TT1000255
Torivac Transformer TT Ringkern 1.000VA 230V 2x55V 2X9,09A
NEW
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
0 Pcs. in stock
Back Order
1 Pcs.
1 Pcs.
Planned delivery time
Ø 1 Week
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available on order
Data Sheet
ECAD Model
Prices
Manufacturer bundle 1 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Type
- Transformer
- Series
- TT
- Core
- Ringkern
- Performance
- 1,000 VA
- Primary voltage
- 230 V
- Secondary voltage
- 2 x 55 V
- RoHS-Conform
Specifications
Open all
Dimensions and weights
- Dimension: Height
- 77 mm
- Diameter
- 165 mm
- Weight
- 7,100 g
Technical features
- Number of inputs
- 1
- Primary voltage
- 230 V
- Number of outputs
- 2
- Secondary voltage
- 2 x 55 V
- Secondary current
- 2 X 9,09A
- Efficiency
- 93 %
- Open circuit voltage
- 59,14
- Test voltage (prim./sec.)
- 4.2 kV
- No-load current, typ. (230V)
- 10 mA
- Performance
- 1,000 VA
- Temperature resistance
- 60-70°C
- Operating Temperature Max.
- 120 °C
- End temperature in the event of a short circuit, max.
- 200 °C
- Recommended primary fuse
- 5,500 mA
- Insulation resistance, min. (500V DC)
- 10 MOhm
Safety/Certifications
- Standards
- UNE EN 61558\nUNE-EN 60204-1:2019\n2011/65/EU (RoHs)\nCEM2014/30/EU\n1107/2009\n2014/35/UE
