PCB Transformers

(455 Results)

Filter results

Show Selected	Part No.	Indiv. Part No.	Manufacturer	Availability	Quantity	Series	Manufacturer	Type	Core	Performance	Primary Voltage	Secondary Voltage	Number of outputs	Secondary Current	Dimension: Length	Dimension: Width	Dimension: Height	Temperature Resistance Class	Approvals
176	Manufacturers Part No. 45025 (MT45025) Myrra Print transformer MT450/30 UI30 6VA 2x115V 2x6V 2x500mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	180 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT450/30	Myrra	Print transformer	UI30	6.0 VA	2 x 115 V	2 x 6 V	2	2 x 500 mA	53.0 mm	44.0 mm	21.8 mm		CE UL 506 cCSA
177	Manufacturers Part No. 45026 (MT45026) Myrra Print transformer MT450/30 UI30 6VA 2x115V 2x9V 2x333mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	5 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT450/30	Myrra	Print transformer	UI30	6.0 VA	2 x 115 V	2 x 9 V	2	2 x 333 mA	53.0 mm	44.0 mm	21.8 mm		CE UL 506 cCSA
178	Manufacturers Part No. 45027 (MT45027) Myrra Print transformer MT450/30 UI30 6VA 2x115V 2x12V 2x250mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	41 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT450/30	Myrra	Print transformer	UI30	6.0 VA	2 x 115 V	2 x 12 V	2	2 x 250 mA	53.0 mm	44.0 mm	21.8 mm		CE UL 506 cCSA
179	Manufacturers Part No. 45028 (MT45028) Myrra Print transformer MT450/30 UI30 6VA 2x115V 2x15V 2x200mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	96 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT450/30	Myrra	Print transformer	UI30	6.0 VA	2 x 115 V	2 x 15 V	2	2 x 200 mA	53.0 mm	44.0 mm	21.8 mm		CE UL 506 cCSA
180	Manufacturers Part No. 45029 (MT45029) Myrra Print transformer MT450/30 UI30 6VA 2x115V 2x18V 2x167mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	12 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT450/30	Myrra	Print transformer	UI30	6.0 VA	2 x 115 V	2 x 18 V	2	2 x 167 mA	53.0 mm	44.0 mm	21.8 mm		CE UL 506 cCSA
181	Manufacturers Part No. 45030 (MT45030) Myrra Print transformer MT450/30 UI30 6VA 2x115V 2x24V 2x125mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	0 Pcs. Planned Delivery Time Ø 17 Weeks Available on order	(at least 48 or mul. of 48)	MT450/30	Myrra	Print transformer	UI30	6.0 VA	2 x 115 V	2 x 24 V	2	2 x 125 mA	53.0 mm	44.0 mm	21.8 mm		CE UL 506 cCSA
182	Manufacturers Part No. 45031 (MT45031) Myrra Print transformer MT450/30 UI30 10VA 2x115V 2x6V 2x833mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	39 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT450/30	Myrra	Print transformer	UI30	10.0 VA	2 x 115 V	2 x 6 V	2	2 x 833 mA	53.0 mm	44.0 mm	27.9 mm		CE UL 506 cCSA
183	Manufacturers Part No. 45032 (MT45032) Myrra Print transformer MT450/30 UI30 10VA 2x115V 2x9V 2x556mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	197 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT450/30	Myrra	Print transformer	UI30	10.0 VA	2 x 115 V	2 x 9 V	2	2 x 556 mA	53.0 mm	44.0 mm	27.9 mm		CE UL 506 cCSA
184	Manufacturers Part No. 45033 (MT45033) Myrra Print transformer MT450/30 UI30 10VA 2x115V 2x12V 2x417mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	291 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT450/30	Myrra	Print transformer	UI30	10.0 VA	2 x 115 V	2 x 12 V	2	2 x 417 mA	53.0 mm	44.0 mm	27.9 mm		CE UL 506 cCSA
185	Manufacturers Part No. 45034 (MT45034) Myrra Print transformer MT450/30 UI30 10VA 2x115V 2x15V 2x333mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	44 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT450/30	Myrra	Print transformer	UI30	10.0 VA	2 x 115 V	2 x 15 V	2	2 x 333 mA	53.0 mm	44.0 mm	27.9 mm		CE UL 506 cCSA
186	Manufacturers Part No. BVUI210002 (BVUI210002) Hahn Print transformer UI 21 UI21 1VA 2x115V 2x6V 2x83mA absolutely short circuit proof TOP	Customer Part No. Customer Project No.	Hahn	220 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock)	(at least 1 or mul. of 1)	UI 21	Hahn	Print transformer	UI21	1.0 VA	2 x 115 V	2 x 6 V	2	2 x 83 mA	34.1 mm	29.6 mm	15.2 mm		CE ENEC10 VDE cCSA cULus
187	Manufacturers Part No. BVUI210003 (BVUI210003) Hahn Print transformer UI 21 UI21 1VA 2x115V 2x9V 2x56mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	42 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock)	(at least 1 or mul. of 1)	UI 21	Hahn	Print transformer	UI21	1.0 VA	2 x 115 V	2 x 9 V	2	2 x 56 mA	34.1 mm	29.6 mm	15.2 mm		CE ENEC10 VDE cCSA cULus
