Results (351)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Mains connection/phases | Output Power | Output voltage | Output current | Efficiency | Input voltage min. AC | Input voltage max. AC | Operating Temperature Min. | Operating Temperature Max. | Dimension: Width | Dimension: Height | Dimension: Depth | Protection class | Application | Approvals | Standards (safety) | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
51 |  | Manufacturers Part No. XDR-960E-36(XDR-960E-36) MEAN WELL AC/DC industrial power supply unit DIN Rail 957,6W 36V 26,6A | Customer Part No. Customer Project No. | 34 Pcs. Planned Delivery Time Ø 19 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 957.6 W | 36.0 V | 26.6 A | 95.0 % | 180.0 V | 264.0 V | -40.0 °C | 70.0 °C | 96.0 mm | 125.2 mm | 132.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | Adjustable output voltage DC compatible DC-OK-Signal Parallel Function | |||||
52 | | Manufacturers Part No. XDR-120E-12(XDR-120E-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 120W 12V 10A | Customer Part No. Customer Project No. | 827 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 120.0 W | 12.0 V | 10.0 A | 89.0 % | 85.0 V | 264.0 V | -40.0 °C | 70.0 °C | 30.0 mm | 125.2 mm | 116.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | Adjustable output voltage DC compatible DC-OK-Signal | |||||
53 | | Manufacturers Part No. XDR-120E-36(XDR-120E-36) MEAN WELL AC/DC industrial power supply unit DIN Rail 119,88W 36V 3,33A | Customer Part No. Customer Project No. | 44 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 119.88 W | 36.0 V | 3.33 A | 91.0 % | 85.0 V | 264.0 V | -40.0 °C | 70.0 °C | 30.0 mm | 125.2 mm | 116.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | Adjustable output voltage DC compatible DC-OK-Signal | |||||
54 | | Manufacturers Part No. XDR-120E-48(XDR-120E-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 120W 48V 2,5A | Customer Part No. Customer Project No. | 621 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 120.0 W | 48.0 V | 2.5 A | 91.0 % | 85.0 V | 264.0 V | -40.0 °C | 70.0 °C | 30.0 mm | 125.2 mm | 116.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | Adjustable output voltage DC compatible DC-OK-Signal | |||||
55 | | Manufacturers Part No. XDR-150E-24(XDR-150E-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 156W 24V 6,5A | Customer Part No. Customer Project No. | 337 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 156.0 W | 24.0 V | 6.5 A | 91.0 % | 85.0 V | 264.0 V | -40.0 °C | 70.0 °C | 30.0 mm | 125.2 mm | 116.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | Adjustable output voltage DC compatible DC-OK-Signal | |||||
56 | | Manufacturers Part No. XDR-480E-24(XDR-480E-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 480W 24V 20A | Customer Part No. Customer Project No. | 787 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 480.0 W | 24.0 V | 20.0 A | 95.5 % | 85.0 V | 264.0 V | -40.0 °C | 70.0 °C | 48.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | Adjustable output voltage DC compatible DC-OK-Signal Parallel Function | |||||
57 | | Manufacturers Part No. XDR-960E-24(XDR-960E-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 960W 24V 40A | Customer Part No. Customer Project No. | 20 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 960.0 W | 24.0 V | 40.0 A | 94.5 % | 180.0 V | 264.0 V | -40.0 °C | 70.0 °C | 96.0 mm | 125.2 mm | 132.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | Adjustable output voltage DC compatible DC-OK-Signal Parallel Function | |||||
58 | | Manufacturers Part No. XDR-150E-36(XDR-150E-36) MEAN WELL AC/DC industrial power supply unit DIN Rail 155,9W 36V 4,33A | Customer Part No. Customer Project No. | 44 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 155.9 W | 36.0 V | 4.33 A | 91.0 % | 85.0 V | 264.0 V | -40.0 °C | 70.0 °C | 30.0 mm | 125.2 mm | 116.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | Adjustable output voltage DC compatible DC-OK-Signal | |||||
59 | | Manufacturers Part No. XDR-150E-48(XDR-150E-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 156W 48V 3,25A | Customer Part No. Customer Project No. | 72 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 156.0 W | 48.0 V | 3.25 A | 91.0 % | 85.0 V | 264.0 V | -40.0 °C | 70.0 °C | 30.0 mm | 125.2 mm | 116.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | Adjustable output voltage DC compatible DC-OK-Signal | |||||
60 | | Manufacturers Part No. XDR-480E-36(XDR-480E-36) MEAN WELL AC/DC industrial power supply unit DIN Rail 478,8W 36V 13,3A | Customer Part No. Customer Project No. | 52 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 478.8 W | 36.0 V | 13.3 A | 95.5 % | 85.0 V | 264.0 V | -40.0 °C | 70.0 °C | 48.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | Adjustable output voltage DC compatible DC-OK-Signal Parallel Function | |||||
61 | | Manufacturers Part No. XDR-480E-48(XDR-480E-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 480W 48V 10A | Customer Part No. Customer Project No. | 139 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 480.0 W | 48.0 V | 10.0 A | 96.0 % | 85.0 V | 264.0 V | -40.0 °C | 70.0 °C | 48.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | Adjustable output voltage DC compatible DC-OK-Signal Parallel Function | |||||
62 | | Manufacturers Part No. XDR-960E-48(XDR-960E-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 960W 48V 20A | Customer Part No. Customer Project No. | 25 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 960.0 W | 48.0 V | 20.0 A | 95.5 % | 180.0 V | 264.0 V | -40.0 °C | 70.0 °C | 96.0 mm | 125.2 mm | 132.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | Adjustable output voltage DC compatible DC-OK-Signal Parallel Function | |||||
