188275-8
TE Connectivity Micro-Match 8pol. 1,27mm
TOP
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
2.140 Pcs. in stock
Next Stock Receipt
Week 02/2025
1.800 Pcs.
1.800 Pcs.
Planned delivery time
Ø 21 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 900 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 10 or multiple of 10)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Series
- 188275
- Labeling or description
- Micro-Match
- Colour
- red
- Number of poles
- 8
- Dimension: Length
- 12.2 mm
- Rated current
- 1.5 A
- Dimension: Width
- 5 mm
- Pitch
- 1.27 mm
- Rated voltage DC
- 230 V DC
- Operating Temperature Min.
- -40 °C
- Operating Temperature Max.
- 105 °C
- RoHS-Conform
Specifications
Open all
Dimensions and weights
- Dimension: Length
- 12.2 mm
- Dimension: Width
- 5 mm
- Height (incl. pins)
- 5.3 mm
- Pitch
- 1.27 mm
Operating conditions
- Operating Temperature Min.
- -40 °C
- Operating Temperature Max.
- 105 °C
Technical features
- Rated current
- 1.5 A
- Rated voltage DC
- 230 V DC
- Contact resistance
- 100 mOhm
Mechanical features
- Insertion force per contact, max.
- 5 N
- Insertion force per contact, min.
- 1 N
- Kontaktbeschichtung Eingang
- verzinnt
Safety/Certifications
- Class of Inflammability
- UL 94 V-0
