Results (336)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Mains connection/phases | Output Power | Output voltage | Output current | Efficiency | Input voltage min. AC | Input voltage max. AC | Operating Temperature Min. | Operating Temperature Max. | Dimension: Width | Dimension: Height | Dimension: Depth | Protection class | Application | Approvals | Standards (safety) | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
76 |  | Manufacturers Part No. HDR-15-24(HDR-15-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 15,2W 24V 0,63A TOP | Customer Part No. Customer Project No. | 29.927 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 15.2 W | 24.0 V | 0.63 A | 86.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 17.5 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable Output Voltage DC compatible LPS | |||||
77 | | Manufacturers Part No. HDR-15-48(HDR-15-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 15,4W 48V 0,32A TOP | Customer Part No. Customer Project No. | 697 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 15.4 W | 48.0 V | 0.32 A | 87.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 17.5 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable Output Voltage DC compatible LPS | |||||
78 | | Manufacturers Part No. MDR-20-12(MDR-20-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 20W 12V 1,67A TOP | Customer Part No. Customer Project No. | 5.911 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 20.0 W | 12.0 V | 1.67 A | 80.0 % | 85.0 V | 264.0 V | -20.0 °C | 70.0 °C | 22.5 mm | 90.0 mm | 100.0 mm | I | ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA UL | EN 62368-1 | Adjustable Output Voltage DC compatible DC-OK-Signal | |||||
79 | | Manufacturers Part No. MDR-20-15(MDR-20-15) MEAN WELL AC/DC industrial power supply unit DIN Rail 20W 15V 1,34A | Customer Part No. Customer Project No. | 305 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 20.0 W | 15.0 V | 1.34 A | 81.0 % | 85.0 V | 264.0 V | -20.0 °C | 70.0 °C | 22.5 mm | 90.0 mm | 100.0 mm | I | ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA UL | EN 62368-1 | Adjustable Output Voltage DC compatible DC-OK-Signal | |||||
80 | | Manufacturers Part No. MDR-20-24(MDR-20-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 24W 24V 1A TOP | Customer Part No. Customer Project No. | 7.404 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 24.0 W | 24.0 V | 1.0 A | 84.0 % | 85.0 V | 264.0 V | -20.0 °C | 70.0 °C | 22.5 mm | 90.0 mm | 100.0 mm | I | ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA UL | EN 62368-1 | Adjustable Output Voltage DC compatible DC-OK-Signal | |||||
81 | | Manufacturers Part No. MDR-20-5(MDR-20-5) MEAN WELL AC/DC industrial power supply unit DIN Rail 15W 5V 3A TOP | Customer Part No. Customer Project No. | 1.212 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 15.0 W | 5.0 V | 3.0 A | 76.0 % | 85.0 V | 264.0 V | -20.0 °C | 70.0 °C | 22.5 mm | 90.0 mm | 100.0 mm | I | ITE Industry | AS/NZ BIS BSMI CE EAC EN IEC UKCA UL | EN 62368-1 | Adjustable Output Voltage DC compatible DC-OK-Signal | |||||
82 | | Manufacturers Part No. HDR-30-12(HDR-30-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 24W 12V 2,00A TOP | Customer Part No. Customer Project No. | 9.081 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 24.0 W | 12.0 V | 2.0 A | 88.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 35.0 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable Output Voltage DC compatible LPS | |||||
83 | | Manufacturers Part No. HDR-30-15(HDR-30-15) MEAN WELL AC/DC industrial power supply unit DIN Rail 30W 15V 2,00A TOP | Customer Part No. Customer Project No. | 2.656 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 30.0 W | 15.0 V | 2.0 A | 89.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 35.0 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable Output Voltage DC compatible LPS | |||||
