Results (4167)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | Capacity | Capacity unit | Capacity Tolerance [%] | Rated voltage DC | Rated voltage AC | Application | Assembly Type | Housing | Diameter | Pitch | Dimension: Length | Dimension: Width | Dimension: Height | Form of Delivery | Operating Temperature Min. | Operating Temperature Max. | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
4151 |  NRND | Manufacturers Part No. EEE1EA220AP(EEE1EA220AP) Panasonic SMD Aluminum electrolytic capacitor S (A) 25V 22µF ±20% 6,3mmx5,4mm -40°C...85°C AEC-Q200 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Not Recommended for New Designs | (at least 100 or mul. of 100) | Aluminum electrolytic capacitor | Panasonic | 22.0 | µF | ±20 | 25.0 V | SMD | D | 6.3 mm | 5.4 mm | -40.0 °C | 85.0 °C | AEC-Q200 | |||||||||||
4152 | NRND | Manufacturers Part No. EEE1EA100WAR(EEE1EA100WAR) Panasonic SMD Aluminum electrolytic capacitor S (A) 25V 10µF ±20% 4mmx5,4mm -40°C...85°C AEC-Q200 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Not Recommended for New Designs | (at least 100 or mul. of 100) | Aluminum electrolytic capacitor | Panasonic | 10.0 | µF | ±20 | 25.0 V | SMD | B | 4.0 mm | 5.4 mm | -40.0 °C | 85.0 °C | AEC-Q200 | |||||||||||
4153 | NRND | Manufacturers Part No. EEE1EA220WAR(EEE1EA220WAR) Panasonic SMD Aluminum electrolytic capacitor S (A) 25V 22µF ±20% 5mmx5,4mm -40°C...85°C AEC-Q200 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Not Recommended for New Designs | (at least 100 or mul. of 100) | Aluminum electrolytic capacitor | Panasonic | 22.0 | µF | ±20 | 25.0 V | SMD | C | 5.0 mm | 5.4 mm | -40.0 °C | 85.0 °C | AEC-Q200 | |||||||||||
4154 | NRND | Manufacturers Part No. EEE1EA221UAP(EEE1EA221UAP) Panasonic SMD Aluminum electrolytic capacitor S (A) 25V 220µF ±20% 8mmx10,2mm -40°C...85°C AEC-Q200 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Not Recommended for New Designs | (at least 100 or mul. of 100) | Aluminum electrolytic capacitor | Panasonic | 220.0 | µF | ±20 | 25.0 V | SMD | F | 8.0 mm | 10.2 mm | -40.0 °C | 85.0 °C | AEC-Q200 | |||||||||||
4155 | NRND | Manufacturers Part No. EEE1EA331AP(EEE1EA331AP) Panasonic SMD Aluminum electrolytic capacitor S (A) 25V 330µF ±20% 10mmx10,2mm -40°C...85°C AEC-Q200 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Not Recommended for New Designs | (at least 100 or mul. of 100) | Aluminum electrolytic capacitor | Panasonic | 330.0 | µF | ±20 | 25.0 V | SMD | G | 10.0 mm | 10.2 mm | -40.0 °C | 85.0 °C | AEC-Q200 | |||||||||||
4156 | NRND | Manufacturers Part No. EEE1EA221AP(EEE1EA221AP) Panasonic SMD Aluminum electrolytic capacitor S (A) 25V 220µF ±20% 10mmx10,2mm -40°C...85°C AEC-Q200 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Not Recommended for New Designs | (at least 100 or mul. of 100) | Aluminum electrolytic capacitor | Panasonic | 220.0 | µF | ±20 | 25.0 V | SMD | G | 10.0 mm | 10.2 mm | -40.0 °C | 85.0 °C | AEC-Q200 | |||||||||||
4157 | NRND | Manufacturers Part No. EEE1AA102UAP(EEE1AA102UAP) Panasonic SMD Aluminum electrolytic capacitor S (A) 10V 1000µF ±20% 10mmx10,2mm -40°C...85°C AEC-Q200 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Not Recommended for New Designs | (at least 100 or mul. of 100) | Aluminum electrolytic capacitor | Panasonic | 1000.0 | µF | ±20 | 10.0 V | SMD | G | 10.0 mm | 10.2 mm | -40.0 °C | 85.0 °C | AEC-Q200 | |||||||||||
4158 | NRND | Manufacturers Part No. EEE1EA470WAP(EEE1EA470WAP) Panasonic SMD Aluminum electrolytic capacitor S (A) 25V 47µF ±20% 4mmx5,4mm -40°C...85°C AEC-Q200 | Customer Part No. Customer Project No. | 800 Pcs. Planned Delivery Time Ø 29 Weeks Not Recommended for New Designs | (at least 100 or mul. of 100) | Aluminum electrolytic capacitor | Panasonic | 47.0 | µF | ±20 | 25.0 V | SMD | D | 4.0 mm | 5.4 mm | -40.0 °C | 85.0 °C | AEC-Q200 | |||||||||||
