PP098L-S

Supertronic PP98 Wall/table housing ABS (Acrylonitrile Butadiene Styrene) 218mmx140mmx55mm gray IP65

PP98GL
Manufacturer Part No.
PP098L-S
Schukat Part No.
PP98GL
Manufacturer
Supertronic
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

9 Pcs. in stock

Planned delivery time
Ø 4 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available (from stock)
Replacement / Follow-up View entire series
Data Sheet
Open PDF
ECAD Model
Downloads

Prices

Manufacturer bundle 1 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Notice
Cross-references:
Here you will find suitable Accessories for Enclosures.
Type
Wall/table housing
Dimension: Length
218 mm
Dimension: Width
140 mm
Dimension: Height
55 mm
Colour
gray
Material
ABS (Acrylonitrile Butadiene Styrene)
Protection Class IP
IP65
RoHS-Conform

Specifications

Open all

General

Manufacturer
  • Supertronic
Series
  • PP98
Product group
  • G4550
Material
  • ABS (Acrylonitrile Butadiene Styrene)
Colour
  • gray
Type
  • Wall/table housing
Type of Mounting
  • Screw
Product description
  • The PP98 model from Supertronic's Deskone series is a plastic enclosure with IP65 protection, offering high protection against water and dust and therefore ideal for outdoor use. Made from robust UL94-HB ABS, this enclosure features a distinctive oval design and is perfect for large desktop devices that require a recessed surface for a membrane keyboard. With external dimensions of 218 x 140 x 56 mm and internal dimensions of 203 x 125 x 44 mm, this enclosure rests on a sturdy base and consists of two parts: the enclosure and the cover, which are assembled using four M3 screws on the front cover for easy removal. It is ideal for embedded systems, transmitters, barometers, gas and humidity sensors, and temperature measurement and control applications that require a high level of protection. This flexibility allows Supertronic to adapt the enclosure to the specific requirements of each project while maintaining high quality and design standards.
Features

  • - Desktop enclosures made of ABS in black, white or grey
    - Screw mounting or snap-in mounting
    - Consisting of lower part with base and upper part, partly with removable front panel
    - Front oval
    - Protection class IP65
    - Partly with a recessed area on the upper side to accommodate a membrane keyboard

Notice

Dimensions and Weights

Dimension: Length
  • 218 mm
Dimension: Width
  • 140 mm
Dimension: Height
  • 55 mm

Safety/Certifications

Protection Class IP
  • IP65
