Wirewound Resistors

(533 Results)

Filter results

Show Selected	Part No.	Indiv. Part No.	Manufacturer	Availability	Quantity	Series	Type	Manufacturer	Assembly Type	Form of Delivery	Resistance value	Resistance unit	Resistance tolerance	Temperature coefficient	Rated power	Dimension: Length	Dimension: Width	Dimension: Height	Pitch	Operating Temperature Min.	Operating Temperature Max.
51	Manufacturers Part No. COR5 220R J (COR5220RJ) Fukushima Futaba Ceramic wire resistor COR 5W 220Ohm 5%	Customer Part No. Customer Project No.	Fukushima Futaba	200 Pcs. Planned Delivery Time Ø 31 Weeks Available (from stock)	(at least 10 or mul. of 10)	COR	Ceramic wire resistor	Fukushima Futaba	THT	bulk	220.0	Ohm	5.0 %	350 ppm/°	5.0 W	13.0 mm	9.0 mm	25.5 mm	5.0 mm	-25.0 °C	155.0 °C
52	Manufacturers Part No. COR5 22K J (COR522KJ) Fukushima Futaba Ceramic wire resistor COR 5W 22kOhm 5%	Customer Part No. Customer Project No.	Fukushima Futaba	220 Pcs. Planned Delivery Time Ø 31 Weeks Available (from stock)	(at least 10 or mul. of 10)	COR	Ceramic wire resistor	Fukushima Futaba	THT	bulk	22.0	kOhm	5.0 %	350 ppm/°	5.0 W	13.0 mm	9.0 mm	25.5 mm	5.0 mm	-25.0 °C	155.0 °C
53	Manufacturers Part No. COR5 2K2 J (COR52K2J) Fukushima Futaba Ceramic wire resistor COR 5W 2,2kOhm 5%	Customer Part No. Customer Project No.	Fukushima Futaba	0 Pcs. Planned Delivery Time Ø 31 Weeks Available on order	(at least 1050 or mul. of 1050)	COR	Ceramic wire resistor	Fukushima Futaba	THT	bulk	2.2	kOhm	5.0 %	350 ppm/°	5.0 W	13.0 mm	9.0 mm	25.5 mm	5.0 mm	-25.0 °C	155.0 °C
54	Manufacturers Part No. COR5 3K3 J (COR53K3J) Fukushima Futaba Ceramic wire resistor COR 5W 3,3kOhm 5%	Customer Part No. Customer Project No.	Fukushima Futaba	0 Pcs. Planned Delivery Time Ø 29 Weeks Available on order	(at least 1050 or mul. of 1050)	COR	Ceramic wire resistor	Fukushima Futaba	THT	bulk	3.3	kOhm	5.0 %	350 ppm/°	5.0 W	13.0 mm	9.0 mm	25.5 mm	5.0 mm	-25.0 °C	155.0 °C
55	Manufacturers Part No. COR5 470R J (COR5470RJ) Fukushima Futaba Ceramic wire resistor COR 5W 470Ohm 5%	Customer Part No. Customer Project No.	Fukushima Futaba	130 Pcs. Planned Delivery Time Ø 31 Weeks Available (from stock)	(at least 10 or mul. of 10)	COR	Ceramic wire resistor	Fukushima Futaba	THT	bulk	470.0	Ohm	5.0 %	350 ppm/°	5.0 W	13.0 mm	9.0 mm	25.5 mm	5.0 mm	-25.0 °C	155.0 °C
56	Manufacturers Part No. COR5 4K7 J (COR54K7J) Fukushima Futaba Ceramic wire resistor COR 5W 4,7kOhm 5%	Customer Part No. Customer Project No.	Fukushima Futaba	0 Pcs. Planned Delivery Time Ø 31 Weeks Available on order	(at least 100 or mul. of 100)	COR	Ceramic wire resistor	Fukushima Futaba	THT	bulk	4.7	kOhm	5.0 %	350 ppm/°	5.0 W	13.0 mm	9.0 mm	25.5 mm	5.0 mm	-25.0 °C	155.0 °C
