179120.1

SIBA Device fuse link 5x20mm 179120 inert 250VAC 1A

Image similar
TOP
Manufacturer Part No.
179120.1
Schukat Part No.
FST01
Manufacturer
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

26.610 Pcs. in stock

Planned delivery time
Ø 7 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available (from stock)
Replacement / Follow-up View entire series
Data Sheet
ECAD Model
Downloads

Prices

Manufacturer bundle 100 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 10 or multiple of 10)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Series
179120
Characteristic
inert
Rated voltage V AC
250 V AC
Rated current
1 A
RoHS-Conform

Specifications

Open all

General

Manufacturer
  • SIBA
Series
  • 179120
Type
  • Device fuse
Product group
  • E1441 SIBA Fuse-Links 5x20mm Time-Lag IEC127-2/3
Characteristic
  • inert
Contact material
  • Brass nickel plated
Package/Case
  • 5 x 20 mm

Technical features

Rated current
  • 1 A
Melting integral
  • 6.5 A²/s
Rated breaking capacity
  • 35 A
Rated voltage V AC
  • 250 V AC
Voltage drop
  • 90 mV
Power loss, max.
  • 0,3 W

Safety/Certifications

Approvals
  • SEMKO
  • VDE
  • cULus
Standards
  • IEC 60127-2/3, EN 60127-2/3,VDE 0820-2/3
