PCB Transformers

(455 Results)

Filter results

Show Selected	Part No.	Indiv. Part No.	Manufacturer	Availability	Quantity	Series	Manufacturer	Type	Core	Performance	Primary Voltage	Secondary Voltage	Number of outputs	Secondary Current	Dimension: Length	Dimension: Width	Dimension: Height	Temperature Resistance Class	Approvals
76	Manufacturers Part No. BVUI4810004 (BVUI4810004) Hahn Print transformer BVUI48 UI48 40VA 2x115V 2x15V 2x1.333mA not short circuit proof	Customer Part No. Customer Project No.	Hahn	0 Pcs. Planned Delivery Time Ø 3 Weeks Available on order	(at least 6 or mul. of 6)	BVUI48	Hahn	Print transformer	UI48	40.0 VA	2 x 115 V	2 x 15 V	2	2 x 1.333 mA	83.7 mm	71.3 mm	39.1 mm		CE ENEC10 VDE cCSA cULus
77	Manufacturers Part No. BVUI4820007 (BVUI4820007) Hahn Print transformer BVUI48 UI48 60VA 2x115V 2x6V 2x5.000mA not short circuit proof	Customer Part No. Customer Project No.	Hahn	0 Pcs. Planned Delivery Time Ø 3 Weeks Available on order	(at least 1 or mul. of 1)	BVUI48	Hahn	Print transformer	UI48	60.0 VA	2 x 115 V	2 x 6 V	2	2 x 5.000 mA	83.7 mm	71.3 mm	48.1 mm		CE ENEC10 VDE cCSA cULus
78	Manufacturers Part No. BVUI4820008 (BVUI4820008) Hahn Print transformer BVUI48 UI48 60VA 2x115V 2x9V 2x3.333mA not short circuit proof	Customer Part No. Customer Project No.	Hahn	0 Pcs. Planned Delivery Time Ø 3 Weeks Available on order	(at least 6 or mul. of 6)	BVUI48	Hahn	Print transformer	UI48	60.0 VA	2 x 115 V	2 x 9 V	2	2 x 3.333 mA	83.7 mm	71.3 mm	48.1 mm		CE ENEC10 VDE cCSA cULus
79	Manufacturers Part No. BVUI4820009 (BVUI4820009) Hahn Print transformer BVUI48 UI48 60VA 2x115V 2x12V 2x2.500mA not short circuit proof	Customer Part No. Customer Project No.	Hahn	36 Pcs. Next Stock Receipt Week 17/2026 (30 Pcs.) Available (from stock)	(at least 1 or mul. of 1)	BVUI48	Hahn	Print transformer	UI48	60.0 VA	2 x 115 V	2 x 12 V	2	2 x 2.500 mA	83.7 mm	71.3 mm	48.1 mm		CE ENEC10 VDE cCSA cULus
80	Manufacturers Part No. BVUI4820010 (BVUI4820010) Hahn Print transformer BVUI48 UI48 60VA 2x115V 2x15V 2x2.000mA not short circuit proof	Customer Part No. Customer Project No.	Hahn	7 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock)	(at least 1 or mul. of 1)	BVUI48	Hahn	Print transformer	UI48	60.0 VA	2 x 115 V	2 x 15 V	2	2 x 2.000 mA	83.7 mm	71.3 mm	48.1 mm		CE ENEC10 VDE cCSA cULus
81	Manufacturers Part No. BVEI3042047 (BVEI3042047) Hahn Print transformer BVEI304 EI30 2,6VA 230V 2x12V 2x108mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	41 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock)	(at least 5 or mul. of 5)	BVEI304	Hahn	Print transformer	EI30	2.6 VA	230 V	2 x 12 V	2	2 x 108 mA	33.2 mm	28.2 mm	27.4 mm	Ta 40/F	ENEC10 UL VDE cCSA
82	Manufacturers Part No. BVEI3042042 (BVEI3042042) Hahn Print transformer BVEI304 EI30 2,6VA 230V 12V 217mA absolutely short circuit proof TOP	Customer Part No. Customer Project No.	Hahn	145 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock)	(at least 5 or mul. of 5)	BVEI304	Hahn	Print transformer	EI30	2.6 VA	230 V	12 V	1	217 mA	33.2 mm	28.2 mm	27.4 mm	Ta 40/F	ENEC10 UL VDE cCSA
