Results (826)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Product Family | Contact Type | Design | Housing | Alignment | Number of poles | Pitch | Contact Surface Input | Housing material | Colour | Coding | Locking Type | Connector Contact | Dimension: Width | Dimension: Height | Dimension: Depth | Operating Temperature Min. | Operating Temperature Max. | Rated current | Rated voltage DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
526 |  | Manufacturers Part No. STLZ950/5F-5.08-H-P2.6-HC-HT(STLZ950/5F-HBKHCHT) PTR HARTMANN Tray pin strip STLZ950 Pin Box Header 1-row horizontal 5 Pole Pitch5,08mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Tray pin strip | STLZ950/..F-5.08-H-P2.6-BK-HC-HT | Pin | Box Header | 1-row | horizontal | 5 | 5.08 mm | Polyphthalamid (PPA) | black | codable | Solder | 35.56 mm | 11.0 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | ||||||||
527 | | Manufacturers Part No. STLZ950/6F-5.08-H-P2.6-HC-HT(STLZ950/6F-HBKHCHT) PTR HARTMANN Tray pin strip STLZ950 Pin Box Header 1-row horizontal 6 Pole Pitch5,08mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Tray pin strip | STLZ950/..F-5.08-H-P2.6-BK-HC-HT | Pin | Box Header | 1-row | horizontal | 6 | 5.08 mm | Polyphthalamid (PPA) | black | codable | Solder | 40.64 mm | 11.0 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | ||||||||
528 | | Manufacturers Part No. STLZ950/7F-5.08-H-P2.6-HC-HT(STLZ950/7F-HBKHCHT) PTR HARTMANN Tray pin strip STLZ950 Pin Box Header 1-row horizontal 7 Pole Pitch5,08mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Tray pin strip | STLZ950/..F-5.08-H-P2.6-BK-HC-HT | Pin | Box Header | 1-row | horizontal | 7 | 5.08 mm | Polyphthalamid (PPA) | black | codable | Solder | 45.72 mm | 11.0 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | ||||||||
529 | | Manufacturers Part No. STLZ950/8F-5.08-H-P2.6-HC-HT(STLZ950/8F-HBKHCHT) PTR HARTMANN Tray pin strip STLZ950 Pin Box Header 1-row horizontal 8 Pole Pitch5,08mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Tray pin strip | STLZ950/..F-5.08-H-P2.6-BK-HC-HT | Pin | Box Header | 1-row | horizontal | 8 | 5.08 mm | Polyphthalamid (PPA) | black | codable | Solder | 50.8 mm | 11.0 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | ||||||||
530 | | Manufacturers Part No. STLZ950/9F-5.08-H-P2.6-HC-HT(STLZ950/9F-HBKHCHT) PTR HARTMANN Tray pin strip STLZ950 Pin Box Header 1-row horizontal 9 Pole Pitch5,08mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Tray pin strip | STLZ950/..F-5.08-H-P2.6-BK-HC-HT | Pin | Box Header | 1-row | horizontal | 9 | 5.08 mm | Polyphthalamid (PPA) | black | codable | Solder | 55.88 mm | 11.0 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | ||||||||
531 | | Manufacturers Part No. STLZ950/10F-5.08-H-P2.6-HC-HT(STLZ950/10FHBKHCHT) PTR HARTMANN Tray pin strip STLZ950 Pin Box Header 1-row horizontal 10 Pole Pitch5,08mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Tray pin strip | STLZ950/..F-5.08-H-P2.6-BK-HC-HT | Pin | Box Header | 1-row | horizontal | 10 | 5.08 mm | Polyphthalamid (PPA) | black | codable | Solder | 60.96 mm | 11.0 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | ||||||||
532 | | Manufacturers Part No. STLZ950/11F-5.08-H-P2.6-HC-HT(STLZ950/11FHBKHCHT) PTR HARTMANN Tray pin strip STLZ950 Pin Box Header 1-row horizontal 11 Pole Pitch5,08mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Tray pin strip | STLZ950/..F-5.08-H-P2.6-BK-HC-HT | Pin | Box Header | 1-row | horizontal | 11 | 5.08 mm | Polyphthalamid (PPA) | black | codable | Solder | 66.04 mm | 11.0 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | ||||||||
533 | | Manufacturers Part No. STLZ950/12F-5.08-H-P2.6-HC-HT(STLZ950/12FHBKHCHT) PTR HARTMANN Tray pin strip STLZ950 Pin Box Header 1-row horizontal 12 Pole Pitch5,08mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Tray pin strip | STLZ950/..F-5.08-H-P2.6-BK-HC-HT | Pin | Box Header | 1-row | horizontal | 12 | 5.08 mm | Polyphthalamid (PPA) | black | codable | Solder | 71.12 mm | 11.0 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | ||||||||
