SPMH14S-3000
Speed Box header SPMHxxS Pin Box Header 2-row straight 14 Pole Pitch2,54mm gray Copper alloy vergoldet
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
15 Pcs. in stock
Next Stock Receipt
Week 33/2026
875 Pcs.
875 Pcs.
Planned delivery time
Ø 2 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 125 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 5 or multiple of 5)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Contact Type
- Pin
- Type
- Box header
- Connector Contact
- Solder
- Series
- SPMHxxS
- Colour
- gray
- Housing material
- Polybutylenterephthalat (PBT) 20% GF
- Housing
- 2-row
- Connector Coating
- Gold-plated
- Specifications
- Box Header
- Number of poles
- 14
- Standards
- EN 60603-13
- Pitch
- 2.54 mm
- Locking
- yes
- Alignment
- straight
- Locking Type
- Lever
- Operating Temperature Max.
- 85 °C
- Rated voltage AC
- 1,000 V AC
- Rated current
- 1 A
- Rated voltage DC
- 1,000 V DC
- Operating Temperature Min.
- 25 °C
- RoHS-Conform
