Results (481)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | Assembly Type | Form of Delivery | Varistor voltage (@1mA) | Surge current | Power consumption | Max. Operating voltage (AC) | Max. Operating voltage (DC) | Operating Temperature Min. | Operating Temperature Max. | Diameter, resistor body | Pitch |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
51 |  | Manufacturers Part No. JVR14N391K87YAW(JVR14N391K) Joyin Metal oxide varistor JVR 350V 4.500A Ø16,5mm P7,5mm | Customer Part No. Customer Project No. | 1.200 Pcs. Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 350.0 V | 4500.0 A | 120.0 J | 250.0 V AC | 390.0 V DC | -40.0 °C | 85.0 °C | 16.5 mm | 7.5 mm | |||||
52 | | Manufacturers Part No. JVR14N431K87YAW(JVR14N431K) Joyin Metal oxide varistor JVR 430V 4.500A Ø16,5mm P7,5mm TOP | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 430.0 V | 4500.0 A | 132.0 J | 275.0 V AC | 430.0 V DC | -40.0 °C | 85.0 °C | 16.5 mm | 7.5 mm | |||||
53 | | Manufacturers Part No. JVR14N470K87YAW(JVR14N470K) Joyin Metal oxide varistor JVR 47V 1.000A Ø16,5mm P7,5mm | Customer Part No. Customer Project No. | 5.800 Pcs. Planned Delivery Time Ø 21 Weeks Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 47.0 V | 1000.0 A | 12.0 J | 30.0 V AC | 47.0 V DC | -40.0 °C | 85.0 °C | 16.5 mm | 7.5 mm | |||||
54 | | Manufacturers Part No. JVR14N471K87YAW(JVR14N471K) Joyin Metal oxide varistor JVR 470V 4.500A Ø16,5mm P7,5mm | Customer Part No. Customer Project No. | 16.300 Pcs. Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 470.0 V | 4500.0 A | 140.0 J | 300.0 V AC | 470.0 V DC | -40.0 °C | 85.0 °C | 16.5 mm | 7.5 mm | |||||
55 | | Manufacturers Part No. JVR05N101K65YAW(JVR05N101K) Joyin Metal oxide varistor JVR 100V 400A Ø7,5mm P5mm | Customer Part No. Customer Project No. | 1.900 Pcs. Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 100.0 V | 400.0 A | 3.5 J | 60.0 V AC | 100.0 V DC | -40.0 °C | 85.0 °C | 7.5 mm | 5.0 mm | |||||
56 | | Manufacturers Part No. JVR05N180K65YAW(JVR05N180K) Joyin Metal oxide varistor JVR 18V 100A Ø7,5mm P5mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 15 Weeks Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 18.0 V | 100.0 A | 0.6 J | 11.0 V AC | 18.0 V DC | -40.0 °C | 85.0 °C | 7.5 mm | 5.0 mm | |||||
57 | | Manufacturers Part No. JVR05N390K65YAW(JVR05N390K) Joyin Metal oxide varistor JVR 39V 100A Ø7,5mm P5mm | Customer Part No. Customer Project No. | 8.750 Pcs. Planned Delivery Time Ø 19 Weeks Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 39.0 V | 100.0 A | 1.2 J | 25.0 V AC | 39.0 V DC | -40.0 °C | 85.0 °C | 7.5 mm | 5.0 mm | |||||
58 | | Manufacturers Part No. JVR05N391K65YAW(JVR05N391K) Joyin Metal oxide varistor JVR 350V 400A Ø7,5mm P5mm | Customer Part No. Customer Project No. | 25.600 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 350.0 V | 400.0 A | 8.4 J | 250.0 V AC | 390.0 V DC | -40.0 °C | 85.0 °C | 7.5 mm | 5.0 mm | |||||
59 | | Manufacturers Part No. JVR05N431K65YAW(JVR05N431K) Joyin Metal oxide varistor JVR 43V 400A Ø7,5mm P5mm | Customer Part No. Customer Project No. | 1.200 Pcs. Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 43.0 V | 400.0 A | 16.5 J | 275.0 V AC | 430.0 V DC | -40.0 °C | 85.0 °C | 7.5 mm | 5.0 mm | |||||
60 | | Manufacturers Part No. JVR05N560K65YAW(JVR05N560K) Joyin Metal oxide varistor JVR 56V 100A Ø7,5mm P5mm | Customer Part No. Customer Project No. | 8.250 Pcs. Planned Delivery Time Ø 15 Weeks Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 56.0 V | 100.0 A | 1.8 J | 35.0 V AC | 56.0 V DC | -40.0 °C | 85.0 °C | 7.5 mm | 5.0 mm | |||||
61 | | Manufacturers Part No. JVR07N101K65YAW(JVR07N101K) Joyin Metal oxide varistor JVR 100V 1.200A Ø9mm P5mm | Customer Part No. Customer Project No. | 12.300 Pcs. Planned Delivery Time Ø 15 Weeks Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 100.0 V | 1200.0 A | 7.0 J | 60.0 V AC | 100.0 V DC | -40.0 °C | 85.0 °C | 9.0 mm | 5.0 mm | |||||
62 | | Manufacturers Part No. JVR07N201K65YAW(JVR07N201K) Joyin Metal oxide varistor JVR 200V 1.200A Ø9mm P5mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 200.0 V | 1200.0 A | 14.3 J | 130.0 V AC | 200.0 V DC | -40.0 °C | 85.0 °C | 9.0 mm | 5.0 mm | |||||
