Tridonic Casambi Bluetooth PWM Dimmer CV 144 W 6 A 12 V 24 V
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Item no longer available!
Planned delivery time
--- Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
EOL 25.08.2025
Discontinued by manufacturer without replacement
Data Sheet
ECAD Model
Prices
Manufacturer bundle 50 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- UN Number (Dangerous Goods)
- 3091 - Lithium Metal Battery in or with equipment
- Type
- Wireless Wall Switch
- Number of outputs
- 4
- Interfaces
- Bluetooth
Casambi
PWM - Operating mode
- CV
- Output Power
- 144 W
- Output current
- 6.000 A
- Input voltage min. DC
- 12 V
- Input voltage max. DC
- 24 V
- RoHS-Conform
Specifications
Open all
Operating conditions
- Operating expectation
- 100,000 h
- Operating Temperature Min.
- -20 °C
- Operating Temperature Max.
- 45 °C
- Storage Temperature Min.
- -25 °C
- Storage Temperature Max.
- 75 °C
Input
- Input voltage min. DC
- 12 V
- Input voltage max. DC
- 24 V
Output
- Number of outputs
- 4
- Output Power
- 144 W
- Output current
- 6.000 A
Safety/Certifications
- Protection Class IP
- IP20
- Approvals
- CE
- EAC
- KC
- RCM
- Standards (EMC)
- EN 55032
- Standards (safety)
- EN 61347-1
- EN 61347-2-13
Hazardous Substances/Goods
- UN Number (Dangerous Goods)
- 3091 - Lithium Metal Battery in or with equipment
Documents
VARTA CR2430 Sicherheitsdatenblatt.pdf
VARTA CR2430 UN38.3.pdf
