Results (583)
Not discontinued
In stock
RoHS compliant
Datasheet
New
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Package/Case | Frequency | Frequency tolerance | Load capacity | Ageing, max. | Load, max. | Operating Temperature Min. | Operating Temperature Max. | Dimension: Length | Dimension: Width | Dimension: Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
201 | Manufacturers Part No. X32-24.576-12-30/30/-40+85(X32-24.576-12-334) MEC Mercury SMD Crystal X32 Metal housing 24,576MHz ±30ppm 3,2mm x 2,5mm x 0,7mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 24.576 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.7 mm | |||||||
202 | Manufacturers Part No. MJ-12.000-12-30/30/-40+85(MJ-12.000-12-334) MEC Mercury SMD Crystal MJ Metal housing 12MHz ±30ppm 5mm x 3,2mm x 0,9mm | Customer Part No. Customer Project No. | 820 Pcs. Planned Delivery Time Ø 10 Weeks | (at least 10 or mul. of 10) | MEC Mercury | SMD Crystal | Metal housing | 12.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 5.0 mm | 3.2 mm | 0.9 mm | |||||||
203 | Manufacturers Part No. X32-32.000-12-30/30/-40+85(X32-32.000-12-334) MEC Mercury SMD Crystal X32 Metal housing 32MHz ±30ppm 3,2mm x 2,5mm x 0,7mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 32.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.7 mm | |||||||
204 | Manufacturers Part No. X32-40.000-12-30/30/-40+85(X32-40.000-12-334) MEC Mercury SMD Crystal X32 Metal housing 40MHz ±30ppm 3,2mm x 2,5mm x 0,7mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 40.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.7 mm | |||||||
205 | Manufacturers Part No. CM7V-T1A 32.768-7-20-TCQA(CM7V-32-7-2-TCQA) Micro Crystal SMD Tuning Fork Quartz Crystal CM7V-T1A Ceramic case 0,032768MHz ±20ppm 1,5mm x 3,2mm x 0,65mm 7pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks | (at least 3000 or mul. of 3000) | Micro Crystal | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 7.0 pF | ±3 ppm/Jahr | 1 µW | -55.0 °C | 125.0 °C | 1.5 mm | 3.2 mm | 0.65 mm | ||||||
206 | Manufacturers Part No. 49S4H3.579545M-AF-3030150R-16R(QMIM003.579) Abundance Miniature Crystal HC49/U-S Metal housing 3,579545MHz ±50ppm 3,8mm x 11,05mm x 3,5mm 16pF | Customer Part No. Customer Project No. | 3.580 Pcs. Planned Delivery Time Ø 30 Weeks | (at least 10 or mul. of 10) | Abundance | Miniature Crystal | Metal housing | 3.579545 MHz | ±50 ppm | 16.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 3.8 mm | 11.05 mm | 3.5 mm | ||||||
207 | Manufacturers Part No. CM9V-T1A 32.768-12.5-20-TAQC(CM9V-32-12.5-2TAQC) Micro Crystal SMD Tuning Fork Quartz Crystal CM9V-T1A Ceramic case 0,032768MHz ±20ppm 1,6mm x 1mm x 0,5mm 12,5pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 6 Weeks | (at least 100 or mul. of 100) | Micro Crystal | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 12.5 pF | ±3 ppm/Jahr | 0,5 µW | -40.0 °C | 85.0 °C | 1.6 mm | 1.0 mm | 0.5 mm | ||||||
208 | Manufacturers Part No. QTC232.76807B2M(QTC232.76807B2R) QANTEK SMD Tuning Fork Quartz Crystal QTC2 Ceramic case 0,032768MHz ±20ppm 1,2mm x 2mm x 0,6mm 7pF | Customer Part No. Customer Project No. | 650 Pcs. Planned Delivery Time Ø 6 Weeks | (at least 10 or mul. of 10) | QANTEK | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 7.0 pF | ±3 ppm/Jahr | 1,5 µW | -40.0 °C | 85.0 °C | 1.2 mm | 2.0 mm | 0.6 mm | ||||||
