Results (573)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | Characteristic | Specifications | Rated voltage V AC | Rated voltage V DC | Voltage drop | Rated current | Rated breaking capacity | Operating temperature range, min. | Operating temperature range, max. | Dimension: Length | Dimension: Width | Dimension: Height | Qualification | Approvals |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
251 |  | Manufacturers Part No. 3403.0016.11(3403.0016.11) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 1A 11x4,6mm | Customer Part No. Customer Project No. | 210 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 1.0 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
252 | | Manufacturers Part No. 3403.0016.24(3403.0016.24) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 1A 11x4,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 250 or mul. of 250) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 1.0 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
253 | | Manufacturers Part No. 3403.0019.11(3403.0019.11) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 2A 11x4,6mm | Customer Part No. Customer Project No. | 400 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 2.0 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
254 | | Manufacturers Part No. 3403.0019.24(3403.0019.24) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 2A 11x4,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 250 or mul. of 250) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 2.0 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
255 | | Manufacturers Part No. 3403.0020.11(3403.0020.11) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 2,5A 11x4,6mm | Customer Part No. Customer Project No. | 40 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 2.5 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
256 | | Manufacturers Part No. 3403.0020.24(3403.0020.24) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 2,5A 11x4,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 250 or mul. of 250) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 2.5 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
257 | | Manufacturers Part No. 3403.0022.11(3403.0022.11) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 4A 11x4,6mm | Customer Part No. Customer Project No. | 290 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 4.0 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
258 | | Manufacturers Part No. 3403.0022.24(3403.0022.24) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 4A 11x4,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 250 or mul. of 250) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 4.0 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
259 | | Manufacturers Part No. 3413.0327.22(3413.0327.22) Schurter SMD fuse UST1206 time-lag 100A 32VAC 63VDC 8A 3,2x1,6mm | Customer Part No. Customer Project No. | 100 Pcs. Planned Delivery Time Ø 13 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | Schurter | time-lag | 32.0 V AC | 63.0 V DC | 60.0 mV | 8.0 A | 100 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 0.6 mm | CE UK CA cULus | |||||||
260 | | Manufacturers Part No. 3404.0112.22(3404.0112.22) Schurter SMD fuse OMT125 time-lag 100A 125VAC 125VDC 0,5A 7,4x3,1mm | Customer Part No. Customer Project No. | 1.500 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | time-lag | 125.0 V AC | 125.0 V DC | 95.0 mV | 0.5 A | 100 A | -40.0 °C | 85.0 °C | 7.4 mm | 3.1 mm | 2.6 mm | CE cULus | |||||||
261 | | Manufacturers Part No. 3413.0328.22(3413.0328.22) Schurter SMD fuse UST1206 time-lag 100A 32VAC 63VDC 10A 3,2x1,6mm | Customer Part No. Customer Project No. | 1.800 Pcs. Planned Delivery Time Ø 13 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | Schurter | time-lag | 32.0 V AC | 63.0 V DC | 69.0 mV | 10.0 A | 100 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 0.6 mm | CE UK CA cULus | |||||||
262 | | Manufacturers Part No. 3413.0329.11(3413.0329.11) Schurter SMD fuse UST1206 time-lag 100A 32VAC 63VDC 12A 3,2x1,6mm | Customer Part No. Customer Project No. | 70 Pcs. Planned Delivery Time Ø 13 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | time-lag | 32.0 V AC | 63.0 V DC | 63.0 mV | 12.0 A | 100 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 0.6 mm | CE UK CA cULus | |||||||
263 | | Manufacturers Part No. 3413.0329.22(3413.0329.22) Schurter SMD fuse UST1206 time-lag 100A 32VAC 63VDC 12A 3,2x1,6mm | Customer Part No. Customer Project No. | 2.000 Pcs. Planned Delivery Time Ø 13 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | Schurter | time-lag | 32.0 V AC | 63.0 V DC | 63.0 mV | 12.0 A | 100 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 0.6 mm | CE UK CA cULus | |||||||