4159 | NRND | Manufacturers Part No. EEE1EA471UAP(EEE1EA471UAP) Panasonic SMD Aluminum electrolytic capacitor S (A) 25V 470µF ±20% 10mmx10,2mm -40°C...85°C AEC-Q200 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Not Recommended for New Designs | (at least 100 or mul. of 100) | Aluminum electrolytic capacitor | Panasonic | 470.0 | µF | ±20 | 25.0 V | SMD | G | 10.0 mm | 10.2 mm | -40.0 °C | 85.0 °C | AEC-Q200 | |||||||||||
4160 | NRND | Manufacturers Part No. EEE1EA4R7AR(EEE1EA4R7AR) Panasonic SMD Aluminum electrolytic capacitor S (A) 25V 4,7µF ±20% 4mmx5,4mm -40°C...85°C AEC-Q200 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Not Recommended for New Designs | (at least 100 or mul. of 100) | Aluminum electrolytic capacitor | Panasonic | 4.7 | µF | ±20 | 25.0 V | SMD | B | 4.0 mm | 5.4 mm | -40.0 °C | 85.0 °C | AEC-Q200 | |||||||||||
4161 | NRND | Manufacturers Part No. EEE1EA100AR(EEE1EA100AR) Panasonic SMD Aluminum electrolytic capacitor S (A) 25V 10µF ±20% 5mmx5,4mm -40°C...85°C AEC-Q200 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Not Recommended for New Designs | (at least 100 or mul. of 100) | Aluminum electrolytic capacitor | Panasonic | 10.0 | µF | ±20 | 25.0 V | SMD | C | 5.0 mm | 5.4 mm | -40.0 °C | 85.0 °C | AEC-Q200 | |||||||||||
4162 | NRND | Manufacturers Part No. EEE1EA330WAR(EEE1EA330WAR) Panasonic SMD Aluminum electrolytic capacitor S (A) 25V 33µF ±20% 5mmx5,4mm -40°C...85°C AEC-Q200 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Not Recommended for New Designs | (at least 100 or mul. of 100) | Aluminum electrolytic capacitor | Panasonic | 33.0 | µF | ±20 | 25.0 V | SMD | C | 5.0 mm | 5.4 mm | -40.0 °C | 85.0 °C | AEC-Q200 | |||||||||||
4163 | NRND | Manufacturers Part No. EEE1EA331UAP(EEE1EA331UAP) Panasonic SMD Aluminum electrolytic capacitor S (A) 25V 330µF ±20% 8mmx10,2mm -40°C...85°C AEC-Q200 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Not Recommended for New Designs | (at least 100 or mul. of 100) | Aluminum electrolytic capacitor | Panasonic | 330.0 | µF | ±20 | 25.0 V | SMD | F | 8.0 mm | 10.2 mm | -40.0 °C | 85.0 °C | AEC-Q200 | |||||||||||
4164 | EOL 08.11.2024 | Manufacturers Part No. EEUFK0J822S(EEUFK0J822S) Panasonic Aluminum electrolytic capacitor FK-A THT radial 6,3V 8200µF ±20% P7,5mm -55°C...105°C AEC-Q200 | Customer Part No. Customer Project No. | No longer available | (at least 25 or mul. of 25) | Aluminum electrolytic capacitor | Panasonic | 8200.0 | µF | ±20 | 6.3 V | THT | radial | 18.0 mm | 7.5 mm | 20.0 mm | bulk | -55.0 °C | 105.0 °C | AEC-Q200 | |||||||||
4165 | EOL 08.11.2024 | Manufacturers Part No. EEUFK1A822S(EEUFK1A822S) Panasonic Aluminum electrolytic capacitor FK-A THT radial 10V 8200µF ±20% P7,5mm -55°C...105°C AEC-Q200 | Customer Part No. Customer Project No. | No longer available | (at least 25 or mul. of 25) | Aluminum electrolytic capacitor | Panasonic | 8200.0 | µF | ±20 | 10.0 V | THT | radial | 18.0 mm | 7.5 mm | 25.0 mm | bulk | -55.0 °C | 105.0 °C | AEC-Q200 | |||||||||
4166 | EOL 08.11.2024 | Manufacturers Part No. EEUFK1E272L(EEUFK1E272L) Panasonic Aluminum electrolytic capacitor FK-A THT radial 25V 2700µF ±20% P5mm -55°C...105°C AEC-Q200 | Customer Part No. Customer Project No. | No longer available | (at least 25 or mul. of 25) | Aluminum electrolytic capacitor | Panasonic | 2700.0 | µF | ±20 | 25.0 V | THT | radial | 12.5 mm | 5.0 mm | 35.0 mm | bulk | -55.0 °C | 105.0 °C | AEC-Q200 | |||||||||
4167 | EOL 07.04.2026 | Manufacturers Part No. A22201612030(CAX02200/16) FTCAP Aluminum electrolytic capacitor A THT Axial 16V 2200µF -40°C...85°C | Customer Part No. Customer Project No. | 234 Pcs. Cancelled by manufacturer without replacement | (at least 25 or mul. of 25) | Aluminum electrolytic capacitor | FTCAP | 2200.0 | µF | 16.0 V | THT | Axial | 12.0 mm | 30.0 mm | bulk | -40.0 °C | 85.0 °C |
