Results (332)
Not discontinued
In stock
RoHS compliant
Datasheet
New
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | Assembly | Housing | Rated current | Interrupting Current, Max. | Rated voltage V AC | Rated voltage V DC | Max. resistance 1 hour after switching off | Operating temperature range, min. | Operating temperature range, max. | Pitch | Dimension: Length | Dimension: Width | Dimension: Height | Diameter |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
101 | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | SMD | 2920 | 2.5 A | 100.0 A | 16.0 V DC | 85.0 mOhm | -40.0 °C | 85.0 °C | 7.98 mm | 5.44 mm | 0.9 mm | ||||||||||
102 | Customer Part No. Customer Project No. | 1.180 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Schurter | SMD | 1206 | 0.5 A | 100.0 A | 13.2 V DC | 700.0 mOhm | -40.0 °C | 85.0 °C | 3.4 mm | 1.8 mm | 0.85 mm | ||||||||||
103 | Customer Part No. Customer Project No. | 2.540 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Schurter | SMD | 1812 | 0.1 A | 40.0 A | 60.0 V DC | 15000.0 mOhm | -40.0 °C | 85.0 °C | 4.73 mm | 3.41 mm | 1.1 mm | ||||||||||
104 | Customer Part No. Customer Project No. | 1.440 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Schurter | SMD | 1812 | 0.75 A | 100.0 A | 13.2 V DC | 450.0 mOhm | -40.0 °C | 85.0 °C | 4.73 mm | 3.41 mm | 0.85 mm | ||||||||||
105 | Manufacturers Part No. RUEF090(RUEF090) Littelfuse Poly-Switch Fuse RUEF 30VAC 30VDC 0,9A radial RM5,8mm | Customer Part No. Customer Project No. | 2.670 Pcs. Planned Delivery Time Ø 4 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | radial | 0.9 A | 40.0 A | 30.0 V AC | 30.0 V DC | 120.0 mOhm | -40.0 °C | 85.0 °C | 5.8 mm | 7.4 mm | 3.0 mm | 19.8 mm | ||||||||
106 | Manufacturers Part No. RUEF160(RUEF160) Littelfuse Poly-Switch Fuse RUEF 30VAC 30VDC 1,6A radial RM5,8mm | Customer Part No. Customer Project No. | 850 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | radial | 1.6 A | 40.0 A | 30.0 V AC | 30.0 V DC | 110.0 mOhm | -40.0 °C | 85.0 °C | 5.8 mm | 8.9 mm | 3.0 mm | 22.8 mm | ||||||||
107 | Manufacturers Part No. RUEF250(RUEF250) Littelfuse Poly-Switch Fuse RUEF 30VAC 30VDC 2,5A radial RM5,8mm | Customer Part No. Customer Project No. | 5.450 Pcs. Planned Delivery Time Ø 4 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | radial | 2.5 A | 40.0 A | 30.0 V AC | 30.0 V DC | 70.0 mOhm | -40.0 °C | 85.0 °C | 5.8 mm | 11.4 mm | 3.0 mm | 25.9 mm | ||||||||
108 | Manufacturers Part No. RUEF600(RUEF600) Littelfuse Poly-Switch Fuse RUEF 30VAC 30VDC 6A radial RM10,9mm | Customer Part No. Customer Project No. | 580 Pcs. Planned Delivery Time Ø 7 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | radial | 6.0 A | 40.0 A | 30.0 V AC | 30.0 V DC | 40.0 mOhm | -40.0 °C | 85.0 °C | 10.9 mm | 16.5 mm | 3.0 mm | 31.7 mm | ||||||||
109 | Manufacturers Part No. RUEF900(RUEF900) Littelfuse Poly-Switch Fuse RUEF 30VAC 30VDC 9A radial RM10,9mm | Customer Part No. Customer Project No. | 440 Pcs. Planned Delivery Time Ø 11 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | radial | 9.0 A | 40.0 A | 30.0 V AC | 30.0 V DC | 20.0 mOhm | -40.0 °C | 85.0 °C | 10.9 mm | 24.1 mm | 3.0 mm | 36.6 mm | ||||||||
110 | Manufacturers Part No. ERFRG3001600Z(ERFRG3001600Z) ECE Poly-Switch Fuse ERFRG 16VDC 3A radial RM5,1mm | Customer Part No. Customer Project No. | 700 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | radial | 3.0 A | 100.0 A | 16.0 V DC | 105.0 mOhm | -40.0 °C | 85.0 °C | 5.1 mm | 7.1 mm | 3.0 mm | 18.6 mm | |||||||||
111 | Manufacturers Part No. ERFRG5001600Z(ERFRG5001600Z) ECE Poly-Switch Fuse ERFRG 16VDC 5A radial RM5,1mm | Customer Part No. Customer Project No. | 1.000 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | radial | 5.0 A | 40.0 A | 16.0 V DC | 44.0 mOhm | -40.0 °C | 85.0 °C | 5.1 mm | 10.4 mm | 3.0 mm | 21.9 mm | |||||||||
112 | Manufacturers Part No. ERFRA0056000Z(ERFRA0056000Z) ECE Poly-Switch Fuse ERFRA 60VDC 0,05A radial RM5,1mm | Customer Part No. Customer Project No. | 1.050 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | radial | 0.05 A | 40.0 A | 60.0 V DC | 20000.0 mOhm | -40.0 °C | 85.0 °C | 5.1 mm | 3.1 mm | 20.3 mm | 7.4 mm | |||||||||
