Results (583)
Not discontinued
In stock
RoHS compliant
Datasheet
New
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Package/Case | Frequency | Frequency tolerance | Load capacity | Ageing, max. | Load, max. | Operating Temperature Min. | Operating Temperature Max. | Dimension: Length | Dimension: Width | Dimension: Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
326 | Manufacturers Part No. 49S4HSMD16.000M-AF-303040R-30P(QSMD016) Abundance SMD Crystal HC49-S4-SMD Metal housing 16MHz ±30ppm 13mm x 4,73mm x 4,2mm 30pF | Customer Part No. Customer Project No. | 22.440 Pcs. | (at least 10 or mul. of 10) | Abundance | SMD Crystal | Metal housing | 16.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 13.0 mm | 4.73 mm | 4.2 mm | ||||||
327 | Manufacturers Part No. HC49S4HSMD-18.432M-30/30-40R(QSMD018.432) Abundance SMD Crystal HC49-S4-SMD Metal housing 18,432MHz ±30ppm 13mm x 4,73mm x 4,2mm 30pF | Customer Part No. Customer Project No. | 1.100 Pcs. Planned Delivery Time Ø 12 Weeks | (at least 10 or mul. of 10) | Abundance | SMD Crystal | Metal housing | 18.432 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 13.0 mm | 4.73 mm | 4.2 mm | ||||||
328 | Manufacturers Part No. 49S4HSMD12.000M-AF-303060R-30P(QSMD012) Abundance SMD Crystal HC49-S4-SMD Metal housing 12MHz ±30ppm 13mm x 4,73mm x 4,2mm 30pF | Customer Part No. Customer Project No. | 13.770 Pcs. | (at least 10 or mul. of 10) | Abundance | SMD Crystal | Metal housing | 12.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 13.0 mm | 4.73 mm | 4.2 mm | ||||||
329 | Manufacturers Part No. HC49S4HSMD-13.56M-30/30-50R(QSMD013.56) Abundance SMD Crystal HC49-S4-SMD Metal housing 13,56MHz ±30ppm 13mm x 4,73mm x 4,2mm 10pF | Customer Part No. Customer Project No. | 4.980 Pcs. Planned Delivery Time Ø 20 Weeks | (at least 10 or mul. of 10) | Abundance | SMD Crystal | Metal housing | 13.56 MHz | ±30 ppm | 10.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 13.0 mm | 4.73 mm | 4.2 mm | ||||||
330 | Manufacturers Part No. 49S4HSMD8.000M-AF-3030-80R-30P(QSMD008) Abundance SMD Crystal HC49-S4-SMD Metal housing 8MHz ±30ppm 13mm x 4,73mm x 4,2mm 30pF TOP | Customer Part No. Customer Project No. | 31.020 Pcs. Planned Delivery Time Ø 21 Weeks | (at least 10 or mul. of 10) | Abundance | SMD Crystal | Metal housing | 8.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 13.0 mm | 4.73 mm | 4.2 mm | ||||||
331 | Manufacturers Part No. 49S4HSMD9.8304M-AF-303080R-30P(QSMD009.830) Abundance SMD Crystal HC49-S4-SMD Metal housing 9,8304MHz ±30ppm 13mm x 4,73mm x 4,2mm 30pF | Customer Part No. Customer Project No. | 580 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Abundance | SMD Crystal | Metal housing | 9.8304 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 13.0 mm | 4.73 mm | 4.2 mm | ||||||
332 | Manufacturers Part No. IC21003.6864M32EE1B(IC21SMD3.6864) Red Frequency SMD Crystal IC 21 Metal housing 3,686MHz ±30ppm 13,3mm x 5mm x 4mm 32pF | Customer Part No. Customer Project No. | 820 Pcs. Planned Delivery Time Ø 6 Weeks | (at least 10 or mul. of 10) | Red Frequency | SMD Crystal | Metal housing | 3.686 MHz | ±30 ppm | 32.0 pF | ±3 ppm/Jahr | 1,0 mW | -20.0 °C | 70.0 °C | 13.3 mm | 5.0 mm | 4.0 mm | ||||||