209 | Manufacturers Part No. CM8V-T1A 32.768-9-20-TAQC(CM8V-32-9-2-TAQC) Micro Crystal SMD Tuning Fork Quartz Crystal CM8V-T1A Ceramic case 0,032768MHz ±20ppm 2mm x 1,2mm x 0,6mm 9pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 6 Weeks | (at least 100 or mul. of 100) | Micro Crystal | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 9.0 pF | ±3 ppm/Jahr | 0,5 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.2 mm | 0.6 mm | ||||||
210 | Manufacturers Part No. IC25006.144M16.0EE1C(IC25TH6.144) Red Frequency Crystal, wired IC 25 Metal housing 6,144MHz 30ppm 11mm x 4,6mm x 13,5mm 16pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 1000 or mul. of 1000) | Red Frequency | Crystal, wired | Metal housing | 6.144 MHz | 30 ppm | 16.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 11.0 mm | 4.6 mm | 13.5 mm | ||||||
211 | Manufacturers Part No. X1A000061000612(X1A0000610006) Epson SMD Clock Crystal FC-12M Plastic housing 0,032768MHz 20ppm 2,05mm x 1,2mm x 0,6mm 7pF | Customer Part No. Customer Project No. | 250 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Epson | SMD Clock Crystal | Plastic housing | 0.032768 MHz | 20 ppm | 7.0 pF | ±3 ppm/Jahr | 0,5 µW | -40.0 °C | 85.0 °C | 2.05 mm | 1.2 mm | 0.6 mm | ||||||
212 | Manufacturers Part No. X1E000021013012(X1E0000210130) Epson SMD Crystal TSX-3225 Plastic housing 24MHz 10ppm 3,2mm x 2,5mm x 0,6mm 16pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 5 or mul. of 5) | Epson | SMD Crystal | Plastic housing | 24.0 MHz | 10 ppm | 16.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.6 mm | ||||||
213 | Manufacturers Part No. Q22FA2380000114(FA238-20) Epson SMD Crystal FA-238 Plastic housing 20MHz 50ppm 3,2mm x 2,5mm x 0,7mm 12pF | Customer Part No. Customer Project No. | 830 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Epson | SMD Crystal | Plastic housing | 20.0 MHz | 50 ppm | 12.0 pF | 5 ppm/Jahr | 200 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.7 mm | ||||||
214 | Manufacturers Part No. 49U-27.000M-3RD-30/30-50R-32P(QM027) Abundance Crystal HC-49/U Metal housing 27MHz ±30ppm x 11,05mm x 13,6mm 32pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 7 Weeks | (at least 1000 or mul. of 1000) | Abundance | Crystal | Metal housing | 27.0 MHz | ±30 ppm | 32.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
215 | Manufacturers Part No. HC49U36.0M-3RD/OT-30/30-50RSER(QM036) Abundance Crystal HC-49/U Metal housing 36MHz ±30ppm x 11,05mm x 13,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 7 Weeks | (at least 1000 or mul. of 1000) | Abundance | Crystal | Metal housing | 36.0 MHz | ±30 ppm | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | ||||||||
216 | Manufacturers Part No. Q22FA23V0008614(FA238V-14.7456) Epson SMD Crystal FA-238V Plastic housing 14,7456MHz 50ppm 3,2mm x 2,5mm x 0,7mm 12pF | Customer Part No. Customer Project No. | 1.360 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Epson | SMD Crystal | Plastic housing | 14.7456 MHz | 50 ppm | 12.0 pF | 5 ppm/Jahr | 200 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.7 mm | ||||||
