Results (826)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Product Family | Contact Type | Design | Housing | Alignment | Number of poles | Pitch | Contact Surface Input | Housing material | Colour | Coding | Locking Type | Connector Contact | Dimension: Width | Dimension: Height | Dimension: Depth | Operating Temperature Min. | Operating Temperature Max. | Rated current | Rated voltage DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
551 |  | Manufacturers Part No. STL950/3G-5.0-V-GRUEN(STL950WV3) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 3 Pole Pitch5mm green | Customer Part No. Customer Project No. | 2.190 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..G-5.0-V-GREEN | Pin | Box Header | 1-row | vertical | 3 | 5.0 mm | Polyamide (PA) 66 | green | codable | Solder | 16.2 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
552 | | Manufacturers Part No. STL950/4G-5.0-V-GRUEN(STL950WV4) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 4 Pole Pitch5mm green | Customer Part No. Customer Project No. | 150 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..G-5.0-V-GREEN | Pin | Box Header | 1-row | vertical | 4 | 5.0 mm | Polyamide (PA) 66 | green | codable | Solder | 21.2 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
553 | | Manufacturers Part No. STL950/5G-5.0-V-GRUEN(STL950WV5) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 5 Pole Pitch5mm green | Customer Part No. Customer Project No. | 840 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..G-5.0-V-GREEN | Pin | Box Header | 1-row | vertical | 5 | 5.0 mm | Polyamide (PA) 66 | green | codable | Solder | 26.2 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
554 | | Manufacturers Part No. STL950/6G-5.0-V-GRUEN(STL950WV6) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 6 Pole Pitch5mm green | Customer Part No. Customer Project No. | 1.410 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..G-5.0-V-GREEN | Pin | Box Header | 1-row | vertical | 6 | 5.0 mm | Polyamide (PA) 66 | green | codable | Solder | 31.2 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
555 | | Manufacturers Part No. STL950/2-5.0-V-P2.6-BK-HT(STL950/2-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 2 Pole Pitch5mm black | Customer Part No. Customer Project No. | 160 Pcs. Planned Delivery Time Ø 7 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 2 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 10.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
556 | | Manufacturers Part No. STL950/3-5.0-V-P2.6-BK-HT(STL950/3-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 3 Pole Pitch5mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 200 or mul. of 200) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 3 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 15.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
557 | | Manufacturers Part No. STL950/4-5.0-V-P2.6-BK-HT(STL950/4-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 4 Pole Pitch5mm black | Customer Part No. Customer Project No. | 140 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 4 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 20.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
558 | | Manufacturers Part No. STL950/5-5.0-V-P2.6-BK-HT(STL950/5-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 5 Pole Pitch5mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 100 or mul. of 100) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 5 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 25.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
559 | | Manufacturers Part No. STL950/6-5.0-V-P2.6-BK-HT(STL950/6-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 6 Pole Pitch5mm black | Customer Part No. Customer Project No. | 100 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 6 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 30.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
560 | | Manufacturers Part No. STL950/7-5.0-V-P2.6-BK-HT(STL950/7-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 7 Pole Pitch5mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 100 or mul. of 100) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 7 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 35.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
561 | | Manufacturers Part No. STL950/8-5.0-V-P2.6-BK-HT(STL950/8-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 8 Pole Pitch5mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 8 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 40.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
562 | | Manufacturers Part No. STL950/9-5.0-V-P2.6-BK-HT(STL950/9-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 9 Pole Pitch5mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 9 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 45.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
563 | | Manufacturers Part No. STL950/10-5.0-V-P2.6-BK-HT(STL950/10-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 10 Pole Pitch5mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 10 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 50.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
564 | | Manufacturers Part No. STL950/11-5.0-V-P2.6-BK-HT(STL950/11-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 11 Pole Pitch5mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 11 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 55.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
565 | | Manufacturers Part No. STL950/12-5.0-V-P2.6-BK-HT(STL950/12-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 12 Pole Pitch5mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 12 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 60.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
566 | | Manufacturers Part No. STL950/2-5.0-V-P2.6-BK-HTR(STL950/2-V-BK-HT-G) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 2 Pole Pitch5mm black | Customer Part No. Customer Project No. | 40 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 2 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 10.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
567 | | Manufacturers Part No. STL950/3-5.0-V-P2.6-BK-HTR(STL950/3-V-BK-HT-G) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 3 Pole Pitch5mm black | Customer Part No. Customer Project No. | 140 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 3 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 15.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
568 | | Manufacturers Part No. STL950/4-5.0-V-P2.6-BK-HTR(STL950/4-V-BK-HT-G) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 4 Pole Pitch5mm black | Customer Part No. Customer Project No. | 140 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 4 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 20.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
569 | | Manufacturers Part No. STL950/5-5.0-V-P2.6-BK-HTR(STL950/5-V-BK-HT-G) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 5 Pole Pitch5mm black | Customer Part No. Customer Project No. | 140 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 5 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 25.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
570 | | Manufacturers Part No. STL950/6-5.0-V-P2.6-BK-HTR(STL950/6-V-BK-HT-G) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 6 Pole Pitch5mm black | Customer Part No. Customer Project No. | 140 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 6 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 30.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
571 | | Manufacturers Part No. STL950/7-5.0-V-P2.6-BK-HTR(STL950/7-V-BK-HT-G) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 7 Pole Pitch5mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 140 or mul. of 140) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 7 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 35.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
572 | | Manufacturers Part No. STL950/8-5.0-V-P2.6-BK-HTR(STL950/8-V-BK-HT-G) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 8 Pole Pitch5mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 140 or mul. of 140) | PTR HARTMANN | Tray pin strip | STL950/..-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 8 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 40.0 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
573 | | Manufacturers Part No. STL950/2G-5.0-V-P2.6-BK-HT(STL950/2G-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 2 Pole Pitch5mm black | Customer Part No. Customer Project No. | 200 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..G-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 2 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 11.2 mm | 14.6 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
574 | | Manufacturers Part No. STL950/3G-5.0-V-P2.6-BK-HT(STL950/3G-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 3 Pole Pitch5mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 200 or mul. of 200) | PTR HARTMANN | Tray pin strip | STL950/..G-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 3 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 16.2 mm | 14.6 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | ||||||||
575 | | Manufacturers Part No. STL950/4G-5.0-V-P2.6-BK-HT(STL950/4G-V-BK-HT) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 4 Pole Pitch5mm black | Customer Part No. Customer Project No. | 300 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..G-5.0-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 4 | 5.0 mm | Polyphthalamid (PPA) | black | codable | Solder | 21.2 mm | 14.6 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A |