84 | | Manufacturers Part No. HDR-30-24(HDR-30-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 36W 24V 1,5A TOP | Customer Part No. Customer Project No. | 30.777 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 36.0 W | 24.0 V | 1.5 A | 89.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 35.0 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable Output Voltage DC compatible LPS | |||||
85 | | Manufacturers Part No. HDR-30-48(HDR-30-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 36W 48V 0,75A | Customer Part No. Customer Project No. | 601 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 36.0 W | 48.0 V | 0.75 A | 90.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 35.0 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable Output Voltage DC compatible LPS | |||||
86 | | Manufacturers Part No. HDR-30-5(HDR-30-5) MEAN WELL AC/DC industrial power supply unit DIN Rail 15W 5V 3,00A TOP | Customer Part No. Customer Project No. | 2.318 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 15.0 W | 5.0 V | 3.0 A | 82.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 35.0 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable Output Voltage DC compatible LPS | |||||
87 | | Manufacturers Part No. DRA-40-12(DRA-40-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 40,08W 12V 3,34A | Customer Part No. Customer Project No. | 173 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 40.08 W | 12.0 V | 3.34 A | 85.0 % | 90.0 V | 264.0 V | -30.0 °C | 70.0 °C | 40.0 mm | 90.0 mm | 100.0 mm | I | ITE Industry | CE EAC EN IEC UKCA UL | EN 62368-1 UL 62368-1 | Adjustable Output Current Adjustable Output Voltage DC compatible LPS | |||||
88 | | Manufacturers Part No. DRA-40-24(DRA-40-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 40,8W 24V 1,7A | Customer Part No. Customer Project No. | 59 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 40.8 W | 24.0 V | 1.7 A | 87.0 % | 90.0 V | 264.0 V | -30.0 °C | 70.0 °C | 40.0 mm | 90.0 mm | 100.0 mm | I | ITE Industry | CE EAC EN IEC UKCA UL | EN 62368-1 UL 62368-1 | Adjustable Output Current Adjustable Output Voltage DC compatible LPS | |||||
89 | | Manufacturers Part No. MDR-40-12(MDR-40-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 40W 12V 3,33A TOP | Customer Part No. Customer Project No. | 601 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 40.0 W | 12.0 V | 3.33 A | 86.0 % | 85.0 V | 264.0 V | -20.0 °C | 70.0 °C | 40.0 mm | 90.0 mm | 100.0 mm | I | ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA | EN 62368-1 UL 60950-1 | Adjustable Output Voltage DC compatible DC-OK-Signal | |||||
90 | | Manufacturers Part No. MDR-40-24(MDR-40-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 40,8W 24V 1,7A TOP | Customer Part No. Customer Project No. | 1.093 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 40.8 W | 24.0 V | 1.7 A | 88.0 % | 85.0 V | 264.0 V | -20.0 °C | 70.0 °C | 40.0 mm | 90.0 mm | 100.0 mm | I | ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA | EN 62368-1 UL 60950-1 | Adjustable Output Voltage DC compatible DC-OK-Signal | |||||
91 | | Manufacturers Part No. MDR-40-48(MDR-40-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 39,8W 48V 0,83A | Customer Part No. Customer Project No. | 143 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 39.8 W | 48.0 V | 0.83 A | 88.0 % | 85.0 V | 264.0 V | -20.0 °C | 70.0 °C | 40.0 mm | 90.0 mm | 100.0 mm | I | ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA | EN 62368-1 UL 60950-1 | Adjustable Output Voltage DC compatible DC-OK-Signal | |||||
92 | | Manufacturers Part No. MDR-40-5(MDR-40-5) MEAN WELL AC/DC industrial power supply unit DIN Rail 30W 5V 6A TOP | Customer Part No. Customer Project No. | 407 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 30.0 W | 5.0 V | 6.0 A | 78.0 % | 85.0 V | 264.0 V | -20.0 °C | 70.0 °C | 40.0 mm | 90.0 mm | 100.0 mm | I | ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA | EN 62368-1 UL 60950-1 | Adjustable Output Voltage DC compatible DC-OK-Signal | |||||
