LM2940HR-5.0
TAEJIN LDO Voltage Regulator 1.000mA 26V TO-263
NEW
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
800 Pcs. in stock
Planned delivery time
Ø 6 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 800 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 5 or multiple of 5)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Type
- LDO Voltage Regulator
- Supply Voltage Max.
- 26 V
- Output Voltage Min./Fixed
- 5 V
- Output current
- 1.000 mA
- Droput Voltage
- 0.4 V
- Output Type
- fixed
- Manufacturer Package
- TO-263
- RoHS-Conform
Specifications
Open all
Operating conditions
- Operating Temperature, min. (TA)
- -40 °C
- Operating Temperature, max. (TA)
- 85 °C
- Barrier Layer temperature, min. (TJ)
- -40 °C
- Barrier Layer Temperature, max. (TJ)
- 125 °C
- Storage Temperature Min.
- -65 °C
- Storage Temperature Max.
- 150 °C
Electrical Properties
- Output Current 1
- 1,000 mA
- Droput Voltage
- 0.4 V
- Supply Voltage Max.
- 26 V
- Output current
- 1.000 mA
- Output Voltage Min./Fixed
- 5 V
- Output Type
- fixed