333 | Manufacturers Part No. IC21004.000M30.0EE1B(IC21SMD4) Red Frequency SMD Crystal IC 21 Metal housing 4MHz ±30ppm 13,3mm x 5mm x 4mm 30pF | Customer Part No. Customer Project No. | 3.530 Pcs. Planned Delivery Time Ø 17 Weeks | (at least 10 or mul. of 10) | Red Frequency | SMD Crystal | Metal housing | 4.0 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 1,0 mW | -20.0 °C | 70.0 °C | 13.3 mm | 5.0 mm | 4.0 mm | ||||||
334 | Manufacturers Part No. IC21016.000M30.0EE1B(IC21SMD16) Red Frequency SMD Crystal IC 21 Metal housing 16MHz ±30ppm 13,3mm x 5mm x 4mm 30pF | Customer Part No. Customer Project No. | 8.420 Pcs. Planned Delivery Time Ø 15 Weeks | (at least 10 or mul. of 10) | Red Frequency | SMD Crystal | Metal housing | 16.0 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 1,0 mW | -20.0 °C | 70.0 °C | 13.3 mm | 5.0 mm | 4.0 mm | ||||||
335 | Manufacturers Part No. IC21024.576M30.0EE1C(IC21SMD24.576) Red Frequency SMD Crystal IC 21 Metal housing 24,576MHz ±30ppm 13,3mm x 5mm x 4mm 30pF | Customer Part No. Customer Project No. | 500 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 10 or mul. of 10) | Red Frequency | SMD Crystal | Metal housing | 24.576 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 13.3 mm | 5.0 mm | 4.0 mm | ||||||
336 | Manufacturers Part No. IC21004.096M30.0EE1B(IC21SMD4.096) Red Frequency SMD Crystal IC 21 Metal housing 4,096MHz ±30ppm 13,3mm x 5mm x 4mm 30pF | Customer Part No. Customer Project No. | 6.650 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 10 or mul. of 10) | Red Frequency | SMD Crystal | Metal housing | 4.096 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 1,0 mW | -20.0 °C | 70.0 °C | 13.3 mm | 5.0 mm | 4.0 mm | ||||||
337 | Manufacturers Part No. IC21030.000M30.0EE1C(IC21SMD30.0) Red Frequency SMD Crystal IC 21 Metal housing 30MHz ±30ppm 13,3mm x 5mm x 4mm 30pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 500 or mul. of 500) | Red Frequency | SMD Crystal | Metal housing | 30.0 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 13.3 mm | 5.0 mm | 4.0 mm | ||||||
338 | Manufacturers Part No. IC21012.288M30.0EE1B(IC21SMD12.288) Red Frequency SMD Crystal IC 21 Metal housing 12,228MHz ±30ppm 13,3mm x 5mm x 4mm 30pF | Customer Part No. Customer Project No. | 220 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 10 or mul. of 10) | Red Frequency | SMD Crystal | Metal housing | 12.228 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 1,0 mW | -20.0 °C | 70.0 °C | 13.3 mm | 5.0 mm | 4.0 mm | ||||||
339 | Manufacturers Part No. IC21025.000M30.0EE1C(IC21SMD25.0) Red Frequency SMD Crystal IC 21 Metal housing 25MHz ±30ppm 13,3mm x 5mm x 4mm 30pF | Customer Part No. Customer Project No. | 1.640 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 10 or mul. of 10) | Red Frequency | SMD Crystal | Metal housing | 25.0 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 13.3 mm | 5.0 mm | 4.0 mm | ||||||
340 | Manufacturers Part No. IC2104.194304M32EE1B(IC21SMD4.194304) Red Frequency SMD Crystal IC 21 Metal housing 4,194304MHz ±30ppm 13,3mm x 5mm x 4mm 32pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks | (at least 500 or mul. of 500) | Red Frequency | SMD Crystal | Metal housing | 4.194304 MHz | ±30 ppm | 32.0 pF | ±3 ppm/Jahr | 1,0 mW | -20.0 °C | 70.0 °C | 13.3 mm | 5.0 mm | 4.0 mm | ||||||