57	Manufacturers Part No. MPC70 0R12 K (MPC700R12K) Fukushima Futaba Metal band resistor MPC70 2W 0,12Ohm 10%	Customer Part No. Customer Project No.	Fukushima Futaba	70 Pcs. Planned Delivery Time Ø 31 Weeks Available (from stock)	(at least 10 or mul. of 10)	MPC70	Metal band resistor	Fukushima Futaba	THT	bulk	0.12	Ohm	10.0 %	350 ppm/°	2.0 W	13.0 mm	4.0 mm	8.0 mm	9.0 mm	-25.0 °C	200.0 °C
58	Manufacturers Part No. MPC70 0R15 K (MPC700R15K) Fukushima Futaba Metal band resistor MPC70 2W 0,15Ohm 10%	Customer Part No. Customer Project No.	Fukushima Futaba	110 Pcs. Next Stock Receipt Week 18/2026 (200 Pcs.) Available (from stock)	(at least 10 or mul. of 10)	MPC70	Metal band resistor	Fukushima Futaba	THT	bulk	0.15	Ohm	10.0 %	350 ppm/°	2.0 W	13.0 mm	4.0 mm	8.0 mm	9.0 mm	-25.0 °C	200.0 °C
59	Manufacturers Part No. MPC70 0R18 K (MPC700R18K) Fukushima Futaba Metal band resistor MPC70 2W 0,18Ohm 10%	Customer Part No. Customer Project No.	Fukushima Futaba	310 Pcs. Planned Delivery Time Ø 31 Weeks Available (from stock)	(at least 10 or mul. of 10)	MPC70	Metal band resistor	Fukushima Futaba	THT	bulk	0.18	Ohm	10.0 %	350 ppm/°	2.0 W	13.0 mm	4.0 mm	8.0 mm	9.0 mm	-25.0 °C	200.0 °C
60	Manufacturers Part No. MPC70 0R1 K (MPC700R1K) Fukushima Futaba Metal band resistor MPC70 2W 0,1Ohm 10%	Customer Part No. Customer Project No.	Fukushima Futaba	0 Pcs. Next Stock Receipt Week 31/2026 (260 Pcs.) Available (from stock)	(at least 10 or mul. of 10)	MPC70	Metal band resistor	Fukushima Futaba	THT	bulk	0.1	Ohm	10.0 %	350 ppm/°	2.0 W	13.0 mm	4.0 mm	8.0 mm	9.0 mm	-25.0 °C	200.0 °C
61	Manufacturers Part No. MPC70 0R22 K (MPC700R22K) Fukushima Futaba Metal band resistor MPC70 2W 0,22Ohm 10%	Customer Part No. Customer Project No.	Fukushima Futaba	3.670 Pcs. Next Stock Receipt Week 31/2026 (2.000 Pcs.) Available (from stock)	(at least 10 or mul. of 10)	MPC70	Metal band resistor	Fukushima Futaba	THT	bulk	0.22	Ohm	10.0 %	350 ppm/°	2.0 W	13.0 mm	4.0 mm	8.0 mm	9.0 mm	-25.0 °C	200.0 °C
62	Manufacturers Part No. MPC70 0R27 K (MPC700R27K) Fukushima Futaba Metal band resistor MPC70 2W 0,27Ohm 10%	Customer Part No. Customer Project No.	Fukushima Futaba	1.790 Pcs. Planned Delivery Time Ø 31 Weeks Available (from stock)	(at least 10 or mul. of 10)	MPC70	Metal band resistor	Fukushima Futaba	THT	bulk	0.27	Ohm	10.0 %	350 ppm/°	2.0 W	13.0 mm	4.0 mm	8.0 mm	9.0 mm	-25.0 °C	200.0 °C