63 | | Manufacturers Part No. XTR-480-48(XTR-480-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 480W 48V 10A | Customer Part No. Customer Project No. | 37 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 480.0 W | 48.0 V | 10.0 A | 95.5 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 63.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC compatible DC-OK-Signal Peak Power Remote Function | |||||
64 | | Manufacturers Part No. XTR-480-12LA(XTR-480-12LA) MEAN WELL AC/DC industrial power supply unit DIN Rail 360W 12V 30A | Customer Part No. Customer Project No. | 24 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 360.0 W | 12.0 V | 30.0 A | 93.0 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 63.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC compatible DC-OK-Signal Parallel Function Peak Power Remote Function | |||||
65 | | Manufacturers Part No. XTR-480-24LA(XTR-480-24LA) MEAN WELL AC/DC industrial power supply unit DIN Rail 480W 24V 20A | Customer Part No. Customer Project No. | 59 Pcs. Planned Delivery Time Ø 19 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 480.0 W | 24.0 V | 20.0 A | 94.0 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 63.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC compatible DC-OK-Signal Parallel Function Peak Power Remote Function | |||||
66 | | Manufacturers Part No. XTR-480-36LA(XTR-480-36LA) MEAN WELL AC/DC industrial power supply unit DIN Rail 478,8W 36V 13,3A | Customer Part No. Customer Project No. | 8 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 478.8 W | 36.0 V | 13.3 A | 94.5 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 63.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC compatible DC-OK-Signal Parallel Function Peak Power Remote Function | |||||
67 | | Manufacturers Part No. XTR-480-48LA(XTR-480-48LA) MEAN WELL AC/DC industrial power supply unit DIN Rail 480W 48V 10A | Customer Part No. Customer Project No. | 33 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 480.0 W | 48.0 V | 10.0 A | 95.5 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 63.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC compatible DC-OK-Signal Parallel Function Peak Power Remote Function | |||||
68 | | Manufacturers Part No. XTR-480-12PI(XTR-480-12PI) MEAN WELL AC/DC industrial power supply unit DIN Rail 360W 12V 30A | Customer Part No. Customer Project No. | 28 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 360.0 W | 12.0 V | 30.0 A | 93.0 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 63.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC compatible DC-OK-Signal Parallel Function Peak Power Remote Function | |||||
69 | | Manufacturers Part No. XTR-480-24PI(XTR-480-24PI) MEAN WELL AC/DC industrial power supply unit DIN Rail 480W 24V 20A | Customer Part No. Customer Project No. | 57 Pcs. Planned Delivery Time Ø 19 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 480.0 W | 24.0 V | 20.0 A | 94.0 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 63.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC compatible DC-OK-Signal Parallel Function Peak Power Remote Function | |||||
70 | | Manufacturers Part No. XTR-480-36PI(XTR-480-36PI) MEAN WELL AC/DC industrial power supply unit DIN Rail 478,8W 36V 13,3A | Customer Part No. Customer Project No. | 8 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 478.8 W | 36.0 V | 13.3 A | 94.5 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 63.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC compatible DC-OK-Signal Parallel Function Peak Power Remote Function | |||||
71 | | Manufacturers Part No. XTR-480-48PI(XTR-480-48PI) MEAN WELL AC/DC industrial power supply unit DIN Rail 480W 48V 10A | Customer Part No. Customer Project No. | 38 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 480.0 W | 48.0 V | 10.0 A | 95.5 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 63.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC compatible DC-OK-Signal Parallel Function Peak Power Remote Function | |||||
72 | | Manufacturers Part No. XTR-480-12(XTR-480-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 360W 12V 30A | Customer Part No. Customer Project No. | 101 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 360.0 W | 12.0 V | 30.0 A | 93.0 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 63.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC compatible DC-OK-Signal Peak Power Remote Function | |||||
73 | | Manufacturers Part No. XTR-480-24(XTR-480-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 480W 24V 20A | Customer Part No. Customer Project No. | 45 Pcs. Planned Delivery Time Ø 19 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 480.0 W | 24.0 V | 20.0 A | 94.0 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 63.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC compatible DC-OK-Signal Peak Power Remote Function | |||||
74 | | Manufacturers Part No. XTR-480-36(XTR-480-36) MEAN WELL AC/DC industrial power supply unit DIN Rail 478,8W 36V 13,3A | Customer Part No. Customer Project No. | 8 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 478.8 W | 36.0 V | 13.3 A | 94.5 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 63.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC compatible DC-OK-Signal Peak Power Remote Function | |||||
75 | | Manufacturers Part No. XTR-240-12(XTR-240-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 180W 12V 15A | Customer Part No. Customer Project No. | 49 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | II/III | 180.0 W | 12.0 V | 15.0 A | 88.7 % | 320.0 V | 600.0 V | -40.0 °C | 85.0 °C | 48.0 mm | 125.2 mm | 125.0 mm | I | ITE Industry MSR/Laboratory | AS/NZ BSMI CCC CE CSA EAC EN IEC RCM UKCA UL | EN 61010-1 EN 61558-1 EN 61558-2-16 EN 62368-1 IEC 61010-1 IEC 61558-1 IEC 62368-1 UL 61010-1 | DC-OK-Signal Parallel Function Peak Power |