341 | Manufacturers Part No. Q22FA1280047612(Q22FA12800476) Epson SMD Crystal FA-128 Plastic housing 27,12MHz 15ppm 2mm x 1,6mm x 0,5mm 8pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Epson | SMD Crystal | Plastic housing | 27.12 MHz | 15 ppm | 8.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
342 | Manufacturers Part No. Q22FA1280009214(FA128-32) Epson SMD Crystal FA-128 Plastic housing 32MHz 10ppm 2mm x 1,6mm x 0,5mm 10pF | Customer Part No. Customer Project No. | 610 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Epson | SMD Crystal | Plastic housing | 32.0 MHz | 10 ppm | 10.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
343 | Manufacturers Part No. Q22FA1280013112(Q22FA12800131) Epson SMD Crystal FA-128 Plastic housing 32MHz 10ppm 2mm x 1,6mm x 0,5mm 9pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Epson | SMD Crystal | Plastic housing | 32.0 MHz | 10 ppm | 9.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
344 | Manufacturers Part No. Q22FA1280022012(Q22FA12800220) Epson SMD Crystal FA-128 Plastic housing 52MHz 10ppm 2mm x 1,6mm x 0,5mm 8pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Epson | SMD Crystal | Plastic housing | 52.0 MHz | 10 ppm | 8.0 pF | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | |||||||
345 | Manufacturers Part No. Q22FA1280055412(Q22FA12800554) Epson SMD Crystal FA-128 Plastic housing 26MHz 10ppm 2mm x 1,6mm x 0,5mm 12pF | Customer Part No. Customer Project No. | 590 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Epson | SMD Crystal | Plastic housing | 26.0 MHz | 10 ppm | 12.0 pF | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | |||||||
346 | Manufacturers Part No. Q22FA1280051712(Q22FA12800517) Epson SMD Crystal FA-128 Plastic housing 32MHz 10ppm 2mm x 1,6mm x 0,5mm 6pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Epson | SMD Crystal | Plastic housing | 32.0 MHz | 10 ppm | 6.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
347 | Manufacturers Part No. Q22FA1280002512(Q22FA12800025) Epson SMD Crystal FA-128 Plastic housing 32MHz 10ppm 2mm x 1,6mm x 0,5mm 8pF | Customer Part No. Customer Project No. | 450 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Epson | SMD Crystal | Plastic housing | 32.0 MHz | 10 ppm | 8.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
348 | Manufacturers Part No. Q22FA1280001114(FA128-26) Epson SMD Crystal FA-128 Plastic housing 26MHz 10ppm 2mm x 1,6mm x 0,5mm 10pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 1000 or mul. of 1000) | Epson | SMD Crystal | Plastic housing | 26.0 MHz | 10 ppm | 10.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
349 | Manufacturers Part No. Q22FA1280001412(Q22FA12800014) Epson SMD Crystal FA-128 Plastic housing 24MHz 30ppm 2mm x 1,6mm x 0,5mm 16pF | Customer Part No. Customer Project No. | 250 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 5 or mul. of 5) | Epson | SMD Crystal | Plastic housing | 24.0 MHz | 30 ppm | 16.0 pF | 5 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
350 | Manufacturers Part No. Q22FA1280019112(Q22FA12800191) Epson SMD Crystal FA-128 Plastic housing 32MHz 10ppm 2mm x 1,6mm x 0,5mm 8pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks | (at least 10 or mul. of 10) | Epson | SMD Crystal | Plastic housing | 32.0 MHz | 10 ppm | 8.0 pF | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm |
