70MT120KPBF

Vishay Screw Mount Power Bridge Rectifier 70A 1.200V 1,55V MT-K

70MT120KB
Manufacturer Part No.
70MT120KPBF
Schukat Part No.
70MT120KB
Manufacturer
Vishay
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

Item no longer available!

Planned delivery time
---
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
EOL 29.07.2025
Discontinued by manufacturer without replacement
Replacement / Follow-up View entire series
Data Sheet
Open PDF
ECAD Model
Downloads

Prices

Manufacturer bundle 15 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

(Uf) Forward Voltage
1.55 V
(If) Forward Current
70 A
(Urrm) Peak Recurrent Reverse Voltage Max.
1,200 V
Manufacturer Package
MT-K
RoHS-Conform

Specifications

Close all

General

Manufacturer
  • Vishay
Type
  • Power Bridge Rectifier
Series
  • 70MT
Product group
  • V7886
Packaging
  • Boxed
Assembly Type
  • Screw Mount
Manufacturer Package
  • MT-K

Operating conditions

Barrier Layer temperature, min. (TJ)
  • -40 °C
Barrier Layer Temperature, max. (TJ)
  • 150 °C
Storage Temperature Min.
  • -40 °C
Storage Temperature Max.
  • 150 °C

Electrical Properties

(Uf) Forward Voltage
  • 1.55 V
(If) Forward Current
  • 70 A
(Urrm) Peak Recurrent Reverse Voltage Max.
  • 1,200 V

Safety/Certifications

Approvals
  • UL