188	Manufacturers Part No. BVUI210004 (BVUI210004) Hahn Print transformer UI 21 UI21 1VA 2x115V 2x12V 2x41mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	0 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock)	(at least 1 or mul. of 1)	UI 21	Hahn	Print transformer	UI21	1.0 VA	2 x 115 V	2 x 12 V	2	2 x 41 mA	34.1 mm	29.6 mm	15.2 mm		CE ENEC10 VDE cCSA cULus
189	Manufacturers Part No. 44265 (MT706-1) Myrra Print transformer MT7 EI48 10VA 230V 6V 1.666mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	5 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT7	Myrra	Print transformer	EI48	10.0 VA	230 V	6 V	1	1.666 mA	51.0 mm	42.8 mm	35.1 mm	T 50/B	ENEC10 UL VDE cCSA
190	Manufacturers Part No. BVUI210005 (BVUI210005) Hahn Print transformer UI 21 UI21 1VA 2x115V 2x15V 2x33mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	13 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock)	(at least 1 or mul. of 1)	UI 21	Hahn	Print transformer	UI21	1.0 VA	2 x 115 V	2 x 15 V	2	2 x 33 mA	34.1 mm	29.6 mm	15.2 mm		CE ENEC10 VDE cCSA cULus
191	Manufacturers Part No. 44266 (MT709-1) Myrra Print transformer MT7 EI48 10VA 230V 9V 1.111mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	96 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT7	Myrra	Print transformer	EI48	10.0 VA	230 V	9 V	1	1.111 mA	51.0 mm	42.8 mm	35.1 mm	T 50/B	ENEC10 UL VDE cCSA
192	Manufacturers Part No. 44273 (MT712-2) Myrra Print transformer MT7 EI48 10VA 230V 2x12V 2x417mA not short circuit proof TOP	Customer Part No. Customer Project No.	Myrra	0 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT7	Myrra	Print transformer	EI48	10.0 VA	230 V	2 x 12 V	2	2 x 417 mA	51.0 mm	42.8 mm	35.1 mm	T 50/B	ENEC10 UL VDE cCSA
193	Manufacturers Part No. 44272 (MT709-2) Myrra Print transformer MT7 EI48 10VA 230V 2x9V 2x556mA not short circuit proof TOP	Customer Part No. Customer Project No.	Myrra	0 Pcs. Next Stock Receipt Week 24/2026 (167 Pcs.) Available (from stock)	(at least 1 or mul. of 1)	MT7	Myrra	Print transformer	EI48	10.0 VA	230 V	2 x 9 V	2	2 x 556 mA	51.0 mm	42.8 mm	35.1 mm	T 50/B	ENEC10 UL VDE cCSA
194	Manufacturers Part No. 44269 (MT718-1) Myrra Print transformer MT7 EI48 10VA 230V 18V 556mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	75 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT7	Myrra	Print transformer	EI48	10.0 VA	230 V	18 V	1	556 mA	51.0 mm	42.8 mm	35.1 mm	T 50/B	ENEC10 UL VDE cCSA
195	Manufacturers Part No. 44274 (MT715-2) Myrra Print transformer MT7 EI48 10VA 230V 2x15V 2x333mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	108 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	MT7	Myrra	Print transformer	EI48	10.0 VA	230 V	2 x 15 V	2	2 x 333 mA	51.0 mm	42.8 mm	35.1 mm	T 50/B	ENEC10 UL VDE cCSA
196	Manufacturers Part No. 44380 (MT1009-2) Myrra Print transformer 443_ EI66 30VA 230V 2x9V 2x1.660mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	61 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	443_	Myrra	Print transformer	EI66	30.0 VA	230 V	2 x 9 V	2	2 x 1.660 mA	70.5 mm	59.5 mm	49.0 mm	T 50/B	ENEC10 UL VDE cCSA
197	Manufacturers Part No. 44381 (MT1012-2) Myrra Print transformer 443_ EI66 30VA 230V 2x12V 2x1.250mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	78 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock)	(at least 1 or mul. of 1)	443_	Myrra	Print transformer	EI66	30.0 VA	230 V	2 x 12 V	2	2 x 1.250 mA	70.5 mm	59.5 mm	49.0 mm	T 50/B	ENEC10 UL VDE cCSA
198	Manufacturers Part No. BVUI3930062 (BVUI3930062) Hahn Print transformer BVUI39 UI39 14VA 2x115V 2x18V 2x389mA not short circuit proof	Customer Part No. Customer Project No.	Hahn	0 Pcs. Planned Delivery Time Ø 3 Weeks Available on order	(at least 12 or mul. of 12)	BVUI39	Hahn	Print transformer	UI39	14.0 VA	2 x 115 V	2 x 18 V	2	2 x 389 mA	68.8 mm	57.9 mm	25.6 mm		CE ENEC10 VDE cCSA cULus
199	Manufacturers Part No. BVUI3930074 (BVUI3930074) Hahn Print transformer BVUI39 UI39 14VA 2x115V 2x9V 2x778mA not short circuit proof	Customer Part No. Customer Project No.	Hahn	23 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock)	(at least 1 or mul. of 1)	BVUI39	Hahn	Print transformer	UI39	14.0 VA	2 x 115 V	2 x 9 V	2	2 x 778 mA	68.8 mm	57.9 mm	25.6 mm		CE ENEC10 VDE cCSA cULus
200	Manufacturers Part No. BVUI3930081 (BVUI3930081) Hahn Print transformer BVUI39 UI39 14VA 2x115V 2x12V 2x583mA not short circuit proof	Customer Part No. Customer Project No.	Hahn	9 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock)	(at least 1 or mul. of 1)	BVUI39	Hahn	Print transformer	UI39	14.0 VA	2 x 115 V	2 x 12 V	2	2 x 583 mA	68.8 mm	57.9 mm	25.6 mm		CE ENEC10 VDE cCSA cULus

‹ 1 ··· 6 7 8 9 10 ··· 19 ›
