3-137-396

Schurter ITU-T plug DT31 Cable C14 3 Pole IP40 10A 250VAC 70°C I

3-137-396
Manufacturer Part No.
3-137-396
Schukat Part No.
3-137-396
Manufacturer
Schurter
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

20 Pcs. in stock

Planned delivery time
Ø 8 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available (from stock)
Replacement / Follow-up View entire series
Data Sheet
Open PDF
ECAD Model
Downloads

Prices

Manufacturer bundle 1 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Contact Type
Plug
Type
ITU-T plug
Series
DT31
Colour
white
Pin Temperature
70 °C
Specifications
Cable
Number of poles
3
Standards
IEC 60320-1
Contact Type
C14
Locking
no
IP Protection Class Front Side
IP40
Rated voltage AC
250 V AC
Rated current
10 A
RoHS-Conform

Specifications

Close all

General

Manufacturer
  • Schurter
Type
  • ITU-T plug
Series
  • DT31
Alternative Part Number
  • DT31-11-0100-1504-01010114
Product group
  • F5514
Contact Type
  • Plug
Rocker colour
  • blue, illuminated
Connection
  • Cable 800mm
Number of poles
  • 3
Contact Type
  • C14
Features
  • - a standalone device with Wi-Fi and Bluetooth connectivity
    - Easy integration of smart IoT functions into existing devices
    - IEC C14 input plug
    - C13 output plug with an approx. 80 cm permanently attached cable
    - Integrated real-time energy measurement sensor with an update rate of up to 60 seconds
    - Low standby power consumption (< 0.5 W)
    - Button with RGB backlighting
    - For easy configuration, control and monitoring via smartphone app (iOS and Android)
    - Compatible with V-Lock
    - Without mains filter
Specifications
  • Cable
Protective conductor
Colour
  • white
Locking
  • no

Dimensions and Weights

Dimension: Length
  • 95.2 mm
Dimension: Width
  • 95 mm
Dimension: Height
  • 34.2 mm

Operating conditions

Pin Temperature
  • 70 °C

Technical Features

Rated current
  • 10 A
Rated voltage AC
  • 250 V AC

Safety/Certifications

Approvals
  • CE
  • UKCA
  • VDE
Standards
  • IEC 60320-1
Protection class
  • I
IP Protection Class Front Side
  • IP40
