SDF-1,6-160
Talema Inductors storage chokes SD 1,6A 160µH -15-15% 205µJ moulded
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Item no longer available!
Back Order
0 Pcs.
0 Pcs.
Planned delivery time
--- Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
EOL 27.06.2023
Article discontinued
Data Sheet
ECAD Model
Prices
Manufacturer bundle 1500 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 1500 or multiple of 1500)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Kind
- storage chokes
- Inductance
- 160 µH
- Inductance tolerance
- -15 %
- Nominal resistance
- 127 mOhm
- Storage energy
- 205 µJ
- Rated current
- 1.6 A
- Dimension: Length
- 17.5 mm
- Dimension: Width
- 15 mm
- Dimension: Height
- 11 mm
- Structure
- moulded
- RoHS-Conform
Specifications
Open all
Dimensions and weights
- Dimension: Length
- 17.5 mm
- Dimension: Width
- 15 mm
- Dimension: Height
- 11 mm
- Wire diameter
- 0.8 mm
Operating conditions
- Operating Temperature Min.
- -40 °C
- Operating Temperature Max.
- 125 °C
Technical features
- Inductance
- 160 µH
- Inductance tolerance
- -15 %
- Open circuit inductance
- 251 µH
- Nominal resistance
- 127 mOhm
- Rated current
- 1.6 A
- Storage energy
- 205 µJ
- Structure
- moulded
- Anzahl Wicklungen
- 1