63 | | Manufacturers Part No. JVR07N220K65YAW(JVR07N220K) Joyin Metal oxide varistor JVR 22V 250A Ø9mm P5mm | Customer Part No. Customer Project No. | 16.050 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 22.0 V | 250.0 A | 1.4 J | 14.0 V AC | 22.0 V DC | -40.0 °C | 85.0 °C | 9.0 mm | 5.0 mm | |||||
64 | | Manufacturers Part No. JVR07N241K65YAW(JVR07N241K) Joyin Metal oxide varistor JVR 240V 1.200A Ø9mm P5mm | Customer Part No. Customer Project No. | 6.250 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 240.0 V | 1200.0 A | 16.8 J | 150.0 V AC | 240.0 V DC | -40.0 °C | 85.0 °C | 9.0 mm | 5.0 mm | |||||
65 | | Manufacturers Part No. JVR07N390K65YAW(JVR07N390K) Joyin Metal oxide varistor JVR 39V 250A Ø9mm P5mm | Customer Part No. Customer Project No. | 4.300 Pcs. Planned Delivery Time Ø 19 Weeks Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 39.0 V | 250.0 A | 2.4 J | 25.0 V AC | 39.0 V DC | -40.0 °C | 85.0 °C | 9.0 mm | 5.0 mm | |||||
66 | | Manufacturers Part No. JVR07N391K65YAW(JVR07N391K) Joyin Metal oxide varistor JVR 350V 1.200A Ø9mm P5mm | Customer Part No. Customer Project No. | 37.050 Pcs. Planned Delivery Time Ø 21 Weeks Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 350.0 V | 1200.0 A | 30.0 J | 250.0 V AC | 390.0 V DC | -40.0 °C | 85.0 °C | 9.0 mm | 5.0 mm | |||||
67 | | Manufacturers Part No. JVR07N431K65YAW(JVR07N431K) Joyin Metal oxide varistor JVR 430V 1.200A Ø9mm P5mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 430.0 V | 1200.0 A | 33.0 J | 275.0 V AC | 430.0 V DC | -40.0 °C | 85.0 °C | 9.0 mm | 5.0 mm | |||||
68 | | Manufacturers Part No. JVR07N470K65YAW(JVR07N470K) Joyin Metal oxide varistor JVR 47V 250A Ø9mm P5mm | Customer Part No. Customer Project No. | 7.700 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 47.0 V | 250.0 A | 3.0 J | 30.0 V AC | 47.0 V DC | -40.0 °C | 85.0 °C | 9.0 mm | 5.0 mm | |||||
69 | | Manufacturers Part No. JVR07N471K65YAW(JVR07N471K) Joyin Metal oxide varistor JVR 470V 1.200A Ø9mm P5mm | Customer Part No. Customer Project No. | 150 Pcs. Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | strapped | 470.0 V | 1200.0 A | 35.0 J | 300.0 V AC | 470.0 V DC | -40.0 °C | 85.0 °C | 9.0 mm | 5.0 mm | |||||
70 | | Manufacturers Part No. ERZV10D271(ERZV10D271) Panasonic Metal oxide varistor ERZV 270V 3.500A Ø12,5mm P7,5mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 19 Weeks Available on order | (at least 50 or mul. of 50) | Metal oxide varistor | Panasonic | THT | bulk | 270.0 V | 3500.0 A | 49.0 J | -40.0 °C | 85.0 °C | 12.5 mm | 7.5 mm | |||||||
71 | | Manufacturers Part No. JVZ10N101K87YAW(JVZ10N101K) Joyin Metal oxide varistor JVZ_N 100V 2.500A Ø10mm P7,5mm | Customer Part No. Customer Project No. | 10.000 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 50 or mul. of 50) | Metal oxide varistor | Joyin | THT | bulk | 100.0 V | 2500.0 A | 14.0 J | 60.0 V AC | 85.0 V DC | -40.0 °C | 105.0 °C | 10.0 mm | 7.5 mm | |||||
72 | | Manufacturers Part No. JVZ10N102K87YAW(JVZ10N102K) Joyin Metal oxide varistor JVZ_N 1.000V 2.500A Ø10mm P7,5mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 18 Weeks Available on order | (at least 10500 or mul. of 10500) | Metal oxide varistor | Joyin | THT | bulk | 1000.0 V | 2500.0 A | 112.0 J | 625.0 V AC | 825.0 V DC | -40.0 °C | 105.0 °C | 10.0 mm | 7.5 mm | |||||
73 | | Manufacturers Part No. JVZ10N112K87YAW(JVZ10N112K) Joyin Metal oxide varistor JVZ_N 1.100V 2.500A Ø10mm P7,5mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 18 Weeks Available on order | (at least 10500 or mul. of 10500) | Metal oxide varistor | Joyin | THT | bulk | 1100.0 V | 2500.0 A | 124.0 J | 680.0 V AC | 895.0 V DC | -40.0 °C | 105.0 °C | 10.0 mm | 7.5 mm | |||||
74 | | Manufacturers Part No. JVZ10N121K87YAW(JVZ10N121K) Joyin Metal oxide varistor JVZ_N 120V 2.500A Ø10mm P7,5mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 18 Weeks Available on order | (at least 10000 or mul. of 10000) | Metal oxide varistor | Joyin | THT | bulk | 120.0 V | 2500.0 A | 16.0 J | 75.0 V AC | 100.0 V DC | -40.0 °C | 105.0 °C | 10.0 mm | 7.5 mm | |||||
75 | | Manufacturers Part No. JVZ10N271K87YAW(JVZ10N271K) Joyin Metal oxide varistor JVZ_N 270V 2.500A Ø10mm P7,5mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 18 Weeks Available on order | (at least 10000 or mul. of 10000) | Metal oxide varistor | Joyin | THT | bulk | 270.0 V | 2500.0 A | 39.5 J | 175.0 V AC | 225.0 V DC | -40.0 °C | 105.0 °C | 10.0 mm | 7.5 mm |
