ETQP6M2R5YLC

Panasonic Inductors SMD storage / suppression chokes PCC-M1060ML 2,5µH -20-20% 10,9mm 10mm 6mm

Manufacturer Part No.
ETQP6M2R5YLC
Schukat Part No.
ETQP6M2R5YLC
Manufacturer
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

80 Pcs. in stock

Planned delivery time
Ø 19 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available (from stock)
Replacement / Follow-up View entire series
Data Sheet
ECAD Model
Downloads

Prices

Manufacturer bundle 1000 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 5 or multiple of 5)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Kind
storage / suppression chokes
Inductance
2,5 µH
Inductance tolerance
-20 %
Nominal resistance
5 mOhm
Housing
SMD
Dimension: Length
10.9 mm
Dimension: Width
10 mm
Dimension: Height
6 mm
RoHS-Conform

Specifications

Open all

General

Manufacturer
  • Panasonic
Series
  • PCC-M1060ML
Product group
  • D2350 Panasonic ETQP_P Series M0530M, M0540M..
Type
  • Inductors
Kind
  • storage / suppression chokes
Housing
  • SMD
Features
  • - High heat resistance and high reliability using metal composite core (MC)
    - High heat resistance: Operation up to 150°C including self-heating
    - High-reliability: High vibration resistance as result of newly developed integral construction; under severe reliability conditions of automotive and other strenuous applications
    - High bias current: Excellent inductance stability using ferrous alloy magnetic material
    - Temperature stability: Excellent inductance stability over broad temperature range
    - Low audible (buzz) noise: A gapless structure achieved with metal composite core
    - High efficiency: Low DC resistance of winding and low eddy-current loss of the core
    - Shielded construction
    - AEC-Q200 compliant

Dimensions and weights

Dimension: Length
  • 10.9 mm
Dimension: Width
  • 10 mm
Dimension: Height
  • 6 mm

Operating conditions

Operating Temperature Min.
  • -40 °C
Operating Temperature Max.
  • 150 °C

Technical features

Inductance
  • 2,5 µH
Inductance tolerance
  • -20 %
Nominal resistance
  • 5 mOhm
Sättigungsstrom
  • 25.8 A

Safety/Certifications

Standards
  • AEC-Q200
