Results (583)
Not discontinued
In stock
RoHS compliant
Datasheet
New
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Package/Case | Frequency | Frequency tolerance | Load capacity | Ageing, max. | Load, max. | Operating Temperature Min. | Operating Temperature Max. | Dimension: Length | Dimension: Width | Dimension: Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
401 | Manufacturers Part No. MQ-24.576-12-30/30/-40+85(MQ-24.576-12-334) MEC Mercury SMD Crystal MQ Metal housing 24,576MHz ±30ppm 7mm x 5mm x 1mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks | (at least 10 or mul. of 10) | MEC Mercury | SMD Crystal | Metal housing | 24.576 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 7.0 mm | 5.0 mm | 1.0 mm | |||||||
402 | Manufacturers Part No. MQ-25.000-12-30/30/-40+85(MQ-25.000-12-334) MEC Mercury SMD Crystal MQ Metal housing 25MHz ±30ppm 7mm x 5mm x 1mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks | (at least 10 or mul. of 10) | MEC Mercury | SMD Crystal | Metal housing | 25.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 7.0 mm | 5.0 mm | 1.0 mm | |||||||
403 | Manufacturers Part No. MQ-6.000-12-30/30/-40+85(MQ-6.000-12-334) MEC Mercury SMD Crystal MQ Metal housing 6MHz ±30ppm 7mm x 5mm x 1mm | Customer Part No. Customer Project No. | 710 Pcs. Planned Delivery Time Ø 12 Weeks | (at least 10 or mul. of 10) | MEC Mercury | SMD Crystal | Metal housing | 6.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 7.0 mm | 5.0 mm | 1.0 mm | |||||||
404 | Manufacturers Part No. MQ-8.000-12-30/30/-40+85(MQ-8.000-12-334) MEC Mercury SMD Crystal MQ Metal housing 8MHz ±30ppm 7mm x 5mm x 1mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks | (at least 1000 or mul. of 1000) | MEC Mercury | SMD Crystal | Metal housing | 8.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 7.0 mm | 5.0 mm | 1.0 mm | |||||||
405 | Manufacturers Part No. X1A000141000112(X1A0001410001) Epson SMD Clock Crystal FC-135R Plastic housing 0,032768MHz 20ppm 3,2mm x 1,5mm x 0,8mm 7pF | Customer Part No. Customer Project No. | 290 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Epson | SMD Clock Crystal | Plastic housing | 0.032768 MHz | 20 ppm | 7.0 pF | ±3 ppm/Jahr | 0,5 µW | -40.0 °C | 85.0 °C | 3.2 mm | 1.5 mm | 0.8 mm | ||||||
406 | Manufacturers Part No. CM7V-T1A 32.768-7-20-TCQA(CM7V-32-7-2-TCQA) Micro Crystal SMD Tuning Fork Quartz Crystal CM7V-T1A Ceramic case 0,032768MHz ±20ppm 1,5mm x 3,2mm x 0,65mm 7pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks | (at least 3000 or mul. of 3000) | Micro Crystal | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 7.0 pF | ±3 ppm/Jahr | 1 µW | -55.0 °C | 125.0 °C | 1.5 mm | 3.2 mm | 0.65 mm | ||||||
407 | Manufacturers Part No. CM9V-T1A 32.768-12.5-20-TAQC(CM9V-32-12.5-2TAQC) Micro Crystal SMD Tuning Fork Quartz Crystal CM9V-T1A Ceramic case 0,032768MHz ±20ppm 1,6mm x 1mm x 0,5mm 12,5pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 6 Weeks | (at least 100 or mul. of 100) | Micro Crystal | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 12.5 pF | ±3 ppm/Jahr | 0,5 µW | -40.0 °C | 85.0 °C | 1.6 mm | 1.0 mm | 0.5 mm | ||||||
408 | Manufacturers Part No. CM8V-T1A 32.768-7-20-TAQC(CM8V-32-7-2-TAQC) Micro Crystal SMD Tuning Fork Quartz Crystal CM8V-T1A Ceramic case 0,032768MHz ±20ppm 2mm x 1,2mm x 0,6mm 7pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 6 Weeks | (at least 10 or mul. of 10) | Micro Crystal | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 7.0 pF | ±3 ppm/Jahr | 0,5 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.2 mm | 0.6 mm | ||||||
