Results (351)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Mains connection/phases | Output Power | Output voltage | Output current | Efficiency | Input voltage min. AC | Input voltage max. AC | Operating Temperature Min. | Operating Temperature Max. | Dimension: Width | Dimension: Height | Dimension: Depth | Protection class | Application | Approvals | Standards (safety) | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
101 |  | Manufacturers Part No. XTR-240-12PI(XTR-240-12PI) MEAN WELL AC/DC industrial power supply unit DIN Rail 180W 12V 15A | Customer Part No. Customer Project No. | 60 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 180.0 W | 12.0 V | 15.0 A | 88.7 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 48.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC-OK-Signal Parallel Function Peak Power | |||||
102 | | Manufacturers Part No. XTR-240-48PI(XTR-240-48PI) MEAN WELL AC/DC industrial power supply unit DIN Rail 240W 48V 5A | Customer Part No. Customer Project No. | 58 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 240.0 W | 48.0 V | 5.0 A | 93.5 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 48.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC-OK-Signal Parallel Function Peak Power | |||||
103 | | Manufacturers Part No. XTR-240P-48(XTR-240P-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 240W 48V 5A | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order | (at least 200 or mul. of 100) | MEAN WELL | II/III | 240.0 W | 48.0 V | 5.0 A | 93.5 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 48.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC-OK-Signal Parallel Function Peak Power | |||||
104 | | Manufacturers Part No. XTR-240P-12LA(XTR-240P-12LA) MEAN WELL AC/DC industrial power supply unit DIN Rail 180W 12V 15A | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order | (at least 200 or mul. of 100) | MEAN WELL | II/III | 180.0 W | 12.0 V | 15.0 A | 88.7 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 48.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC-OK-Signal Parallel Function Peak Power | |||||
105 | | Manufacturers Part No. XTR-240P-36LA(XTR-240P-36LA) MEAN WELL AC/DC industrial power supply unit DIN Rail 239,8W 36V 6,66A | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order | (at least 200 or mul. of 100) | MEAN WELL | II/III | 239.8 W | 36.0 V | 6.66 A | 92.5 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 48.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC-OK-Signal Parallel Function Peak Power | |||||
106 | | Manufacturers Part No. XTR-240P-24PI(XTR-240P-24PI) MEAN WELL AC/DC industrial power supply unit DIN Rail 240W 24V 10A | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order | (at least 200 or mul. of 100) | MEAN WELL | II/III | 240.0 W | 24.0 V | 10.0 A | 92.5 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 48.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC-OK-Signal Parallel Function Peak Power | |||||
107 | | Manufacturers Part No. XTR-240P-48PI(XTR-240P-48PI) MEAN WELL AC/DC industrial power supply unit DIN Rail 240W 48V 5A | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order | (at least 200 or mul. of 100) | MEAN WELL | II/III | 240.0 W | 48.0 V | 5.0 A | 93.5 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 48.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC-OK-Signal Parallel Function Peak Power | |||||
108 | | Manufacturers Part No. HDR-15-12(HDR-15-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 15W 12V 1,25A TOP | Customer Part No. Customer Project No. | 36.321 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 15.0 W | 12.0 V | 1.25 A | 85.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 17.5 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable output voltage DC compatible LPS | |||||
109 | | Manufacturers Part No. HDR-15-24(HDR-15-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 15,2W 24V 0,63A TOP | Customer Part No. Customer Project No. | 31.519 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 15.2 W | 24.0 V | 0.63 A | 86.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 17.5 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable output voltage DC compatible LPS | |||||
110 | | Manufacturers Part No. HDR-15-48(HDR-15-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 15,4W 48V 0,32A TOP | Customer Part No. Customer Project No. | 743 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 15.4 W | 48.0 V | 0.32 A | 87.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 17.5 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable output voltage DC compatible LPS | |||||
111 | | Manufacturers Part No. HDR-15-5(HDR-15-5) MEAN WELL AC/DC industrial power supply unit DIN Rail 12W 5V 2,4A TOP | Customer Part No. Customer Project No. | 21.941 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 12.0 W | 5.0 V | 2.4 A | 80.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 17.5 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable output voltage DC compatible LPS | |||||
112 | | Manufacturers Part No. MDR-20-12(MDR-20-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 20W 12V 1,67A TOP | Customer Part No. Customer Project No. | 4.957 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 20.0 W | 12.0 V | 1.67 A | 80.0 % | 85.0 V | 264.0 V | -20.0 °C | 70.0 °C | 22.5 mm | 90.0 mm | 100.0 mm | I | ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA UL | EN 62368-1 | Adjustable output voltage DC compatible DC-OK-Signal | |||||
