D03045400G-00
SUNON HA Axial DC fan 12VDC 39,8mm x 10,4mm Vapo Bearing 3,22m³/h 10,5dBA
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Item no longer available!
Planned delivery time
--- Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
EOL 31.12.2023
Discontinued by manufacturer with replacement
Data Sheet
ECAD Model
Prices
Manufacturer bundle 200 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 200 or multiple of 200)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Notice
- Cross-references:
Here you will find suitable Fan Accessories. - Type
- Axial
- Rated Voltage
- 12VDC
- Dimension: Height
- 39.8 mm
- Dimension: Depth
- 10.4 mm
- Bearing type
- Vapo Bearing
- Air Flow (Rate)
- 3.22 m³/h
- Noise
- 10.5 dBA
- RoHS-Conform
Specifications
Open all
Operating conditions
- Minimum Operating Temperature
- -10 °C
- Maximum Operating Temperature
- 70 °C
- Minimum Storage Temperature
- -40 °C
- Maximum Storage Temperature
- 70 °C
Performance features
- Air Flow (Rate)
- 3.22 m³/h
- Life Expectancy MTTF
- 70,000 h bei 40°C, for test conditions, see datasheet
- Noise
- 10.5 dBA
- Speed RPM
- 4,400 U/min
- Static pressure [inch-H₂O]
- 0.04 inch-H₂O
- Static pressure [mm/H₂O]
- 0.10 mm/H₂O
- Static pressure [Pa]
- 9.96 Pa
Electrical properties
- Rated Voltage
- 12VDC
- Rated current
- 0.025 A
- Operating voltage range from
- 10 VDC
- Maximum Operating Voltage
- 13.8 VDC
- Starting voltage
- 10 VDC
- Power consumption
- 0.3 W
Mechanical properties
- Drive
- Electronically commutated DC motor designed as a solid shaft motor
- Housing material
- Filled Thermoplastic PBT (UL94V-0)
- Impeller material
- Filled Thermoplastic PBT (UL94V-0)
- Bearing type
- Vapo Bearing
- Assembly specifications
- 0.098 Nm to 0.196 Nm
- Termination Style
- Strand, UL1571 AWG28, Stripped, Tinned
Safety/Certifications
- Insulation class
- A
- Insulation resistance at 500V DC
- 10 MOhm
- Approvals
- TÜV
