Results (2250)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Input voltage min. DC | Input voltage max. DC | Output Power | Number of outputs | Output voltage | Output current | Operating mode | Package/Case | Isolation voltage I/P-O/P | Efficiency | Operating Temperature Min. | Operating Temperature Max. | Dimension: Length | Dimension: Width | Dimension: Height | Connection type, output | Application | Approvals | Standards (safety) | Features | Packaging |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
01 |  | Manufacturers Part No. SRS-0505(SRS-0505) MEAN WELL DC/DC converter regulated 5 V 0,1 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 4.5 V | 5.5 V | 0.5 W | 1 | 5.0 V | 0.1 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
02 | | Manufacturers Part No. SRS-0509(SRS-0509) MEAN WELL DC/DC converter regulated 9 V 0,056 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 4.5 V | 5.5 V | 0.5 W | 1 | 9.0 V | 0.056 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
03 | | Manufacturers Part No. SRS-0512(SRS-0512) MEAN WELL DC/DC converter regulated 12 V 0,042 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 4.5 V | 5.5 V | 0.5 W | 1 | 12.0 V | 0.042 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
04 | | Manufacturers Part No. SRS-0515(SRS-0515) MEAN WELL DC/DC converter regulated 15 V 0,034 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 4.5 V | 5.5 V | 0.5 W | 1 | 15.0 V | 0.034 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
05 | | Manufacturers Part No. SRS-1205(SRS-1205) MEAN WELL DC/DC converter regulated 5 V 0,1 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 10.0 V | 13.2 V | 0.5 W | 1 | 5.0 V | 0.1 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
06 | | Manufacturers Part No. SRS-1209(SRS-1209) MEAN WELL DC/DC converter regulated 9 V 0,056 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 10.0 V | 13.2 V | 0.5 W | 1 | 9.0 V | 0.056 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
07 | | Manufacturers Part No. SRS-1212(SRS-1212) MEAN WELL DC/DC converter regulated 12 V 0,042 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 10.0 V | 13.2 V | 0.5 W | 1 | 12.0 V | 0.042 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
08 | | Manufacturers Part No. SRS-1215(SRS-1215) MEAN WELL DC/DC converter regulated 15 V 0,034 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 10.0 V | 13.2 V | 0.5 W | 1 | 15.0 V | 0.034 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
09 | | Manufacturers Part No. SRS-2405(SRS-2405) MEAN WELL DC/DC converter regulated 5 V 0,1 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 21.0 V | 26.4 V | 0.5 W | 1 | 5.0 V | 0.1 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
10 | | Manufacturers Part No. SRS-2409(SRS-2409) MEAN WELL DC/DC converter regulated 9 V 0,056 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 21.0 V | 26.4 V | 0.5 W | 1 | 9.0 V | 0.056 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
11 | | Manufacturers Part No. SRS-2412(SRS-2412) MEAN WELL DC/DC converter regulated 12 V 0,042 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 21.0 V | 26.4 V | 0.5 W | 1 | 12.0 V | 0.042 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
12 | | Manufacturers Part No. SRS-2415(SRS-2415) MEAN WELL DC/DC converter regulated 15 V 0,034 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 21.0 V | 26.4 V | 0.5 W | 1 | 15.0 V | 0.034 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
13 | | Manufacturers Part No. SRS-4805(SRS-4805) MEAN WELL DC/DC converter regulated 5 V 0,1 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 43.0 V | 52.8 V | 0.5 W | 1 | 5.0 V | 0.1 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
14 | | Manufacturers Part No. SRS-4809(SRS-4809) MEAN WELL DC/DC converter regulated 9 V 0,056 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 43.0 V | 52.8 V | 0.5 W | 1 | 9.0 V | 0.056 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
