6025 101 501
Varta Lithium manganese dioxide (LiMn2O4) Button Cell 6025 CR2025 3V 165mAh
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
1.440 Pcs. in stock
Planned delivery time
Ø 29 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 800 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 20 or multiple of 20)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- UN Number (Dangerous Goods)
- 3090 - Lithium Metal Battery
- Rated Voltage
- 3 V
- Nominal capacity
- 165 mAh
- Chemical system
- Lithium manganese dioxide (LiMn2O4)
- IEC Code
- CR2025
Specifications
Open all
Operating conditions
- Self-discharge (% p.m.)
- 0.083 %/Monat
- Storage Temperature Min.
- -55 °C
- Storage Temperature Max.
- 70 °C
- Shelf life (years)
- 10
Electrical features
- Nominal capacity
- 165 mAh
- Energy storage, capacity
- 0.495 Wh
- Rated Voltage
- 3 V
Conformity
- REACH Notice
- REACh Art. 33: contains 1,2-dimethoxyethane; ethylene glycol dimethyl ether(EGDME) CAS# 110-71-4
Hazardous Substances/Goods
- UN Number (Dangerous Goods)
- 3090 - Lithium Metal Battery
Documents
6025.pdf
MSDS_05_Primary_Lithium_Button_Series_CR_en.pdf