217 | Manufacturers Part No. IC15030.000M20.0CE1B(IC15M30.0) Red Frequency SMD Crystal IC 15 Ceramic case 30MHz 20ppm 5,2mm x 3,4mm x 1,1mm 20pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 500 or mul. of 500) | Red Frequency | SMD Crystal | Ceramic case | 30.0 MHz | 20 ppm | 20.0 pF | ±2 ppm/Jahr | -20.0 °C | 70.0 °C | 5.2 mm | 3.4 mm | 1.1 mm | |||||||
218 | Manufacturers Part No. IC18009.851M20.0CE1B(IC18SMD9.851) Red Frequency SMD Crystal IC 18 Ceramic case 9,851MHz ±30ppm 7,2mm x 5,2mm x 1,2mm 20pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 500 or mul. of 500) | Red Frequency | SMD Crystal | Ceramic case | 9.851 MHz | ±30 ppm | 20.0 pF | ±3 ppm/Jahr | -20.0 °C | 70.0 °C | 7.2 mm | 5.2 mm | 1.2 mm | |||||||
219 | Manufacturers Part No. IC15008.000M12.0EF1B(IC15M8) Red Frequency SMD Crystal IC 15 Ceramic case 8MHz 30ppm 5,2mm x 3,4mm x 1,1mm 12pF | Customer Part No. Customer Project No. | 3.380 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 5 or mul. of 5) | Red Frequency | SMD Crystal | Ceramic case | 8.0 MHz | 30 ppm | 12.0 pF | ±2 ppm/Jahr | -20.0 °C | 70.0 °C | 5.2 mm | 3.4 mm | 1.1 mm | |||||||
220 | Manufacturers Part No. IC16010.000M20.0CE1B(IC16SMD10.0) Red Frequency SMD Crystal IC 16 Ceramic case 10MHz ±30ppm 6,2mm x 3,7mm x 1,2mm 20pF | Customer Part No. Customer Project No. | 770 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 5 or mul. of 5) | Red Frequency | SMD Crystal | Ceramic case | 10.0 MHz | ±30 ppm | 20.0 pF | ±2 ppm/Jahr | -20.0 °C | 70.0 °C | 6.2 mm | 3.7 mm | 1.2 mm | |||||||
221 | Manufacturers Part No. IC22010.000M20.0CE1B(IC22SMD10.0) Red Frequency SMD Crystal IC 22 Metal housing 10MHz ±20ppm 11,4mm x 4,6mm x 3,3mm 20pF | Customer Part No. Customer Project No. | 790 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 10 or mul. of 10) | Red Frequency | SMD Crystal | Metal housing | 10.0 MHz | ±20 ppm | 20.0 pF | ±3 ppm/Jahr | -10.0 °C | 70.0 °C | 11.4 mm | 4.6 mm | 3.3 mm | |||||||
222 | Manufacturers Part No. IC22016.000M30.0CE1B(IC22SMD16.0) Red Frequency SMD Crystal IC 22 Metal housing 16MHz ±20ppm 11,4mm x 4,6mm x 3,3mm 30pF | Customer Part No. Customer Project No. | 970 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 10 or mul. of 10) | Red Frequency | SMD Crystal | Metal housing | 16.0 MHz | ±20 ppm | 30.0 pF | ±3 ppm/Jahr | -10.0 °C | 70.0 °C | 11.4 mm | 4.6 mm | 3.3 mm | |||||||
223 | Manufacturers Part No. M49-4.9152-18-30/50/-40+85(M49-4.9152-18-354) MEC Mercury SMD Crystal M49 Metal housing 4,9152MHz ±30ppm 12,4mm x 4,5mm x 4mm 18pF | Customer Part No. Customer Project No. | 990 Pcs. Planned Delivery Time Ø 10 Weeks | (at least 10 or mul. of 10) | MEC Mercury | SMD Crystal | Metal housing | 4.9152 MHz | ±30 ppm | 18.0 pF | ±3 ppm/Jahr | 500 µW | -40.0 °C | 85.0 °C | 12.4 mm | 4.5 mm | 4.0 mm | ||||||
224 | Manufacturers Part No. M49-9.8304-18-30/50/-40+85(M49-9.8304-18-354) MEC Mercury SMD Crystal M49 Metal housing 9,8304MHz ±30ppm 12,4mm x 4,5mm x 4mm 18pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 9.8304 MHz | ±30 ppm | 18.0 pF | ±3 ppm/Jahr | 500 µW | -40.0 °C | 85.0 °C | 12.4 mm | 4.5 mm | 4.0 mm | ||||||
225 | Manufacturers Part No. M49-16.000-18-30/50/-40+85(M49-16.000-18-354) MEC Mercury SMD Crystal M49 Metal housing 16MHz ±30ppm 12,4mm x 4,5mm x 4mm 18pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 16.0 MHz | ±30 ppm | 18.0 pF | ±3 ppm/Jahr | 500 µW | -40.0 °C | 85.0 °C | 12.4 mm | 4.5 mm | 4.0 mm |
