Filter articles
Manufacturer
Manufacturer
Series
Series
Type
Type
Package/Case
Package/Case
Frequency
Frequency
Frequency tolerance
Frequency tolerance
Load capacity
Load capacity
Ageing, max.
Ageing, max.
Load, max.
Load, max.
Operating Temperature Min.
Operating Temperature Min.
Operating Temperature Max.
Operating Temperature Max.
Dimension: Length
Dimension: Length
Dimension: Width
Dimension: Width
Dimension: Height
Dimension: Height
Results (583)
Not discontinued
In stock
RoHS compliant
Datasheet
New
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Package/Case | Frequency | Frequency tolerance | Load capacity | Ageing, max. | Load, max. | Operating Temperature Min. | Operating Temperature Max. | Dimension: Length | Dimension: Width | Dimension: Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
51 | Manufacturers Part No. 49U-3.6864M-AF-30/30-100R-16P(QM003.686) Abundance Crystal HC-49/U Metal housing 3,6864MHz ±30ppm x 11,05mm x 13,6mm 16pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 7 Weeks | (at least 1000 or mul. of 1000) | Abundance | Crystal | Metal housing | 3.6864 MHz | ±30 ppm | 16.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
52 | Manufacturers Part No. HC49U-4.0000M-AF-30/30-90R-30P(QM004) Abundance Crystal HC-49/U Metal housing 4MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 6.630 Pcs. Planned Delivery Time Ø 29 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 4.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
53 | Manufacturers Part No. 49U-4.194304M-AF-30/30-90R-32P(QM004.194) Abundance Crystal HC-49/U Metal housing 4,194304MHz ±30ppm x 11,05mm x 13,6mm 32pF | Customer Part No. Customer Project No. | 4.160 Pcs. Planned Delivery Time Ø 15 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 4.194304 MHz | ±30 ppm | 32.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
54 | Manufacturers Part No. 49U-4.915200M-AF-30/30-90R-16P(QM004.915) Abundance Crystal HC-49/U Metal housing 4,9152MHz ±30ppm x 11,05mm x 13,6mm 16pF | Customer Part No. Customer Project No. | 4.090 Pcs. Planned Delivery Time Ø 17 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 4.9152 MHz | ±30 ppm | 16.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
55 | Manufacturers Part No. HC49U-6.0000M-AF-30/30-60R-30P(QM006) Abundance Crystal HC-49/U Metal housing 6MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 4.440 Pcs. Planned Delivery Time Ø 17 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 6.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
56 | Manufacturers Part No. HC49U-6.1440M-AF-30/30-60R-16P(QM006.144) Abundance Crystal HC-49/U Metal housing 6,144MHz ±30ppm x 11,05mm x 13,6mm 16pF | Customer Part No. Customer Project No. | 4.860 Pcs. Planned Delivery Time Ø 24 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 6.144 MHz | ±30 ppm | 16.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
57 | Manufacturers Part No. HC49U-7.3728M-AF-30/30-60R-32P(QM007.372) Abundance Crystal HC-49/U Metal housing 7,3728MHz ±30ppm x 11,05mm x 13,6mm 32pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 7 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 7.3728 MHz | ±30 ppm | 32.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
58 | Manufacturers Part No. HC49U-8.000M-AF-30/30-50R-30P(QM008) Abundance Crystal HC-49/U Metal housing 8MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 7.260 Pcs. Planned Delivery Time Ø 21 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 8.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
59 | Manufacturers Part No. HC49U-9.8304M-AF-30/30-45R-30P(QM009.830) Abundance Crystal HC-49/U Metal housing 9,8304MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 7 Weeks | (at least 1000 or mul. of 1000) | Abundance | Crystal | Metal housing | 9.8304 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
60 | Manufacturers Part No. 49U-10.0000M-AF-30/30-40R-30P(QM010) Abundance Crystal HC-49/U Metal housing 10MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 3.490 Pcs. Planned Delivery Time Ø 29 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 10.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
61 | Manufacturers Part No. 49U-11.0592M-AF-30/30-40R-30P(QM011.0592) Abundance Crystal HC-49/U Metal housing 11,0592MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 5.100 Pcs. Planned Delivery Time Ø 13 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 11.0592 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
62 | Manufacturers Part No. 49U-12.0000M-AF-30/30-35R-30P(QM012) Abundance Crystal HC-49/U Metal housing 12MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 6.730 Pcs. Planned Delivery Time Ø 29 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 12.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