409 | Manufacturers Part No. CM8V-T1A 32.768-12.5-20-TAQC(CM8V-32-12.5-2TAQC) Micro Crystal SMD Tuning Fork Quartz Crystal CM8V-T1A Ceramic case 0,032768MHz ±20ppm 2mm x 1,2mm x 0,6mm 12,5pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 6 Weeks | (at least 100 or mul. of 100) | Micro Crystal | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 12.5 pF | ±3 ppm/Jahr | 0,5 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.2 mm | 0.6 mm | ||||||
410 | Manufacturers Part No. QTC232.76807B2M(QTC232.76807B2R) QANTEK SMD Tuning Fork Quartz Crystal QTC2 Ceramic case 0,032768MHz ±20ppm 1,2mm x 2mm x 0,6mm 7pF | Customer Part No. Customer Project No. | 650 Pcs. Planned Delivery Time Ø 6 Weeks | (at least 10 or mul. of 10) | QANTEK | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 7.0 pF | ±3 ppm/Jahr | 1,5 µW | -40.0 °C | 85.0 °C | 1.2 mm | 2.0 mm | 0.6 mm | ||||||
411 | Manufacturers Part No. CM8V-T1A 32.768-9-20-TAQC(CM8V-32-9-2-TAQC) Micro Crystal SMD Tuning Fork Quartz Crystal CM8V-T1A Ceramic case 0,032768MHz ±20ppm 2mm x 1,2mm x 0,6mm 9pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 6 Weeks | (at least 100 or mul. of 100) | Micro Crystal | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 9.0 pF | ±3 ppm/Jahr | 0,5 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.2 mm | 0.6 mm | ||||||
412 | Manufacturers Part No. Q13MC1461000614(MC146-32.768-6PF) Epson SMD Clock Crystal MC-146 Plastic housing 0,032768MHz 20ppm 7mm x 1,5mm x 1,4mm 6pF | Customer Part No. Customer Project No. | 4.070 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Epson | SMD Clock Crystal | Plastic housing | 0.032768 MHz | 20 ppm | 6.0 pF | ±3 ppm/Jahr | 0,5 µW | -40.0 °C | 85.0 °C | 7.0 mm | 1.5 mm | 1.4 mm | ||||||
413 | Manufacturers Part No. 49U-2.0000M-AF-30/30-550R-30P(QM002) Abundance Crystal HC-49/U Metal housing 2MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 8.000 Pcs. Planned Delivery Time Ø 26 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 2.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
414 | Manufacturers Part No. 49U-3.6864M-AF-30/30-100R-16P(QM003.686) Abundance Crystal HC-49/U Metal housing 3,6864MHz ±30ppm x 11,05mm x 13,6mm 16pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 7 Weeks | (at least 1000 or mul. of 1000) | Abundance | Crystal | Metal housing | 3.6864 MHz | ±30 ppm | 16.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
415 | Manufacturers Part No. 49U-4.194304M-AF-30/30-90R-32P(QM004.194) Abundance Crystal HC-49/U Metal housing 4,194304MHz ±30ppm x 11,05mm x 13,6mm 32pF | Customer Part No. Customer Project No. | 4.160 Pcs. Planned Delivery Time Ø 15 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 4.194304 MHz | ±30 ppm | 32.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
416 | Manufacturers Part No. HC49U-6.1440M-AF-30/30-60R-16P(QM006.144) Abundance Crystal HC-49/U Metal housing 6,144MHz ±30ppm x 11,05mm x 13,6mm 16pF | Customer Part No. Customer Project No. | 4.860 Pcs. Planned Delivery Time Ø 24 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 6.144 MHz | ±30 ppm | 16.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