63	Manufacturers Part No. MPC70 0R33 K (MPC700R33K) Fukushima Futaba Metal band resistor MPC70 2W 0,33Ohm 10%	Customer Part No. Customer Project No.	Fukushima Futaba	910 Pcs. Next Stock Receipt Week 31/2026 (1.000 Pcs.) Available (from stock)	(at least 10 or mul. of 10)	MPC70	Metal band resistor	Fukushima Futaba	THT	bulk	0.33	Ohm	10.0 %	350 ppm/°	2.0 W	13.0 mm	4.0 mm	8.0 mm	9.0 mm	-25.0 °C	200.0 °C
64	Manufacturers Part No. MPC70 0R47 K (MPC700R47K) Fukushima Futaba Metal band resistor MPC70 2W 0,47Ohm 10%	Customer Part No. Customer Project No.	Fukushima Futaba	1.820 Pcs. Next Stock Receipt Week 36/2026 (1.000 Pcs.) Available (from stock)	(at least 10 or mul. of 10)	MPC70	Metal band resistor	Fukushima Futaba	THT	bulk	0.47	Ohm	10.0 %	350 ppm/°	2.0 W	13.0 mm	4.0 mm	8.0 mm	9.0 mm	-25.0 °C	200.0 °C
65	Manufacturers Part No. MPC70 0R68 K (MPC700R68K) Fukushima Futaba Metal band resistor MPC70 2W 0,68Ohm 10%	Customer Part No. Customer Project No.	Fukushima Futaba	780 Pcs. Planned Delivery Time Ø 31 Weeks Available (from stock)	(at least 10 or mul. of 10)	MPC70	Metal band resistor	Fukushima Futaba	THT	bulk	0.68	Ohm	10.0 %	350 ppm/°	2.0 W	13.0 mm	4.0 mm	8.0 mm	9.0 mm	-25.0 °C	200.0 °C
66	Manufacturers Part No. MPC70 1R K (MPC701RK) Fukushima Futaba Metal band resistor MPC70 2W 1Ohm 10%	Customer Part No. Customer Project No.	Fukushima Futaba	610 Pcs. Next Stock Receipt Week 23/2026 (750 Pcs.) Available (from stock)	(at least 10 or mul. of 10)	MPC70	Metal band resistor	Fukushima Futaba	THT	bulk	1.0	Ohm	10.0 %	350 ppm/°	2.0 W	13.0 mm	4.0 mm	8.0 mm	9.0 mm	-25.0 °C	200.0 °C
67	Manufacturers Part No. CWR2 1R0 J (CWR21R0J) Fukushima Futaba Ceramic wire resistor CWR 2W 1Ohm 5%	Customer Part No. Customer Project No.	Fukushima Futaba	0 Pcs. Planned Delivery Time Ø 31 Weeks Available on order	(at least 1200 or mul. of 1200)	CWR	Ceramic wire resistor	Fukushima Futaba	THT	bulk	1.0	Ohm	5.0 %	350 ppm/°	2.0 W	11.0 mm	7.0 mm	20.5 mm	5.0 mm	-25.0 °C	155.0 °C
68	Manufacturers Part No. CWR2 22R J (CWR222RJ) Fukushima Futaba Ceramic wire resistor CWR 2W 22Ohm 5%	Customer Part No. Customer Project No.	Fukushima Futaba	140 Pcs. Planned Delivery Time Ø 31 Weeks Available (from stock)	(at least 10 or mul. of 10)	CWR	Ceramic wire resistor	Fukushima Futaba	THT	bulk	22.0	Ohm	5.0 %	350 ppm/°	2.0 W	11.0 mm	7.0 mm	20.5 mm	5.0 mm	-25.0 °C	155.0 °C
