Discontinued by manufacturer without replacement
Data Sheet
ECAD Model
Prices
Manufacturer bundle 50 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 1000 or multiple of 1000)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- (Uf) Forward Voltage
- 1.7 V
- (If) Forward Current
- 9,000 mA
- Peak Let-Through Surrent Max.
- 63,000 mA
- (Urrm) Peak Recurrent Reverse Voltage Max.
- 650 V
- (Ir) Reverse Current
- 40,000 nA
- RoHS-Conform
Specifications
Open all
Operating conditions
- Barrier Layer temperature, min. (TJ)
- -55 °C
- Barrier Layer Temperature, max. (TJ)
- 175 °C
- Storage Temperature Min.
- -55 °C
- Storage Temperature Max.
- 175 °C
Electrical Properties
- (Uf) Forward Voltage
- 1.7 V
- (If) Forward Current
- 9,000 mA
- Peak Let-Through Surrent Max.
- 63,000 mA
- (Urrm) Peak Recurrent Reverse Voltage Max.
- 650 V
- (Ir) Reverse Current
- 40,000 nA
- (Cd) Diode Capacitance
- 295 pF
