Results (918)
Not discontinued
In stock
RoHS compliant
Datasheet
New
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | Assembly Type | Rated voltage AC | Rated voltage DC | Switching current | Switching capacity (VA) | contacts | Contact material | Coil resistance | Dimension: Length | Dimension: Width | Dimension: Height | Protection class RT | Operating Temperature Min. | Operating Temperature Max. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
101 | Manufacturers Part No. ALQ324(ALQ324) Panasonic Signal relay LQ THT SPST-NO 5A 24VDC 2.880Ohm 20mmx10mmx16mm RTIII | Customer Part No. Customer Project No. | 1.430 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Signal relay | Panasonic | THT | 24.0 V DC | 5.0 A | 1250.0 VA | SPST-NO | AgNi | 2880.0 Ohm | 20.0 mm | 10.0 mm | 16.0 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
102 | Manufacturers Part No. FTR-C1CA003G(FTR-C1CA003G) FCL Components Power relay FTR-C1 THT DPDT 2A 3VDC 32,1Ohm 15,2mmx7,7mmx9,4mm RTIII | Customer Part No. Customer Project No. | 970 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 10 or mul. of 10) | Power relay | FCL Components | THT | 3.0 V DC | 2.0 A | 62.5 VA | DPDT | AgPd/Au | 32.1 Ohm | 15.2 mm | 7.7 mm | 9.4 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
103 | Manufacturers Part No. FTR-C1GA003G-B05(FTR-C1GA003G-B05) FCL Components Power relay FTR-C1 SMD DPDT 2A 3VDC 32,1Ohm 15,2mmx7,7mmx9,7mm RTIII | Customer Part No. Customer Project No. | 500 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 10 or mul. of 10) | Power relay | FCL Components | SMD | 3.0 V DC | 2.0 A | 62.5 VA | DPDT | AgPd/Au | 32.1 Ohm | 15.2 mm | 7.7 mm | 9.7 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
104 | Manufacturers Part No. FTR-LYAA024Y(FTR-LYAA024Y) FCL Components Power relay FTR-LY THT SPST-NO 6A 24VDC 3.390Ohm 28mmx5mmx15mm RTIII | Customer Part No. Customer Project No. | 1.250 Pcs. Planned Delivery Time Ø 22 Weeks Available (from stock) | (at least 5 or mul. of 5) | Power relay | FCL Components | THT | 24.0 V DC | 6.0 A | 1500.0 VA | SPST-NO | AgSnO2 | 3390.0 Ohm | 28.0 mm | 5.0 mm | 15.0 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
105 | Manufacturers Part No. AZ921-1A-12DEF(AZ921-1A-12DEF) Zettler Power relay AZ921 THT SPST-NO 5A 12VDC 1.200Ohm 20,3mmx5,3mmx12,8mm | Customer Part No. Customer Project No. | 510 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Power relay | Zettler | THT | 12.0 V DC | 5.0 A | 1250.0 VA | SPST-NO | AgNi | 1200.0 Ohm | 20.3 mm | 5.3 mm | 12.8 mm | -40.0 °C | 85.0 °C | ||||||||
106 | Manufacturers Part No. AZ921-1AB-24DEAF(AZ921-1AB-24DEAF) Zettler Power relay AZ921 THT SPST-NO 5A 24VDC 3.200Ohm 20,3mmx5,3mmx12,8mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 18 Weeks Available on order | (at least 1000 or mul. of 1000) | Power relay | Zettler | THT | 24.0 V DC | 5.0 A | 1250.0 VA | SPST-NO | AgNi/Au | 3200.0 Ohm | 20.3 mm | 5.3 mm | 12.8 mm | -40.0 °C | 85.0 °C | ||||||||