534 | | Manufacturers Part No. STLZ950/2F-5.08-H-P2.6-HC-HTR(STLZ950/2FHBKHCHTG) PTR HARTMANN Tray pin strip STLZ950 Pin Box Header 1-row horizontal 2 Pole Pitch5,08mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 330 or mul. of 330) | PTR HARTMANN | Tray pin strip | STLZ950/..F-5.08-H-P2.6-BK-HC-HT | Pin | Box Header | 1-row | horizontal | 2 | 5.08 mm | Polyphthalamid (PPA) | black | codable | Solder | 20.32 mm | 11.0 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | ||||||||
535 | | Manufacturers Part No. STLZ950/3F-5.08-H-P2.6-HC-HTR(STLZ950/3FHBKHCHTG) PTR HARTMANN Tray pin strip STLZ950 Pin Box Header 1-row horizontal 3 Pole Pitch5,08mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 330 or mul. of 330) | PTR HARTMANN | Tray pin strip | STLZ950/..F-5.08-H-P2.6-BK-HC-HT | Pin | Box Header | 1-row | horizontal | 3 | 5.08 mm | Polyphthalamid (PPA) | black | codable | Solder | 25.4 mm | 11.0 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | ||||||||
536 | | Manufacturers Part No. STLZ950/4F-5.08-H-P2.6-HC-HTR(STLZ950/4FHBKHCHTG) PTR HARTMANN Tray pin strip STLZ950 Pin Box Header 1-row horizontal 4 Pole Pitch5,08mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 330 or mul. of 330) | PTR HARTMANN | Tray pin strip | STLZ950/..F-5.08-H-P2.6-BK-HC-HT | Pin | Box Header | 1-row | horizontal | 4 | 5.08 mm | Polyphthalamid (PPA) | black | codable | Solder | 30.48 mm | 11.0 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | ||||||||
537 | | Manufacturers Part No. STLZ950/5F-5.08-H-P2.6-HC-HTR(STLZ950/5FHBKHCHTG) PTR HARTMANN Tray pin strip STLZ950 Pin Box Header 1-row horizontal 5 Pole Pitch5,08mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 330 or mul. of 330) | PTR HARTMANN | Tray pin strip | STLZ950/..F-5.08-H-P2.6-BK-HC-HT | Pin | Box Header | 1-row | horizontal | 5 | 5.08 mm | Polyphthalamid (PPA) | black | codable | Solder | 35.56 mm | 11.0 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | ||||||||
538 | | Manufacturers Part No. STLZ950/6F-5.08-H-P2.6-HC-HTR(STLZ950/6FHBKHCHTG) PTR HARTMANN Tray pin strip STLZ950 Pin Box Header 1-row horizontal 6 Pole Pitch5,08mm black | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 330 or mul. of 330) | PTR HARTMANN | Tray pin strip | STLZ950/..F-5.08-H-P2.6-BK-HC-HT | Pin | Box Header | 1-row | horizontal | 6 | 5.08 mm | Polyphthalamid (PPA) | black | codable | Solder | 40.64 mm | 11.0 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | ||||||||
539 | | Manufacturers Part No. 2EDGVC-5.08-02P-14-100A(H)(2EDGVC-5.08-02P-14) DEGSON Tray pin strip 2EDGVC-5.08 Pin Box Header 1-row straight 2 Pole Pitch5,08mm green verzinnt | Customer Part No. Customer Project No. | 6.300 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Tray pin strip | Pin | Box Header | 1-row | straight | 2 | 5.08 mm | verzinnt | Polyamide (PA) 66 | green | Solder | 12.16 mm | 16.0 mm | 8.6 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
540 | | Manufacturers Part No. 2EDGVC-5.08-03P-14-100A(H)(2EDGVC-5.08-03P-14) DEGSON Tray pin strip 2EDGVC-5.08 Pin Box Header 1-row straight 3 Pole Pitch5,08mm green verzinnt | Customer Part No. Customer Project No. | 2.500 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Tray pin strip | Pin | Box Header | 1-row | straight | 3 | 5.08 mm | verzinnt | Polyamide (PA) 66 | green | Solder | 17.24 mm | 16.0 mm | 8.6 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
541 | | Manufacturers Part No. 2EDGVC-5.08-04P-14-100A(H)(2EDGVC-5.08-04P-14) DEGSON Tray pin strip 2EDGVC-5.08 Pin Box Header 1-row straight 4 Pole Pitch5,08mm green verzinnt | Customer Part No. Customer Project No. | 200 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Tray pin strip | Pin | Box Header | 1-row | straight | 4 | 5.08 mm | verzinnt | Polyamide (PA) 66 | green | Solder | 22.32 mm | 16.0 mm | 8.6 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
