KT24-1A-40L-THT

Standex Electronics THT Reed relay Series KT SPST-NO 24VDC 1A 1.800Ohm Solder connection AEC-Q200

KT24-1A-40L-THTKT24-1A-40L-THTKT24-1A-40L-THTKT24-1A-40L-THT
Manufacturer Part No.
KT24-1A-40L-THT
Schukat Part No.
KT24-1A-40L-THT
Manufacturer
Standex Electronics
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

0 Pcs. in stock

Next Stock Receipt
Week 20/2026
15 Pcs.
Planned delivery time
Ø 31 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available (from stock)
Replacement / Follow-up View entire series
Data Sheet
Open PDF
ECAD Model
Downloads

Prices

Manufacturer bundle 15 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 15 or multiple of 15)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Series
KT
Termination Style
Solder connection
contacts
SPST-NO
Contact: Switching Current (min/typ/max)
1 A
Coil: Nominal Voltage DC
24 V DC
Coil resistance
1,800 Ohm
RoHS-Conform

Specifications

Open all

General

Manufacturer
  • Standex Electronics
Type
  • Reed relay
Series
  • KT
Product group
  • E4517
contacts
  • SPST-NO
Assembly Type
  • THT
Termination Style
  • Solder connection
Application

  • Inverters in photovoltaic collectors, automotive, battery management systems and others

Features

  • • High voltage relay
    • High dielectric strength
    • AEC-Q200 certified

Dimensions and Weights

Dimension: Length
  • 30.2 mm
Dimension: Width
  • 10.2 mm
Dimension: Height
  • 8.7 mm

Operating conditions

Operating Temperature Min.
  • -40 °C
Operating Temperature Max.
  • 100 °C

Technical Features

Contact: Switching Current (min/typ/max)
  • 1 A
Contact: Switching Voltage, max. DC
  • 1,000 V DC
Contact: Carry Current
  • 2.5 A
Contact: Switching Load (W)
  • 100 W
Contact resistance
  • 150 mOhm
Coil resistance
  • 1,800 Ohm
Inductor power
  • 320 mW
Coil: Nominal Voltage DC
  • 24 V DC
Coil: Operating Voltage, max.
  • 30 V
Coil: Pick-up voltage
  • 16 V
Coil: Drop-out Voltage
  • 2.9 V
Response time
  • 1.1 ms
Drop-out time
  • 0.1 ms
Insulation resistance
  • 1.000 GOhm
Vibration resistance
  • 20 g

Safety/Certifications

Qualification
  • AEC-Q200
Approvals
  • cULus