417 | Manufacturers Part No. HC49U-7.3728M-AF-30/30-60R-32P(QM007.372) Abundance Crystal HC-49/U Metal housing 7,3728MHz ±30ppm x 11,05mm x 13,6mm 32pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 7 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 7.3728 MHz | ±30 ppm | 32.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
418 | Manufacturers Part No. 49U-12.0000M-AF-30/30-35R-30P(QM012) Abundance Crystal HC-49/U Metal housing 12MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 6.730 Pcs. Planned Delivery Time Ø 29 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 12.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
419 | Manufacturers Part No. 49U-18.4320M-AF-30/30-25R-30P(QM018.432) Abundance Crystal HC-49/U Metal housing 18,432MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 830 Pcs. Planned Delivery Time Ø 7 Weeks | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 18.432 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
420 | Manufacturers Part No. ZMR206BE-32.768K-20-12.5P(ZMR206BE32.768) Abundance SMD Clock Crystal ZM Metal housing 0,032768MHz ±20ppm 6,1mm x 2mm x 12,5pF | Customer Part No. Customer Project No. | 3.725 Pcs. Planned Delivery Time Ø 17 Weeks | (at least 25 or mul. of 25) | Abundance | SMD Clock Crystal | Metal housing | 0.032768 MHz | ±20 ppm | 12.5 pF | ±3 ppm/Jahr | 1 µW | -40.0 °C | 85.0 °C | 6.1 mm | 2.0 mm | |||||||
421 | Manufacturers Part No. IC23025.000M16.0EE1C(IC23TH25.0) Red Frequency Crystal, wired IC 23 Metal housing 25MHz ±30ppm 10,7mm x 4,3mm x 3,5mm 16pF | Customer Part No. Customer Project No. | 600 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 10 or mul. of 10) | Red Frequency | Crystal, wired | Metal housing | 25.0 MHz | ±30 ppm | 16.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 10.7 mm | 4.3 mm | 3.5 mm | ||||||
422 | Manufacturers Part No. 49S4H4.915200M-AF-3030150R-16R(QMIM004.915) Abundance Miniature Crystal HC49/U-S Metal housing 4,9152MHz ±50ppm 3,8mm x 11,05mm x 3,5mm 16pF | Customer Part No. Customer Project No. | 1.630 Pcs. Planned Delivery Time Ø 29 Weeks | (at least 10 or mul. of 10) | Abundance | Miniature Crystal | Metal housing | 4.9152 MHz | ±50 ppm | 16.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 3.8 mm | 11.05 mm | 3.5 mm | ||||||
423 | Manufacturers Part No. CM7V-T1A 32.768-7-20-TBQA(CM7V-32-7-2TBQA) Micro Crystal SMD Tuning Fork Quartz Crystal CM7V-T1A Ceramic case 0,032768MHz ±20ppm 1,5mm x 3,2mm x 0,65mm 7pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 12 Weeks | (at least 3000 or mul. of 3000) | Micro Crystal | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 7.0 pF | ±3 ppm/Jahr | 1 µW | -40.0 °C | 125.0 °C | 1.5 mm | 3.2 mm | 0.65 mm | ||||||
424 | Manufacturers Part No. IC24011.0592M20CE1B(IC24TH11.0) Red Frequency Crystal, wired IC 24 Metal housing 11MHz 20ppm 10,7mm x 4,3mm x 2,8mm 20pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 500 or mul. of 500) | Red Frequency | Crystal, wired | Metal housing | 11.0 MHz | 20 ppm | 20.0 pF | ±3 ppm/Jahr | 500 µW | -20.0 °C | 70.0 °C | 10.7 mm | 4.3 mm | 2.8 mm | ||||||
425 | Manufacturers Part No. IC25012.000M30.0EE1C(IC25TH12.0) Red Frequency Crystal, wired IC 25 Metal housing 12MHz 30ppm 11mm x 4,6mm x 13,5mm 30pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 500 or mul. of 500) | Red Frequency | Crystal, wired | Metal housing | 12.0 MHz | 30 ppm | 30.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 11.0 mm | 4.6 mm | 13.5 mm |