83	Manufacturers Part No. BVEI3042046 (BVEI3042046) Hahn Print transformer BVEI304 EI30 2,6VA 230V 2x9V 2x145mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	75 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock)	(at least 5 or mul. of 5)	BVEI304	Hahn	Print transformer	EI30	2.6 VA	230 V	2 x 9 V	2	2 x 145 mA	33.2 mm	28.2 mm	27.4 mm	Ta 40/F	ENEC10 UL VDE cCSA
84	Manufacturers Part No. BVEI3042048 (BVEI3042048) Hahn Print transformer BVEI304 EI30 2,6VA 230V 2x15V 2x87mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	25 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock)	(at least 5 or mul. of 5)	BVEI304	Hahn	Print transformer	EI30	2.6 VA	230 V	2 x 15 V	2	2 x 87 mA	33.2 mm	28.2 mm	27.4 mm	Ta 40/F	ENEC10 UL VDE cCSA
85	Manufacturers Part No. BVEI3042089 (BVEI3042089) Hahn Print transformer BVEI304 EI30 2,1VA 230V 2x18V 2x58mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	0 Pcs. Planned Delivery Time Ø 3 Weeks Available on order	(at least 50 or mul. of 50)	BVEI304	Hahn	Print transformer	EI30	2.1 VA	230 V	2 x 18 V	2	2 x 58 mA	33.2 mm	28.2 mm	27.4 mm	Ta 40/F	ENEC10 UL VDE cCSA
86	Manufacturers Part No. BVEI3048006 (BVEI3048006) Hahn Print transformer BVEI304 EI30 2,1VA 230V 2x12V 2x88mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	0 Pcs. Planned Delivery Time Ø 3 Weeks Available on order	(at least 50 or mul. of 50)	BVEI304	Hahn	Print transformer	EI30	2.1 VA	230 V	2 x 12 V	2	2 x 88 mA	33.2 mm	28.2 mm	27.4 mm	Ta 70/F	ENEC10 UL VDE cCSA
87	Manufacturers Part No. BVEI3048013 (BVEI3048013) Hahn Print transformer BVEI304 EI30 2,1VA 230V 6V 350mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	0 Pcs. Planned Delivery Time Ø 3 Weeks Available on order	(at least 50 or mul. of 50)	BVEI304	Hahn	Print transformer	EI30	2.1 VA	230 V	6 V	1	350 mA	33.2 mm	28.2 mm	27.4 mm	Ta 70/F	ENEC10 UL VDE cCSA
88	Manufacturers Part No. BVEI3048024 (BVEI3048024) Hahn Print transformer BVEI304 EI30 2,1VA 230V 7,5V 280mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	0 Pcs. Planned Delivery Time Ø 3 Weeks Available on order	(at least 50 or mul. of 50)	BVEI304	Hahn	Print transformer	EI30	2.1 VA	230 V	7,5 V	1	280 mA	33.2 mm	28.2 mm	27.4 mm	Ta 70/F	ENEC10 UL VDE cCSA
89	Manufacturers Part No. BVEI3012911 (BVEI3012911) Hahn Print transformer BVEI301 EI30 0,5VA 230V 9V 56mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	40 Pcs. Planned Delivery Time Ø 4 Weeks Available (from stock)	(at least 5 or mul. of 5)	BVEI301	Hahn	Print transformer	EI30	0.5 VA	230 V	9 V	1	56 mA	33.2 mm	28.2 mm	15.2 mm	Ta 70/F	ENEC10 UL VDE 0570 cCSA
90	Manufacturers Part No. BVEI3013005 (BVEI3013005) Hahn Print transformer BVEI301 EI30 0,5VA 230V 6V 83mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	290 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock)	(at least 5 or mul. of 5)	BVEI301	Hahn	Print transformer	EI30	0.5 VA	230 V	6 V	1	83 mA	33.2 mm	28.2 mm	15.2 mm	Ta 70/F	ENEC10 UL VDE 0570 cCSA
91	Manufacturers Part No. BVEI3032034 (BVEI3032034) Hahn Print transformer BVEI303 EI30 1,9VA 230V 18V 105mA absolutely short circuit proof TOP	Customer Part No. Customer Project No.	Hahn	1.140 Pcs. Planned Delivery Time Ø 6 Weeks Available (from stock)	(at least 5 or mul. of 5)	BVEI303	Hahn	Print transformer	EI30	1.9 VA	230 V	18 V	1	105 mA	33.2 mm	28.2 mm	24.3 mm	Ta 70/F	ENEC10 UL VDE cCSA