264 | | Manufacturers Part No. 3413.0330.11(3413.0330.11) Schurter SMD fuse UST1206 time-lag 100A 32VAC 63VDC 15A 3,2x1,6mm | Customer Part No. Customer Project No. | 100 Pcs. Planned Delivery Time Ø 13 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | time-lag | 32.0 V AC | 63.0 V DC | 57.0 mV | 15.0 A | 100 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 0.6 mm | CE UK CA cULus | |||||||
265 | | Manufacturers Part No. 3413.0330.22(3413.0330.22) Schurter SMD fuse UST1206 time-lag 100A 32VAC 63VDC 15A 3,2x1,6mm | Customer Part No. Customer Project No. | 1.500 Pcs. Planned Delivery Time Ø 13 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | Schurter | time-lag | 32.0 V AC | 63.0 V DC | 57.0 mV | 15.0 A | 100 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 0.6 mm | CE UK CA cULus | |||||||
266 | | Manufacturers Part No. 3413.0331.11(3413.0331.11) Schurter SMD fuse UST1206 time-lag 100A 32VAC 63VDC 20A 3,2x1,6mm | Customer Part No. Customer Project No. | 100 Pcs. Planned Delivery Time Ø 13 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | time-lag | 32.0 V AC | 63.0 V DC | 53.0 mV | 20.0 A | 100 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 0.6 mm | CE UK CA cULus | |||||||
267 | | Manufacturers Part No. 3413.0331.22(3413.0331.22) Schurter SMD fuse UST1206 time-lag 100A 32VAC 63VDC 20A 3,2x1,6mm | Customer Part No. Customer Project No. | 400 Pcs. Planned Delivery Time Ø 13 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | Schurter | time-lag | 32.0 V AC | 63.0 V DC | 53.0 mV | 20.0 A | 100 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 0.6 mm | CE UK CA cULus | |||||||
268 | | Manufacturers Part No. 3413.0332.11(3413.0332.11) Schurter SMD fuse UST1206 time-lag 100A 32VAC 63VDC 25A 3,2x1,6mm | Customer Part No. Customer Project No. | 70 Pcs. Planned Delivery Time Ø 13 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | time-lag | 32.0 V AC | 63.0 V DC | 48.0 mV | 25.0 A | 100 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 0.6 mm | CE UK CA cULus | |||||||
269 | | Manufacturers Part No. 3413.0332.22(3413.0332.22) Schurter SMD fuse UST1206 time-lag 100A 32VAC 63VDC 25A 3,2x1,6mm | Customer Part No. Customer Project No. | 100 Pcs. Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | Schurter | time-lag | 32.0 V AC | 63.0 V DC | 48.0 mV | 25.0 A | 100 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 0.6 mm | CE UK CA cULus | |||||||
270 | | Manufacturers Part No. 3404.0116.22(3404.0116.22) Schurter SMD fuse OMT125 time-lag 100A 125VAC 125VDC 4A 7,4x3,1mm | Customer Part No. Customer Project No. | 360 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | time-lag | 125.0 V AC | 125.0 V DC | 75.0 mV | 4.0 A | 100 A | -40.0 °C | 85.0 °C | 7.4 mm | 3.1 mm | 2.6 mm | CE cULus | |||||||
271 | | Manufacturers Part No. 3404.0120.11(3404.0120.11) Schurter SMD fuse OMT125 time-lag 100A 125VAC 125VDC 4A 7,4x3,1mm | Customer Part No. Customer Project No. | 380 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | time-lag | 125.0 V AC | 125.0 V DC | 77.0 mV | 4.0 A | 100 A | -40.0 °C | 85.0 °C | 7.4 mm | 3.1 mm | 2.6 mm | CE cULus | |||||||
272 | | Manufacturers Part No. 3403.0170.24(3403.0170.24) Schurter SMD fuse UMT250 time-lag 200A 250VAC 125VDC 2,5A 10,1x3mm | Customer Part No. Customer Project No. | 360 Pcs. Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | time-lag | 250.0 V AC | 125.0 V DC | 300.0 mV | 2.5 A | 200 A | -55.0 °C | 125.0 °C | 10.1 mm | 3.0 mm | 3.0 mm | CE CQC KTL METI VDE cULus | |||||||
273 | | Manufacturers Part No. 3403.0175.24(3403.0175.24) Schurter SMD fuse UMT250 time-lag 35A 250VAC 125VDC 8A 10,1x3mm | Customer Part No. Customer Project No. | 1.900 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | time-lag | 250.0 V AC | 125.0 V DC | 220.0 mV | 8.0 A | 35 A | -55.0 °C | 125.0 °C | 10.1 mm | 3.0 mm | 3.0 mm | CE METI cULus | |||||||
274 | | Manufacturers Part No. 3403.0158.24(3403.0158.24) Schurter SMD fuse UMT250 time-lag 200A 250VAC 125VDC 0,16A 10,1x3mm | Customer Part No. Customer Project No. | 1.640 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | time-lag | 250.0 V AC | 125.0 V DC | 1000.0 mV | 0.16 A | 200 A | -55.0 °C | 125.0 °C | 10.1 mm | 3.0 mm | 3.0 mm | CE CQC KTL VDE cULus | |||||||
275 | | Manufacturers Part No. 3403.0160.11(3403.0160.11) Schurter SMD fuse UMT250 time-lag 200A 250VAC 125VDC 10,1x3mm | Customer Part No. Customer Project No. | 430 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | time-lag | 250.0 V AC | 125.0 V DC | 800.0 mV | 200 A | -55.0 °C | 125.0 °C | 10.1 mm | 3.0 mm | 3.0 mm | CE CQC KTL VDE cULus |
