IHLP3232DZEK1R0M01
Vishay Inductors SMD throttle IHLP-3232DZ-01 18A 1µH -20-20 8,64mm 8,18mm 4mm
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
0 Pcs. in stock
Planned delivery time
Ø 27 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available on order
Data Sheet
ECAD Model
Prices
Manufacturer bundle 1250 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 1250 or multiple of 1250)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Kind
- throttle
- Inductance
- 1 µH
- Inductance tolerance[%]
- -20 - 20
- Nominal resistance
- 5,4 mOhm
- Rated current
- 18 A
- Housing
- SMD
- Dimension: Length
- 8.64 mm
- Dimension: Width
- 8.18 mm
- Dimension: Height
- 4 mm
- RoHS-Conform
Specifications
Open all
Dimensions and Weights
- Dimension: Length
- 8.64 mm
- Dimension: Width
- 8.18 mm
- Dimension: Height
- 4 mm
Operating conditions
- Operating Temperature Min.
- -55 °C
- Operating Temperature Max.
- 125 °C
Technical Features
- Inductance
- 1 µH
- Inductance value
- 1
- Inductance unit
- µH
- Inductance tolerance[%]
- -20 - 20
- Nominal resistance
- 5,4 mOhm
- Rated current
- 18 A
- Saturation Current
- 24 A