69	Manufacturers Part No. CWR2 2R2 J (CWR22R2J) Fukushima Futaba Ceramic wire resistor CWR 2W 2,2Ohm 5%	Customer Part No. Customer Project No.	Fukushima Futaba	260 Pcs. Planned Delivery Time Ø 31 Weeks Available (from stock)	(at least 10 or mul. of 10)	CWR	Ceramic wire resistor	Fukushima Futaba	THT	bulk	2.2	Ohm	5.0 %	350 ppm/°	2.0 W	11.0 mm	7.0 mm	20.5 mm	5.0 mm	-25.0 °C	155.0 °C
70	Manufacturers Part No. CWR2 3R3 J (CWR23R3J) Fukushima Futaba Ceramic wire resistor CWR 2W 3,3Ohm 5%	Customer Part No. Customer Project No.	Fukushima Futaba	0 Pcs. Planned Delivery Time Ø 31 Weeks Available on order	(at least 1200 or mul. of 1200)	CWR	Ceramic wire resistor	Fukushima Futaba	THT	bulk	3.3	Ohm	5.0 %	350 ppm/°	2.0 W	11.0 mm	7.0 mm	20.5 mm	5.0 mm	-25.0 °C	155.0 °C
71	Manufacturers Part No. CWR2 47R J (CWR247RJ) Fukushima Futaba Ceramic wire resistor CWR 2W 47Ohm 5%	Customer Part No. Customer Project No.	Fukushima Futaba	0 Pcs. Planned Delivery Time Ø 31 Weeks Available on order	(at least 1200 or mul. of 1200)	CWR	Ceramic wire resistor	Fukushima Futaba	THT	bulk	47.0	Ohm	5.0 %	350 ppm/°	2.0 W	11.0 mm	7.0 mm	20.5 mm	5.0 mm	-25.0 °C	155.0 °C
72	Manufacturers Part No. CWR2 4R7 J (CWR24R7J) Fukushima Futaba Ceramic wire resistor CWR 2W 4,7Ohm 5%	Customer Part No. Customer Project No.	Fukushima Futaba	0 Pcs. Planned Delivery Time Ø 31 Weeks Available on order	(at least 200 or mul. of 200)	CWR	Ceramic wire resistor	Fukushima Futaba	THT	bulk	4.7	Ohm	5.0 %	350 ppm/°	2.0 W	11.0 mm	7.0 mm	20.5 mm	5.0 mm	-25.0 °C	155.0 °C
73	Manufacturers Part No. CWR2 6R8 J (CWR26R8J) Fukushima Futaba Ceramic wire resistor CWR 2W 6,8Ohm 5%	Customer Part No. Customer Project No.	Fukushima Futaba	180 Pcs. Planned Delivery Time Ø 31 Weeks Available (from stock)	(at least 10 or mul. of 10)	CWR	Ceramic wire resistor	Fukushima Futaba	THT	bulk	6.8	Ohm	5.0 %	350 ppm/°	2.0 W	11.0 mm	7.0 mm	20.5 mm	5.0 mm	-25.0 °C	155.0 °C
74	Manufacturers Part No. MPC71 0R12 K (MPC710R12K) Fukushima Futaba Metal band resistor MPC71 5W 0,12Ohm 10%	Customer Part No. Customer Project No.	Fukushima Futaba	550 Pcs. Planned Delivery Time Ø 31 Weeks Available (from stock)	(at least 10 or mul. of 10)	MPC71	Metal band resistor	Fukushima Futaba	THT	bulk	0.12	Ohm	10.0 %	350 ppm/°	5.0 W	14.0 mm	5.0 mm	18.0 mm	9.0 mm	-25.0 °C	200.0 °C
75	Manufacturers Part No. MPC71 0R1 K (MPC710R1K) Fukushima Futaba Metal band resistor MPC71 5W 0,1Ohm 10%	Customer Part No. Customer Project No.	Fukushima Futaba	1.640 Pcs. Planned Delivery Time Ø 31 Weeks Available (from stock)	(at least 10 or mul. of 10)	MPC71	Metal band resistor	Fukushima Futaba	THT	bulk	0.1	Ohm	10.0 %	350 ppm/°	5.0 W	14.0 mm	5.0 mm	18.0 mm	9.0 mm	-25.0 °C	200.0 °C

‹ 1 2 3 4 5 ··· 22 ›