107 | Manufacturers Part No. HF46F/12-HS1(HF46F-12-HS1) Hongfa Power relay HF46F THT SPST-NO 5A 12VDC 720Ohm 20,5mmx7mmx15,3mm | Customer Part No. Customer Project No. | 780 Pcs. Available (from stock) | (at least 5 or mul. of 5) | Power relay | Hongfa | THT | 12.0 V DC | 5.0 A | 1385.0 VA | SPST-NO | AgNi | 720.0 Ohm | 20.5 mm | 7.0 mm | 15.3 mm | -40.0 °C | 85.0 °C | ||||||||
108 | Manufacturers Part No. AZ6991-1A-12D(AZ6991-1A-12D) Zettler Power relay AZ6991 THT SPST-NO 8A 12VDC 848Ohm 28mmx5mmx15mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 18 Weeks Available on order | (at least 2000 or mul. of 2000) | Power relay | Zettler | THT | 12.0 V DC | 8.0 A | 2216.0 VA | SPST-NO | AgNi | 848.0 Ohm | 28.0 mm | 5.0 mm | 15.0 mm | -40.0 °C | 85.0 °C | ||||||||
109 | Manufacturers Part No. HF46F-G/5-HS1T(HF46F-G-5-HS1T) Hongfa Power relay HF46F THT SPST-NO 10A 5VDC 125Ohm 20,5mmx7mmx15,3mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 5 or mul. of 5) | Power relay | Hongfa | THT | 5.0 V DC | 10.0 A | 2770.0 VA | SPST-NO | AgSnO2 | 125.0 Ohm | 20.5 mm | 7.0 mm | 15.3 mm | -40.0 °C | 85.0 °C | ||||||||
110 | Manufacturers Part No. AZ6991-1AE-12DE(AZ6991-1AE-12DE) Zettler Power relay AZ6991 THT SPST-NO 8A 12VDC 848Ohm 28mmx5mmx15mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Power relay | Zettler | THT | 12.0 V DC | 8.0 A | 2216.0 VA | SPST-NO | AgSnO2 | 848.0 Ohm | 28.0 mm | 5.0 mm | 15.0 mm | -40.0 °C | 85.0 °C | ||||||||
111 | Manufacturers Part No. RM699BV-2011-85-1060(RM699BV2011-851060) RELPOL Power relay RM699B THT SPST 10A 60VDC 16.600Ohm 28mmx5mmx15mm RTIII | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 21 Weeks Available on order | (at least 1000 or mul. of 1000) | Power relay | RELPOL | THT | 60.0 V DC | 10.0 A | 1500.0 VA | SPST | AgNi | 16600.0 Ohm | 28.0 mm | 5.0 mm | 15.0 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
112 | Manufacturers Part No. AZ7709T-1AE-12DSEF(AZ7709T-1AE-12DSEF) Zettler Power relay AZ7709 THT SPST-NO 10A 12VDC 720Ohm 18,9mmx10,7mmx15,7mm | Customer Part No. Customer Project No. | 710 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 10 or mul. of 10) | Power relay | Zettler | THT | 12.0 V DC | 10.0 A | 2500.0 VA | SPST-NO | AgSnO2 | 720.0 Ohm | 18.9 mm | 10.7 mm | 15.7 mm | -40.0 °C | 85.0 °C | ||||||||
113 | Manufacturers Part No. FTR-B3SA4.5Z-B10(FTR-B3-4.5) FCL Components Signal relay FTR B3 SMD DPDT 2A 4,5VDC 145Ohm 10,6mmx7,2mmx5,45mm RTIII TOP | Customer Part No. Customer Project No. | 2.130 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Signal relay | FCL Components | SMD | 4.5 V DC | 2.0 A | 62.5 VA | DPDT | AgNi/Au | 145.0 Ohm | 10.6 mm | 7.2 mm | 5.45 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
114 | Manufacturers Part No. TQ2SA-12V(TQ2SA-12V) Panasonic Signal relay TQ SMD DPDT 2A 12VDC 1.028Ohm 14mmx9mmx5,6mm TOP | Customer Part No. Customer Project No. | 1.344 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 5 or mul. of 5) | Signal relay | Panasonic | SMD | 12.0 V DC | 2.0 A | 62.5 VA | DPDT | AgNi/Au | 1028.0 Ohm | 14.0 mm | 9.0 mm | 5.6 mm | -40.0 °C | 85.0 °C | ||||||||