63 | Manufacturers Part No. 49U-14.31818M-AF-30/30-35R-30P(QM014.318) Abundance Crystal HC-49/U Metal housing 14,31818MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 1.000 Pcs. Planned Delivery Time Ø 7 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 14.31818 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
64 | Manufacturers Part No. 49U-16.0000M-AF-30/30-30R-30P(QM016) Abundance Crystal HC-49/U Metal housing 16MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 1.530 Pcs. | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 16.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
65 | Manufacturers Part No. 49U-18.0000M-AF-30/30-25R-30P(QM018) Abundance Crystal HC-49/U Metal housing 18MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 380 Pcs. Planned Delivery Time Ø 12 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 18.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
66 | Manufacturers Part No. 49U-18.4320M-AF-30/30-25R-30P(QM018.432) Abundance Crystal HC-49/U Metal housing 18,432MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 830 Pcs. Planned Delivery Time Ø 7 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 18.432 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
67 | Manufacturers Part No. HC49U-24.000M-AF-30/30-25R-30P(QM024-FUND) Abundance Crystal HC-49/U Metal housing 24MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 4.400 Pcs. Planned Delivery Time Ø 7 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 24.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
68 | Manufacturers Part No. ZM206E32.768K-20-12.5P(ZM206E32.768K) Abundance SMD Clock Crystal ZM Plastic housing 0,032768MHz ±20ppm 8mm x 3,8mm x 2,5mm 12,5pF | Customer Part No. Customer Project No. | 14.100 Pcs. Planned Delivery Time Ø 17 Weeks | (at least 25 or mul. of 25) | Abundance | SMD Clock Crystal | Plastic housing | 0.032768 MHz | ±20 ppm | 12.5 pF | ±3 ppm/Jahr | 1 µW | -40.0 °C | 85.0 °C | 8.0 mm | 3.8 mm | 2.5 mm | ||||||
69 | Manufacturers Part No. ZM315-32.768K-20-12.5P(ZM31532.768) Abundance SMD Clock Crystal ZM Metal housing 0,032768MHz ±20ppm 3,2mm x 1,5mm x 0,9mm 12,5pF | Customer Part No. Customer Project No. | 2.850 Pcs. | (at least 25 or mul. of 25) | Abundance | SMD Clock Crystal | Metal housing | 0.032768 MHz | ±20 ppm | 12.5 pF | ±5 ppm/Jahr | 1 µW | -40.0 °C | 85.0 °C | 3.2 mm | 1.5 mm | 0.9 mm | ||||||
70 | Manufacturers Part No. ZMR206BE-32.768K-20-12.5P(ZMR206BE32.768) Abundance SMD Clock Crystal ZM Metal housing 0,032768MHz ±20ppm 6,1mm x 2mm x 12,5pF | Customer Part No. Customer Project No. | 3.725 Pcs. Planned Delivery Time Ø 17 Weeks | (at least 25 or mul. of 25) | Abundance | SMD Clock Crystal | Metal housing | 0.032768 MHz | ±20 ppm | 12.5 pF | ±3 ppm/Jahr | 1 µW | -40.0 °C | 85.0 °C | 6.1 mm | 2.0 mm | |||||||
71 | Manufacturers Part No. CM7V-T1A 32.768-7-20-TAQC(CM7V-32-7-2TAQC) Micro Crystal SMD Tuning Fork Quartz Crystal CM7V-T1A Ceramic case 0,032768MHz ±20ppm 1,5mm x 3,2mm x 0,65mm 7pF | Customer Part No. Customer Project No. | 2.970 Pcs. Planned Delivery Time Ø 12 Weeks | (at least 10 or mul. of 10) | Micro Crystal | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 7.0 pF | ±3 ppm/Jahr | 1 µW | -40.0 °C | 85.0 °C | 1.5 mm | 3.2 mm | 0.65 mm | ||||||
72 | Manufacturers Part No. IC23006.144M16.0EE1C(IC23TH6.144) Red Frequency Crystal, wired IC23 Metal housing 6,144MHz ±30ppm 10,7mm x 4,3mm x 3,5mm 16pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 10 or mul. of 10) | Red Frequency | Crystal, wired | Metal housing | 6.144 MHz | ±30 ppm | 16.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 10.7 mm | 4.3 mm | 3.5 mm | ||||||
73 | Manufacturers Part No. IC23012.000M30.0EE1C(IC23TH12.0) Red Frequency Crystal, wired IC 23 Metal housing 12MHz ±30ppm 10,7mm x 4,3mm x 3,5mm 30pF | Customer Part No. Customer Project No. | 1.190 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 10 or mul. of 10) | Red Frequency | Crystal, wired | Metal housing | 12.0 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 10.7 mm | 4.3 mm | 3.5 mm | ||||||
74 | Manufacturers Part No. IC23025.000M16.0EE1C(IC23TH25.0) Red Frequency Crystal, wired IC 23 Metal housing 25MHz ±30ppm 10,7mm x 4,3mm x 3,5mm 16pF | Customer Part No. Customer Project No. | 600 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 10 or mul. of 10) | Red Frequency | Crystal, wired | Metal housing | 25.0 MHz | ±30 ppm | 16.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 10.7 mm | 4.3 mm | 3.5 mm | ||||||
75 | Manufacturers Part No. IC23004.096M30.0EE1C(IC23TH4.096) Red Frequency Crystal, wired IC 23 Metal housing 4,096MHz ±30ppm 10,7mm x 4,3mm x 3,5mm 30pF | Customer Part No. Customer Project No. | 1.450 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 10 or mul. of 10) | Red Frequency | Crystal, wired | Metal housing | 4.096 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 10.7 mm | 4.3 mm | 3.5 mm |
