WSL1206R0150FEA
Vishay SMD Metal band resistor WSL 1206 0,25W 0,015Ohm 1%
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
3.850 Pcs. in stock
Planned delivery time
Ø 14 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 4000 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 50 or multiple of 50)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Resistance value
- 0,015 Ohm
- Resistance tolerance
- 1 %
- Rated power
- 0.25 W
- Housing
- 1206
- RoHS-Conform
Specifications
Open all
Dimensions and weights
- Dimension: Length
- 0.126 mm
- Dimension: Width
- 0.063 mm
- Dimension: Height
- 0.025 mm
- Weight
- 16.2 g
Operating conditions
- Operating Temperature Min.
- -65 °C
- Operating Temperature Max.
- 170 °C
Technical features
- Solderability
- 260°C / 10s
- Resistance value
- 0.015
- Resistance unit
- Ohm
- Resistance value
- 0,015 Ohm
- Resistance tolerance
- 1 %
- Rated power
- 0.25 W
- Temperature coefficient
- 20 ppm/°
Safety/Certifications
- Standards
- AEC-Q200-qualifiziert
