Results (573)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | Characteristic | Specifications | Rated voltage V AC | Rated voltage V DC | Voltage drop | Rated current | Rated breaking capacity | Operating temperature range, min. | Operating temperature range, max. | Dimension: Length | Dimension: Width | Dimension: Height | Qualification | Approvals |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
176 |  | Manufacturers Part No. 160012.0,4GT(160012.0.4GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 0,4A 12x4,4mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1500 or mul. of 1500) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 950.0 mV | 0.4 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
177 | | Manufacturers Part No. 160012.0,5GT(160012.0.5GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 0,5A 12x4,4mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1500 or mul. of 1500) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 800.0 mV | 0.5 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
178 | | Manufacturers Part No. 160012.0,63GT(160012.0.63GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 0,63A 12x4,4mm | Customer Part No. Customer Project No. | 200 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 700.0 mV | 0.63 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
179 | | Manufacturers Part No. 160012.0,8GT(160012.0.8GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 0,8A 12x4,4mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1500 or mul. of 1500) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 600.0 mV | 0.8 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
180 | | Manufacturers Part No. 160012.1,25GT(160012.1.25GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 1,25A 12x4,4mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1500 or mul. of 1500) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 350.0 mV | 1.25 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
181 | | Manufacturers Part No. 160012.1,6GT(160012.1.6GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 1,6A 12x4,4mm | Customer Part No. Customer Project No. | 200 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 340.0 mV | 1.6 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
182 | | Manufacturers Part No. 160012.1GT(160012.1GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 1A 12x4,4mm | Customer Part No. Customer Project No. | 200 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 450.0 mV | 1.0 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
183 | | Manufacturers Part No. 160012.2,5GT(160012.2.5GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 2,5A 12x4,4mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1500 or mul. of 1500) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 270.0 mV | 2.5 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
184 | | Manufacturers Part No. 160012.2GT(160012.2GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 2A 12x4,4mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1500 or mul. of 1500) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 340.0 mV | 2.0 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
185 | | Manufacturers Part No. 160012.3,15GT(160012.3.15GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 3,15A 12x4,4mm | Customer Part No. Customer Project No. | 200 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 220.0 mV | 3.15 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
186 | | Manufacturers Part No. 160012.4GT(160012.4GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 4A 12x4,4mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1500 or mul. of 1500) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 185.0 mV | 4.0 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
187 | | Manufacturers Part No. 160012.5GT(160012.5GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 5A 12x4,4mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1500 or mul. of 1500) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 155.0 mV | 5.0 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
188 | | Manufacturers Part No. 160012.6,3GT(160012.6.3GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 6,3A 12x4,4mm | Customer Part No. Customer Project No. | 200 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 165.0 mV | 6.3 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
189 | | Manufacturers Part No. 160012.8GT(160012.8GT) SIBA SMD fuse 160012 time-lag 500A 277VAC 250VDC 8A 12x4,4mm | Customer Part No. Customer Project No. | 200 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | SIBA | time-lag | 277.0 V AC | 250.0 V DC | 110.0 mV | 8.0 A | 500 A | 12.0 mm | 4.4 mm | 4.4 mm | cULus | |||||||||
190 | | Manufacturers Part No. 154000.0,75GT-5K(154000.0.75GT-5K) SIBA SMD fuse 154000 superquickacting 50A 63VDC 0,75A 3,2x1,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 63.0 V DC | 325.0 mV | 0.75 A | 50 A | 3.2 mm | 1.6 mm | 0.55 mm | |||||||||||
191 | | Manufacturers Part No. 154000.1,6GT-5K(154000.1.6GT-5K) SIBA SMD fuse 154000 superquickacting 50A 63VDC 1,6A 3,2x1,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 63.0 V DC | 168.0 mV | 1.6 A | 50 A | 3.2 mm | 1.6 mm | 0.55 mm | |||||||||||
192 | | Manufacturers Part No. 154000.3,15GT-5K(154000.3.15GT-5K) SIBA SMD fuse 154000 superquickacting 50A 63VDC 3,15A 3,2x1,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 63.0 V DC | 153.0 mV | 3.15 A | 50 A | 3.2 mm | 1.6 mm | 0.55 mm | |||||||||||
193 | | Manufacturers Part No. 152000.0,63GT-5K(152000.0.63GT-5K) SIBA SMD fuse 152000 superquickacting 50A 32VDC 0,63A 1,55x0,85mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 32.0 V DC | 331.0 mV | 0.63 A | 50 A | 1.55 mm | 0.85 mm | 0.45 mm | VDE cULus | ||||||||||
194 | | Manufacturers Part No. 152000.2,5GT-5K(152000.2.5GT-5K) SIBA SMD fuse 152000 superquickacting 50A 32VDC 2,5A 1,55x0,85mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 32.0 V DC | 151.0 mV | 2.5 A | 50 A | 1.55 mm | 0.85 mm | 0.45 mm | VDE cULus | ||||||||||
195 | | Manufacturers Part No. 152000.0,5GT-5K(152000.0.5GT-5K) SIBA SMD fuse 152000 superquickacting 50A 32VDC 0,5A 1,55x0,85mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 32.0 V DC | 361.0 mV | 0.5 A | 50 A | 1.55 mm | 0.85 mm | 0.45 mm | VDE cULus | ||||||||||
196 | | Manufacturers Part No. 152000.1,6GT-5K(152000.1.6GT-5K) SIBA SMD fuse 152000 superquickacting 50A 32VDC 1,6A 1,55x0,85mm | Customer Part No. Customer Project No. | 5.000 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | super quick acting | 32.0 V DC | 159.0 mV | 1.6 A | 50 A | 1.55 mm | 0.85 mm | 0.45 mm | VDE cULus | ||||||||||
197 | | Manufacturers Part No. 152000.1GT-5K(152000.1GT-5K) SIBA SMD fuse 152000 superquickacting 50A 32VDC 1A 1,55x0,85mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 32.0 V DC | 223.0 mV | 1.0 A | 50 A | 1.55 mm | 0.85 mm | 0.45 mm | VDE cULus | ||||||||||
198 | | Manufacturers Part No. 152000.3,15GT-5K(152000.3.15GT-5K) SIBA SMD fuse 152000 superquickacting 50A 32VDC 3,15A 1,55x0,85mm | Customer Part No. Customer Project No. | 3.400 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | super quick acting | 32.0 V DC | 120.0 mV | 3.15 A | 50 A | 1.55 mm | 0.85 mm | 0.45 mm | VDE cULus | ||||||||||
199 | | Manufacturers Part No. 154000.1,5GT-5K(154000.1.5GT-5K) SIBA SMD fuse 154000 superquickacting 50A 63VDC 1,5A 3,2x1,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 63.0 V DC | 207.0 mV | 1.5 A | 50 A | 3.2 mm | 1.6 mm | 0.55 mm | |||||||||||
200 | | Manufacturers Part No. 154000.2GT-5K(154000.2GT-5K) SIBA SMD fuse 154000 superquickacting 50A 63VDC 2A 3,2x1,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 63.0 V DC | 181.0 mV | 2.0 A | 50 A | 3.2 mm | 1.6 mm | 0.55 mm |
