SLD20-700IL-ES

Self AC/DC LED power supply unit CC 20W 0,700A IP20 Trailing Edge Mode Leading Edge Mode

SLD20-700IL-ESSLD20-700IL-ESSLD20-700IL-ES
Manufacturer Part No.
SLD20-700IL-ES
Schukat Part No.
SLD20-700IL-ES
Manufacturer
Self
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

Item no longer available!

Planned delivery time
---
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
EOL 06.03.2025
Discontinued by manufacturer with replacement
Replacement / Follow-up View entire series
Data Sheet
Open PDF
ECAD Model
Downloads

Prices

Manufacturer bundle 100 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Operating mode
CC
Output Power
20 W
Output current
0.700 A
Output Voltage Min.
19 V
Output Voltage Max.
29 V
Protection Class IP
IP20
Interfaces
Leading Edge Mode
Trailing Edge Mode
RoHS-Conform

Specifications

Close all

General

Manufacturer
  • Self
Series
  • SLD20-IL-ES
Product group
  • M8720
Application
  • Lighting
Operating mode
  • CC
Package/Case
  • Enclosed Plastic
Dimension: Length
  • 121 mm
Dimension: Width
  • 45 mm
Dimension: Height
  • 20 mm
Weight
  • 75 g
Label
  • SELV; MM-Zeichen
Dimmable
Interfaces
  • Leading Edge Mode
  • Trailing Edge Mode
Manufacturer's warranty (years)
  • 5
Features
  • Independent Control Gear

Operating conditions

Operating expectation
  • 35,000 h
Operating Temperature Min.
  • -20 °C
Operating Temperature Max.
  • 40 °C
Storage Temperature Min.
  • -30 °C
Storage Temperature Max.
  • 80 °C

Input

Mains frequency min.
  • 50 Hz
Mains frequency max.
  • 60 Hz
Input voltage min. AC
  • 220 V
Input voltage max. AC
  • 240 V
Input current
  • 0.12 A
Efficiency
  • 78.5 %
No load power, less than
  • 0.5 W
Power consumption in standby mode (PSB), less than
  • 0.5 W
Inrush current, max.
  • 2 A
Max. number on B16 circuit breaker
  • 70
Max. number on C16 circuit breaker
  • 119
Power factor correction (PFC)
Power factor
  • 0.9
Connection type, input
  • Screw Terminal

Output

Number of outputs
  • 1
Output Power
  • 20 W
Output Voltage Min.
  • 19 V
Output Voltage Max.
  • 29 V
Output current
  • 0.700 A
Output current tolerance
  • -5.5 %
Overload protection
Short-circuit protection
Overvoltage protection
Overtemperature protection
Connection type, output
  • Screw Terminal

Safety/Certifications

Protection class
  • II
Protection Class IP
  • IP20
Approvals
  • CE
  • EN
  • ENEC
  • UKCA
Standards (EMC)
  • EN 55015
Standards (safety)
  • EN 61347-1
  • EN 61347-2-13

Documents

Self_Katalog_2026.pdf
Download (pdf, 5.829 KB)
SELF_SLD20-500IL-ES German.pdf
Download (pdf, 191 KB)