113 | Manufacturers Part No. ERFRA0176000Z(ERFRA0176000Z) ECE Poly-Switch Fuse ERFRA 60VDC 0,17A radial RM5,1mm | Customer Part No. Customer Project No. | 20 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | radial | 0.17 A | 40.0 A | 60.0 V DC | 7000.0 mOhm | -40.0 °C | 85.0 °C | 5.1 mm | 3.1 mm | 20.3 mm | 7.4 mm | |||||||||
114 | Manufacturers Part No. ERFRA0256000Z(ERFRA0256000Z) ECE Poly-Switch Fuse ERFRA 60VDC 0,25A radial RM5,1mm | Customer Part No. Customer Project No. | 310 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | radial | 0.25 A | 40.0 A | 60.0 V DC | 3000.0 mOhm | -40.0 °C | 85.0 °C | 5.1 mm | 3.1 mm | 20.3 mm | 7.4 mm | |||||||||
115 | Customer Part No. Customer Project No. | 2.280 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | radial | 0.75 A | 40.0 A | 72.0 V DC | 600.0 mOhm | -40.0 °C | 85.0 °C | 5.8 mm | 3.0 mm | 22.8 mm | 10.2 mm | ||||||||||
116 | Customer Part No. Customer Project No. | 4.470 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | radial | 1.1 A | 40.0 A | 72.0 V DC | 380.0 mOhm | -40.0 °C | 85.0 °C | 5.8 mm | 3.0 mm | 25.1 mm | 12.8 mm | ||||||||||
117 | Customer Part No. Customer Project No. | 1.880 Pcs. Planned Delivery Time Ø 11 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | radial | 1.6 A | 40.0 A | 72.0 V DC | 220.0 mOhm | -40.0 °C | 85.0 °C | 5.8 mm | 3.0 mm | 28.4 mm | 16.3 mm | ||||||||||
118 | Customer Part No. Customer Project No. | 1.410 Pcs. Planned Delivery Time Ø 11 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | radial | 2.5 A | 40.0 A | 72.0 V DC | 130.0 mOhm | -40.0 °C | 85.0 °C | 10.9 mm | 3.0 mm | 33.0 mm | 20.8 mm | ||||||||||
119 | Manufacturers Part No. RXEF375(RXEF375) Littelfuse Poly-Switch Fuse RXEF 72VDC 3,75A radial RM10,9mm | Customer Part No. Customer Project No. | 560 Pcs. Planned Delivery Time Ø 4 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | radial | 3.75 A | 40.0 A | 72.0 V DC | 80.0 mOhm | -40.0 °C | 85.0 °C | 10.9 mm | 3.0 mm | 39.4 mm | 27.2 mm | |||||||||
120 | Manufacturers Part No. MINISMDC110F-2(MINISMDC110F-2) Littelfuse Poly-Switch Fuse miniSMD_F 8VDC 1,1A SMD | Customer Part No. Customer Project No. | 540 Pcs. Planned Delivery Time Ø 19 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | SMD | 1.1 A | 100.0 A | 8.0 V DC | 210.0 mOhm | 3.41 mm | 0.62 mm | 4.73 mm | ||||||||||||
121 | Manufacturers Part No. MINISMDC150F-2(MINISMDC150F-2) Littelfuse Poly-Switch Fuse miniSMD_F 6VDC 1,5A SMD | Customer Part No. Customer Project No. | 825 Pcs. Planned Delivery Time Ø 4 Weeks Available (from stock) | (at least 25 or mul. of 25) | Self-resetting fuse | Littelfuse | SMD | 1.5 A | 100.0 A | 6.0 V DC | 110.0 mOhm | 3.41 mm | 0.48 mm | 4.73 mm | ||||||||||||
122 | Manufacturers Part No. MINISMDC200F-2(MINISMDC200F-2) Littelfuse Poly-Switch Fuse miniSMD_F 8VDC 2A SMD | Customer Part No. Customer Project No. | 1.550 Pcs. Planned Delivery Time Ø 4 Weeks Available (from stock) | (at least 25 or mul. of 25) | Self-resetting fuse | Littelfuse | SMD | 2.0 A | 100.0 A | 8.0 V DC | 70.0 mOhm | 3.41 mm | 1.22 mm | 4.73 mm | ||||||||||||
123 | Manufacturers Part No. ERFRB1103000Z(ERFRB1103000Z) ECE Poly-Switch Fuse ERFRB 30VDC 1,1A radial RM5,1mm | Customer Part No. Customer Project No. | 790 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | radial | 1.1 A | 40.0 A | 30.0 V DC | 170.0 mOhm | -40.0 °C | 85.0 °C | 5.1 mm | 7.4 mm | 3.0 mm | 21.8 mm | |||||||||
124 | Manufacturers Part No. ERFRB1603000Z(ERFRB1603000Z) ECE Poly-Switch Fuse ERFRB 30VDC 1,6A radial RM5,1mm | Customer Part No. Customer Project No. | 900 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | radial | 1.6 A | 40.0 A | 30.0 V DC | 110.0 mOhm | -40.0 °C | 85.0 °C | 5.1 mm | 8.9 mm | 3.0 mm | 22.8 mm | |||||||||
125 | Customer Part No. Customer Project No. | 440 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Schurter | radial | 0.4 A | 40.0 A | 60.0 V DC | 1290.0 mOhm | -40.0 °C | 85.0 °C | 5.8 mm | 3.1 mm | 21.3 mm | 7.4 mm |
