UMS05-1A80-75L
StandexMeder THT Reed relay SIP SIL Series UMS SPST-NO 5VDC 0,5A 400Ohm
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
95 Pcs. in stock
Planned delivery time
Ø 9 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 75 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 5 or multiple of 5)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Type
- Reed relay SIP SIL
- Series
- UMS
- Rated voltage DC
- 5 V DC
- Switching current
- 0.5 A
- contacts
- SPST-NO
- Coil resistance
- 400 Ohm
- Dimension: Length
- 6.8 mm
- Dimension: Width
- 3.6 mm
- Dimension: Height
- 9.5 mm
- RoHS-Conform
Specifications
Open all
Dimensions and Weights
- Dimension: Length
- 6.8 mm
- Dimension: Width
- 3.6 mm
- Dimension: Height
- 9.5 mm
Operating conditions
- Operating Temperature Min.
- -20 °C
- Operating Temperature Max.
- 85 °C
Technical Features
- Rated voltage DC
- 5 V DC
- Switching voltage, max. DC
- 170 V DC
- Response voltage
- 3.75 V
- Drop-out voltage
- 0.5 V
- Switching current
- 0.5 A
- Transport Current
- 1 A
- Rated power
- 62.5 mW
- Switching capacity (W)
- 10 W
- Coil resistance
- 400 Ohm
- Contact resistance
- 200 mOhm
- Insulation resistance
- 10^12 Ohm
- Response time
- 0.2 ms
- Drop-out time
- 0.1 ms
- Vibration resistance
- 20 G