93 | | Manufacturers Part No. WDR-60-12(WDR-60-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 60W 12V 5,00A | Customer Part No. Customer Project No. | 360 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I/II | 60.0 W | 12.0 V | 5.0 A | 86.0 % | 180.0 V | 550.0 V | -30.0 °C | 85.0 °C | 32.0 mm | 125.2 mm | 102.0 mm | I | Building Automation ITE Industry | CE EAC EN UKCA | EN 61558-1 EN 61558-2-16 | Adjustable Output Voltage DC compatible DC-OK-Signal | |||||
94 | | Manufacturers Part No. HDR-60-12(HDR-60-12) MEAN WELL AC/DC industrial power supply unit DIN Rail 54W 12V 4,5A TOP | Customer Part No. Customer Project No. | 5.247 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 54.0 W | 12.0 V | 4.5 A | 88.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 52.2 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable Output Voltage DC compatible LPS | |||||
95 | | Manufacturers Part No. WDR-60-24(WDR-60-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 60W 24V 2,5A | Customer Part No. Customer Project No. | 1.183 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I/II | 60.0 W | 24.0 V | 2.5 A | 89.0 % | 180.0 V | 550.0 V | -30.0 °C | 85.0 °C | 32.0 mm | 125.2 mm | 102.0 mm | I | Building Automation ITE Industry | CE EAC EN UKCA | EN 61558-1 EN 61558-2-16 | Adjustable Output Voltage DC compatible DC-OK-Signal | |||||
96 | | Manufacturers Part No. HDR-60-15(HDR-60-15) MEAN WELL AC/DC industrial power supply unit DIN Rail 60W 15V 4,00A TOP | Customer Part No. Customer Project No. | 272 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 60.0 W | 15.0 V | 4.0 A | 89.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 52.2 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable Output Voltage DC compatible LPS | |||||
97 | | Manufacturers Part No. WDR-60-48(WDR-60-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 60W 48V 1,25A | Customer Part No. Customer Project No. | 4 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I/II | 60.0 W | 48.0 V | 1.25 A | 90.0 % | 180.0 V | 550.0 V | -30.0 °C | 85.0 °C | 32.0 mm | 125.2 mm | 102.0 mm | I | Building Automation ITE Industry | CE EAC EN UKCA | EN 61558-1 EN 61558-2-16 | Adjustable Output Voltage DC compatible DC-OK-Signal | |||||
98 | | Manufacturers Part No. HDR-60-24(HDR-60-24) MEAN WELL AC/DC industrial power supply unit DIN Rail 60W 24V 2,5A TOP | Customer Part No. Customer Project No. | 36.360 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 60.0 W | 24.0 V | 2.5 A | 90.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 52.2 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable Output Voltage DC compatible LPS | |||||
99 | | Manufacturers Part No. WDR-60-5(WDR-60-5) MEAN WELL AC/DC industrial power supply unit DIN Rail 50W 5V 10,00A | Customer Part No. Customer Project No. | 125 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I/II | 50.0 W | 5.0 V | 10.0 A | 83.0 % | 180.0 V | 550.0 V | -30.0 °C | 85.0 °C | 32.0 mm | 125.2 mm | 102.0 mm | I | Building Automation ITE Industry | CE EAC EN UKCA | EN 61558-1 EN 61558-2-16 | Adjustable Output Voltage DC compatible DC-OK-Signal | |||||
100 | | Manufacturers Part No. HDR-60-48(HDR-60-48) MEAN WELL AC/DC industrial power supply unit DIN Rail 60W 48V 1,25A TOP | Customer Part No. Customer Project No. | 956 Pcs. Available (from stock) | (at least 1 or mul. of 1) | MEAN WELL | I | 60.0 W | 48.0 V | 1.25 A | 91.0 % | 85.0 V | 264.0 V | -30.0 °C | 70.0 °C | 52.2 mm | 90.0 mm | 54.5 mm | II | Building Automation ITE Industry | AS/NZ BSMI CE EAC EN IEC UKCA UL | EN 61558-2-16 IEC 62368-1 UL 62368-1 | Adjustable Output Voltage DC compatible LPS |