15 | | Manufacturers Part No. SRS-4812(SRS-4812) MEAN WELL DC/DC converter regulated 12 V 0,042 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 43.0 V | 52.8 V | 0.5 W | 1 | 12.0 V | 0.042 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
16 | | Manufacturers Part No. SRS-4815(SRS-4815) MEAN WELL DC/DC converter regulated 15 V 0,034 A DIP16 1.000 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 43.0 V | 52.8 V | 0.5 W | 1 | 15.0 V | 0.034 A | regulated | DIP16 | 1000.0 V | 60.0 % | -25.0 °C | 71.0 °C | 22.6 mm | 9.9 mm | 8.4 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
17 | | Manufacturers Part No. SPRN01L-05(SPRN01L-05) MEAN WELL DC/DC converter regulated 5 V 0,2 A SIP6 1.500 V | Customer Part No. Customer Project No. | 10 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | 4.75 V | 5.5 V | 1.0 W | 1 | 5.0 V | 0.2 A | regulated | SIP6 | 1500.0 V | 68.0 % | -40.0 °C | 90.0 °C | 19.6 mm | 7.1 mm | 10.14 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
18 | | Manufacturers Part No. SPRN01L-12(SPRN01L-12) MEAN WELL DC/DC converter regulated 12 V 0,084 A SIP6 1.500 V | Customer Part No. Customer Project No. | 30 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | 4.75 V | 5.5 V | 1.008 W | 1 | 12.0 V | 0.084 A | regulated | SIP6 | 1500.0 V | 71.0 % | -40.0 °C | 90.0 °C | 19.6 mm | 7.1 mm | 10.14 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
19 | | Manufacturers Part No. SPRN01L-15(SPRN01L-15) MEAN WELL DC/DC converter regulated 15 V 0,067 A SIP6 1.500 V | Customer Part No. Customer Project No. | 48 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | 4.75 V | 5.5 V | 1.005 W | 1 | 15.0 V | 0.067 A | regulated | SIP6 | 1500.0 V | 71.0 % | -40.0 °C | 90.0 °C | 19.6 mm | 7.1 mm | 10.14 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
20 | | Manufacturers Part No. SPRN01M-05(SPRN01M-05) MEAN WELL DC/DC converter regulated 5 V 0,2 A SIP6 1.500 V | Customer Part No. Customer Project No. | 34 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | 11.4 V | 13.2 V | 1.0 W | 1 | 5.0 V | 0.2 A | regulated | SIP6 | 1500.0 V | 72.0 % | -40.0 °C | 90.0 °C | 19.6 mm | 7.1 mm | 10.14 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
21 | | Manufacturers Part No. SPRN01M-12(SPRN01M-12) MEAN WELL DC/DC converter regulated 12 V 0,084 A SIP6 1.500 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available on order | (at least 1 or mul. of 1) | MEAN WELL | 11.4 V | 13.2 V | 1.008 W | 1 | 12.0 V | 0.084 A | regulated | SIP6 | 1500.0 V | 72.0 % | -40.0 °C | 90.0 °C | 19.6 mm | 7.1 mm | 10.14 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
22 | | Manufacturers Part No. SPRN01M-15(SPRN01M-15) MEAN WELL DC/DC converter regulated 15 V 0,067 A SIP6 1.500 V | Customer Part No. Customer Project No. | 38 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | 11.4 V | 13.2 V | 1.005 W | 1 | 15.0 V | 0.067 A | regulated | SIP6 | 1500.0 V | 73.0 % | -40.0 °C | 90.0 °C | 19.6 mm | 7.1 mm | 10.14 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
23 | | Manufacturers Part No. SPRN01N-05(SPRN01N-05) MEAN WELL DC/DC converter regulated 5 V 0,2 A SIP6 1.500 V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | 22.8 V | 26.4 V | 1.0 W | 1 | 5.0 V | 0.2 A | regulated | SIP6 | 1500.0 V | 67.0 % | -40.0 °C | 90.0 °C | 19.6 mm | 7.1 mm | 10.14 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
24 | | Manufacturers Part No. SPRN01N-12(SPRN01N-12) MEAN WELL DC/DC converter regulated 12 V 0,084 A SIP6 1.500 V | Customer Part No. Customer Project No. | 22 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | 22.8 V | 26.4 V | 1.008 W | 1 | 12.0 V | 0.084 A | regulated | SIP6 | 1500.0 V | 72.0 % | -40.0 °C | 90.0 °C | 19.6 mm | 7.1 mm | 10.14 mm | THT | ITE Industry | CE EAC UKCA | Tube | |||||||
25 | | Manufacturers Part No. SPRN01N-15(SPRN01N-15) MEAN WELL DC/DC converter regulated 15 V 0,067 A SIP6 1.500 V | Customer Part No. Customer Project No. | 4 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | 22.8 V | 26.4 V | 1.005 W | 1 | 15.0 V | 0.067 A | regulated | SIP6 | 1500.0 V | 73.0 % | -40.0 °C | 90.0 °C | 19.6 mm | 7.1 mm | 10.14 mm | THT | ITE Industry | CE EAC UKCA | Tube |