113 | | Manufacturers Part No. HDR-30-24(HDR-30-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 36W 24V 1,5A TOP | Customer Part No. Customer Project No. | 36.942 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 36.0 W | 24.0 V | 1.5 A | 89.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 35.0 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable output voltage DC compatible LPS | |||||
114 | | Manufacturers Part No. HDR-30-5(HDR-30-5) MEAN WELL AC/DC industrial power supply unit DIN Rail 15W 5V 3,00A TOP | Customer Part No. Customer Project No. | 3.731 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 15.0 W | 5.0 V | 3.0 A | 82.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 35.0 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable output voltage DC compatible LPS | |||||
115 | | Manufacturers Part No. DRA-40-12(DRA-40-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 40,08W 12V 3,34A | Customer Part No. Customer Project No. | 130 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 40.08 W | 12.0 V | 3.34 A | 85.0 % | 90.0 V | 264.0 V | -30.0 °C | 70.0 °C | 40.0 mm | 90.0 mm | 100.0 mm | I | ITE Industry | CE EAC EN IEC UKCA UL | EN 62368-1 UL 62368-1 | Adjustable output current Adjustable output voltage DC compatible LPS | |||||
116 | | Manufacturers Part No. DRA-40-24(DRA-40-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 40,8W 24V 1,7A | Customer Part No. Customer Project No. | 113 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 40.8 W | 24.0 V | 1.7 A | 87.0 % | 90.0 V | 264.0 V | -30.0 °C | 70.0 °C | 40.0 mm | 90.0 mm | 100.0 mm | I | ITE Industry | CE EAC EN IEC UKCA UL | EN 62368-1 UL 62368-1 | Adjustable output current Adjustable output voltage DC compatible LPS | |||||
117 | | Manufacturers Part No. MDR-40-12(MDR-40-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 40W 12V 3,33A TOP | Customer Part No. Customer Project No. | 1.364 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 40.0 W | 12.0 V | 3.33 A | 86.0 % | 85.0 V | 264.0 V | -20.0 °C | 70.0 °C | 40.0 mm | 90.0 mm | 100.0 mm | I | ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA | EN 62368-1 UL 60950-1 | Adjustable output voltage DC compatible DC-OK-Signal | |||||
118 | | Manufacturers Part No. MDR-40-24(MDR-40-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 40,8W 24V 1,7A TOP | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 40.8 W | 24.0 V | 1.7 A | 88.0 % | 85.0 V | 264.0 V | -20.0 °C | 70.0 °C | 40.0 mm | 90.0 mm | 100.0 mm | I | ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA | EN 62368-1 UL 60950-1 | Adjustable output voltage DC compatible DC-OK-Signal | |||||
119 | | Manufacturers Part No. MDR-40-48(MDR-40-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 39,8W 48V 0,83A | Customer Part No. Customer Project No. | 305 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 39.8 W | 48.0 V | 0.83 A | 88.0 % | 85.0 V | 264.0 V | -20.0 °C | 70.0 °C | 40.0 mm | 90.0 mm | 100.0 mm | I | ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA | EN 62368-1 UL 60950-1 | Adjustable output voltage DC compatible DC-OK-Signal | |||||
120 | | Manufacturers Part No. MDR-40-5(MDR-40-5) MEAN WELL AC/DC industrial power supply unit DIN Rail 30W 5V 6A TOP | Customer Part No. Customer Project No. | 883 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 30.0 W | 5.0 V | 6.0 A | 78.0 % | 85.0 V | 264.0 V | -20.0 °C | 70.0 °C | 40.0 mm | 90.0 mm | 100.0 mm | I | ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA | EN 62368-1 UL 60950-1 | Adjustable output voltage DC compatible DC-OK-Signal | |||||
121 | | Manufacturers Part No. WDR-60-12(WDR-60-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 60W 12V 5,00A | Customer Part No. Customer Project No. | 295 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I/II | 60.0 W | 12.0 V | 5.0 A | 86.0 % | 180.0 V | 550.0 V | -30.0 °C | 85.0 °C | 32.0 mm | 125.2 mm | 102.0 mm | I | Building Automation ITE Industry | BIS CE EAC EN UKCA | EN 61558-1 EN 61558-2-16 | Adjustable output voltage DC compatible DC-OK-Signal | |||||
122 | | Manufacturers Part No. HDR-60-12(HDR-60-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 54W 12V 4,5A TOP | Customer Part No. Customer Project No. | 6.705 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 54.0 W | 12.0 V | 4.5 A | 88.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 52.2 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable output voltage DC compatible LPS | |||||
123 | | Manufacturers Part No. WDR-60-24(WDR-60-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 60W 24V 2,5A | Customer Part No. Customer Project No. | 2.716 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I/II | 60.0 W | 24.0 V | 2.5 A | 89.0 % | 180.0 V | 550.0 V | -30.0 °C | 85.0 °C | 32.0 mm | 125.2 mm | 102.0 mm | I | Building Automation ITE Industry | BIS CE EAC EN UKCA | EN 61558-1 EN 61558-2-16 | Adjustable output voltage DC compatible DC-OK-Signal | |||||
124 | | Manufacturers Part No. HDR-60-15(HDR-60-15) MEAN WELL AC/DC industrial power supply unit DIN Rail 60W 15V 4,00A TOP | Customer Part No. Customer Project No. | 1.861 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 60.0 W | 15.0 V | 4.0 A | 89.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 52.2 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable output voltage DC compatible LPS | |||||
125 | | Manufacturers Part No. WDR-60-48(WDR-60-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 60W 48V 1,25A | Customer Part No. Customer Project No. | 3 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I/II | 60.0 W | 48.0 V | 1.25 A | 90.0 % | 180.0 V | 550.0 V | -30.0 °C | 85.0 °C | 32.0 mm | 125.2 mm | 102.0 mm | I | Building Automation ITE Industry | CE EAC EN UKCA | EN 61558-1 EN 61558-2-16 | Adjustable output voltage DC compatible DC-OK-Signal |