542 | | Manufacturers Part No. 2EDGVC-5.08-05P-14-100A(H)(2EDGVC-5.08-05P-14) DEGSON Tray pin strip 2EDGVC-5.08 Pin Box Header 1-row straight 5 Pole Pitch5,08mm green verzinnt | Customer Part No. Customer Project No. | 185 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Tray pin strip | Pin | Box Header | 1-row | straight | 5 | 5.08 mm | verzinnt | Polyamide (PA) 66 | green | Solder | 27.4 mm | 16.0 mm | 8.6 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
543 | | Manufacturers Part No. 2EDGVC-5.08-06P-14-100A(H)(2EDGVC-5.08-06P-14) DEGSON Tray pin strip 2EDGVC-5.08 Pin Box Header 1-row straight 6 Pole Pitch5,08mm green verzinnt | Customer Part No. Customer Project No. | 990 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Tray pin strip | Pin | Box Header | 1-row | straight | 6 | 5.08 mm | verzinnt | Polyamide (PA) 66 | green | Solder | 32.48 mm | 16.0 mm | 8.6 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
544 | | Manufacturers Part No. 2EDGRC-5.08-02P-14-100A(H)(2EDGRC-5.08-02P-14) DEGSON Tray pin strip 2EDGRC-5.08 Pin Box Header 1-row 90° 2 Pole Pitch5,08mm green verzinnt | Customer Part No. Customer Project No. | 4.630 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Tray pin strip | Pin | Box Header | 1-row | 90° | 2 | 5.08 mm | verzinnt | Polyamide (PA) 66 | green | Solder | 12.16 mm | 8.6 mm | 15.1 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
545 | | Manufacturers Part No. 2EDGRC-5.08-03P-14-100A(H)(2EDGRC-5.08-03P-14) DEGSON Tray pin strip 2EDGRC-5.08 Pin Box Header 1-row 90° 3 Pole Pitch5,08mm green verzinnt | Customer Part No. Customer Project No. | 830 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Tray pin strip | Pin | Box Header | 1-row | 90° | 3 | 5.08 mm | verzinnt | Polyamide (PA) 66 | green | Solder | 17.24 mm | 8.6 mm | 15.1 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
546 | | Manufacturers Part No. 2EDGRC-5.08-04P-14-100A(H)(2EDGRC-5.08-04P-14) DEGSON Tray pin strip 2EDGRC-5.08 Pin Box Header 1-row 90° 4 Pole Pitch5,08mm green verzinnt | Customer Part No. Customer Project No. | 870 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Tray pin strip | Pin | Box Header | 1-row | 90° | 4 | 5.08 mm | verzinnt | Polyamide (PA) 66 | green | Solder | 22.32 mm | 8.6 mm | 15.1 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
547 | | Manufacturers Part No. 2EDGRC-5.08-05P-14-100A(H)(2EDGRC-5.08-05P-14) DEGSON Tray pin strip 2EDGRC-5.08 Pin Box Header 1-row 90° 5 Pole Pitch5,08mm green verzinnt | Customer Part No. Customer Project No. | 910 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Tray pin strip | Pin | Box Header | 1-row | 90° | 5 | 5.08 mm | verzinnt | Polyamide (PA) 66 | green | Solder | 27.4 mm | 8.6 mm | 15.1 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
548 | | Manufacturers Part No. 2EDGRC-5.08-06P-14-100A(H)(2EDGRC-5.08-06P-14) DEGSON Tray pin strip 2EDGRC-5.08 Pin Box Header 1-row 90° 6 Pole Pitch5,08mm green verzinnt | Customer Part No. Customer Project No. | 4.300 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Tray pin strip | Pin | Box Header | 1-row | 90° | 6 | 5.08 mm | verzinnt | Polyamide (PA) 66 | green | Solder | 32.48 mm | 8.6 mm | 15.1 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
549 | | Manufacturers Part No. 2EDGRC-5.08-12P-14-100A(H)(2EDGRC-5.08-12P-14) DEGSON Tray pin strip 2EDGRC-5.08 Pin Box Header 1-row 90° 12 Pole Pitch5,08mm green verzinnt | Customer Part No. Customer Project No. | 260 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Tray pin strip | Pin | Box Header | 1-row | 90° | 12 | 5.08 mm | verzinnt | Polyamide (PA) 66 | green | Solder | 62.96 mm | 8.6 mm | 15.1 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
550 | | Manufacturers Part No. STL950/2G-5.0-V-GRUEN(STL950WV2) PTR HARTMANN Tray pin strip STL950 Pin Box Header 1-row vertical 2 Pole Pitch5mm green | Customer Part No. Customer Project No. | 7.970 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Tray pin strip | STL950/..G-5.0-V-GREEN | Pin | Box Header | 1-row | vertical | 2 | 5.0 mm | Polyamide (PA) 66 | green | codable | Solder | 11.2 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A |
