CF1082HVL-1000U-999
SUNON CF Axial Fan EC 115VAC 80mm x 25mm Vapo Bearing Strand, AWG24, UL3266, Stripped, Tinned 67,94m³/h 32dBA
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
0 Pcs. in stock
Planned delivery time
Ø 23 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available on order
Data Sheet
ECAD Model
Prices
Manufacturer bundle 50 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Notice
- Cross-references:
Here you will find suitable Fan Accessories. - Type
- Axial
- Rated Voltage
- 115VAC
- Dimension: Height
- 80 mm
- Dimension: Depth
- 25 mm
- Bearing type
- Vapo Bearing
- Air Flow (Rate)
- 67.94 m³/h
- Noise
- 32 dBA
- RoHS-Conform
Specifications
Open all
Operating conditions
- Minimum Operating Temperature
- -20 °C
- Maximum Operating Temperature
- 70 °C
- Minimum Storage Temperature
- -40 °C
- Maximum Storage Temperature
- 70 °C
Performance features
- Air Flow (Rate)
- 67.94 m³/h
- Life Expectancy MTTF
- 70,000 h bei 40°C, for test conditions, see datasheet
- Air Flow (Rate) Speed Level 2
- 69.64 m³/h
- Noise
- 32 dBA
- Noise Speed Level 2
- 33 dBA
- Speed RPM
- 3,100 U/min
- Speed Level 2 RPM
- 3,200 U/min
- Static pressure [inch-H₂O]
- 0.14 inch-H₂O
- Static pressure [mm/H₂O]
- 0.36 mm/H₂O
- Static pressure [Pa]
- 34.86 Pa
- Static Pressure Speed Level 2 [inch-H₂O]
- 0.15 inch-H₂O
- Static pressure level 2 [mm/H₂O]
- 0.38 mm/H₂O
- Static Pressure Speed Level 2 [PA]
- 37.35 Pa
Electrical properties
- Rated Voltage
- 115VAC
- Rated current
- 0.221 A
- Rated Current Speed Level 2
- 0.211 A
- Operating voltage range from
- 100 VAC
- Maximum Operating Voltage
- 120 VAC
- Starting voltage
- 100 VAC
- Power consumption
- 3.2 W
- Power Consumption Speed Level 2
- 3.3 W
- Dielectric strength
- 1500V AC for 1s
Mechanical properties
- Drive
- Brushless 4 Pole Motor, Impedance Protected
- Switchable Speed Level
- Number of motor poles
- 4
- Housing material
- Thermoplastic PBT (UL94V-0)
- Impeller material
- Thermoplastic PBT (UL94V-0)
- Bearing type
- Vapo Bearing
- Assembly specifications
- 0.294 Nm to 0.392 Nm
- Air flow direction
- Air flow in the direction of the label Best mounting direction: any orientation
- Termination Style
- Strand, AWG24, UL3266, Stripped, Tinned
Safety/Certifications
- Insulation class
- A
- Approvals
- CE
- CUR
- TÜV
- UL
Documents
Sunon_EC_Katalog.pdf
