Manufacturer Part No.
3-49040
Schukat Part No.
3-49040
Manufacturer
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

0 Pcs. in stock

Planned delivery time
Ø 2 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available on order
Replacement / Follow-up View entire series
Data Sheet
ECAD Model
Downloads

Prices

Manufacturer bundle 6 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 6 or multiple of 6)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Packaging (g)
60 g
RoHS-Conform

Specifications

Open all

General

Manufacturer
  • UHU
Type
  • Plasticine
Series
  • REPAIR ALL
Product group
  • R3120 UHU two-component epoxy resin modeling clay
Application
  • Repairing; Bonding; Sealing; Filling; Modeling

Colour
  • white
Packaging (g)
  • 60 g
Features
  • - Grinding, drilling, sawing and painting possible after curing
    - Easy to apply, see "Processing"
    - Fast curing: 5-10 minutes
    - Can be used internaly and externally
    - Water resistant: Suitable for continous water exposure
    - Cures under water
    - Chemical resistance to hydrocarbons, ketones, alcohol, esters, salt solutions, diluted acids and bases
    - Including storage box

Operating conditions

Temperature resistance, min.
  • -30 °C
Temperature resistance, max.
  • 125 °C
Storage
  • Store in tightly closed packaging in a dry, cool and frost-free place.

Safety/Certifications

Directions
  • Working conditions: Only apply at temperatures between +15°C and +25°C.

    Personal safety: Preferably, process with gloves. After use, wash hands immediately and thoroughly with soap and water.

    Surface requirements: The surface must be dry, clean and free of dust and grease

    Preliminary surface treatment: Degrease parts to be bonded with acetone. Roughen smooth surfaces (sandpaper).

    Tools: A moist knife to cut off the required amount from the stick

    Application: Cut the required quantity from the rod with a damp knife (reinsert foil). Knead with your fingers until a homogeneous colour (dark gray) is obtained. If kneading is difficult, bring the rod at room temperature. Apply within 2 minutes after mixing and put into shape. Cut off excess mass with a knife.

    Stains/residue: Remove fingerprints by rubbing with water or a damp cloth before curing starts.

Documents

de_msds_4026700490404_uhu_repair_all_powerkitt_60g.pdf
de_msds_4026700490404_uhu_repair_all_powerkitt_60g.pdf