92	Manufacturers Part No. BVEI3032036 (BVEI3032036) Hahn Print transformer BVEI303 EI30 1,9VA 230V 2x9V 2x105mA absolutely short circuit proof TOP	Customer Part No. Customer Project No.	Hahn	1.345 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock)	(at least 5 or mul. of 5)	BVEI303	Hahn	Print transformer	EI30	1.9 VA	230 V	2 x 9 V	2	2 x 105 mA	33.2 mm	28.2 mm	24.3 mm	Ta 70/F	ENEC10 UL VDE cCSA
93	Manufacturers Part No. BVEI3032095 (BVEI3032095) Hahn Print transformer BVEI303 EI30 1,9VA 230V 2x7,5V 2x126mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	0 Pcs. Planned Delivery Time Ø 3 Weeks Available on order	(at least 50 or mul. of 50)	BVEI303	Hahn	Print transformer	EI30	1.9 VA	230 V	2 x 7,5 V	2	2 x 126 mA	33.2 mm	28.2 mm	24.3 mm	Ta 70/F	ENEC10 UL VDE cCSA
94	Manufacturers Part No. BVEI3032897 (BVEI3032897) Hahn Print transformer BVEI303 EI30 1,9VA 115V 12V 158mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	0 Pcs. Planned Delivery Time Ø 3 Weeks Available on order	(at least 50 or mul. of 50)	BVEI303	Hahn	Print transformer	EI30	1.9 VA	115 V	12 V	1	158 mA	33.2 mm	28.2 mm	24.3 mm	Ta 70/F	ENEC10 UL VDE cCSA
95	Manufacturers Part No. BVEI3032038 (BVEI3032038) Hahn Print transformer BVEI303 EI30 1,9VA 230V 2x15V 2x63mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	165 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock)	(at least 5 or mul. of 5)	BVEI303	Hahn	Print transformer	EI30	1.9 VA	230 V	2 x 15 V	2	2 x 63 mA	33.2 mm	28.2 mm	24.3 mm	Ta 70/F	ENEC10 UL VDE cCSA
96	Manufacturers Part No. BVEI3032839 (BVEI3032839) Hahn Print transformer BVEI303 EI30 1,5VA 230V 9V 167mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	0 Pcs. Planned Delivery Time Ø 3 Weeks Available on order	(at least 50 or mul. of 50)	BVEI303	Hahn	Print transformer	EI30	1.5 VA	230 V	9 V	1	167 mA	33.2 mm	28.2 mm	24.3 mm	Ta 70/F	ENEC10 UL VDE cCSA
97	Manufacturers Part No. BVEI3038021 (BVEI3038021) Hahn Print transformer BVEI303 EI30 1,5VA 230V 2x9V 2x83mA absolutely short circuit proof	Customer Part No. Customer Project No.	Hahn	0 Pcs. Planned Delivery Time Ø 3 Weeks Available on order	(at least 50 or mul. of 50)	BVEI303	Hahn	Print transformer	EI30	1.5 VA	230 V	2 x 9 V	2	2 x 83 mA	33.2 mm	28.2 mm	24.3 mm	Ta 70/F	ENEC10 UL VDE cCSA
98	Manufacturers Part No. 45073 (MT45073) Myrra Print transformer MT450 UI48 60VA 2x115V 2x6V 2x5000mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	0 Pcs. Planned Delivery Time Ø 17 Weeks Available on order	(at least 54 or mul. of 54)	MT450	Myrra	Print transformer	UI48	60.0 VA	2 x 115 V	2 x 6 V	2	2 x 5000 mA	85.8 mm	69.8 mm	48.3 mm		CE UL 506 cCSA
99	Manufacturers Part No. 45074 (MT45074) Myrra Print transformer MT450 UI48 60VA 2x115V 2x9V 2x3333mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	0 Pcs. Planned Delivery Time Ø 17 Weeks Available on order	(at least 54 or mul. of 54)	MT450	Myrra	Print transformer	UI48	60.0 VA	2 x 115 V	2 x 9 V	2	2 x 3333 mA	85.8 mm	69.8 mm	48.3 mm		CE UL 506 cCSA
100	Manufacturers Part No. 45075 (MT45075) Myrra Print transformer MT450 UI48 60VA 2x115V 2x12V 2x2500mA not short circuit proof	Customer Part No. Customer Project No.	Myrra	0 Pcs. Planned Delivery Time Ø 17 Weeks Available on order	(at least 54 or mul. of 54)	MT450	Myrra	Print transformer	UI48	60.0 VA	2 x 115 V	2 x 12 V	2	2 x 2500 mA	85.8 mm	69.8 mm	48.3 mm		CE UL 506 cCSA