115 | Manufacturers Part No. FTR-B3GA024Z-B10(FTRB3GA024ZB10) FCL Components Signal relay FTR B3 SMD DPDT 2A 24VDC 2.504Ohm 10,6mmx7,2mmx5,45mm RTIII | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Signal relay | FCL Components | SMD | 24.0 V DC | 2.0 A | 62.5 VA | DPDT | AgNi/Au | 2504.0 Ohm | 10.6 mm | 7.2 mm | 5.45 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
116 | Manufacturers Part No. FTR-B3GA4.5Z-B10(FTRB3GA4.5ZB10) FCL Components Signal relay FTR B3 SMD DPDT 2A 4,5VDC 145Ohm 10,6mmx7,2mmx5,45mm RTIII TOP | Customer Part No. Customer Project No. | 2.600 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Signal relay | FCL Components | SMD | 4.5 V DC | 2.0 A | 62.5 VA | DPDT | AgNi/Au | 145.0 Ohm | 10.6 mm | 7.2 mm | 5.45 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
117 | Manufacturers Part No. FTR-B3SA009Z-B10(FTRB3SA009ZB10) FCL Components Signal relay FTR B3 SMD DPDT 2A 9VDC 579Ohm 10,6mmx7,2mmx5,45mm RTIII | Customer Part No. Customer Project No. | 840 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 10 or mul. of 10) | Signal relay | FCL Components | SMD | 9.0 V DC | 2.0 A | 62.5 VA | DPDT | AgNi/Au | 579.0 Ohm | 10.6 mm | 7.2 mm | 5.45 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
118 | Manufacturers Part No. FTR-B3SA024Z-B10(FTRB3SA024ZB10) FCL Components Signal relay FTR B3 SMD DPDT 2A 24VDC 2.504Ohm 10,6mmx7,2mmx5,45mm RTIII | Customer Part No. Customer Project No. | 530 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 10 or mul. of 10) | Signal relay | FCL Components | SMD | 24.0 V DC | 2.0 A | 62.5 VA | DPDT | AgNi/Au | 2504.0 Ohm | 10.6 mm | 7.2 mm | 5.45 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
119 | Manufacturers Part No. AZ850P2-12(AZ850P2-12) Zettler Signal relay DIP DIL AZ850 THT DPDT 1A 12VDC 1.440Ohm 14mmx9mmx5mm | Customer Part No. Customer Project No. | 1.015 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock) | (at least 5 or mul. of 5) | Signal relay DIP DIL | Zettler | THT | 12.0 V DC | 1.0 A | 62.5 VA | DPDT | AgPd/Au | 1440.0 Ohm | 14.0 mm | 9.0 mm | 5.0 mm | -40.0 °C | 85.0 °C | ||||||||
120 | Manufacturers Part No. AZ851-5(AZ851-5) Zettler Signal relay AZ851 SMD DPDT 1A 5VDC 178Ohm 14,2mmx9,3mmx6,2mm | Customer Part No. Customer Project No. | 970 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock) | (at least 5 or mul. of 5) | Signal relay | Zettler | SMD | 5.0 V DC | 1.0 A | 62.5 VA | DPDT | AgPd/Au | 178.0 Ohm | 14.2 mm | 9.3 mm | 6.2 mm | -40.0 °C | 85.0 °C | ||||||||
121 | Manufacturers Part No. G6K-2F DC5(G6K2F-5) Omron Signal relay G6K SMD DPDT 1A 5VDC 237Ohm 10mmx6,5mmx5,2mm TOP | Customer Part No. Customer Project No. | 1.550 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Signal relay | Omron | SMD | 5.0 V DC | 1.0 A | DPDT | Ag/Au | 237.0 Ohm | 10.0 mm | 6.5 mm | 5.2 mm | -40.0 °C | 70.0 °C | |||||||||
122 | Manufacturers Part No. AZ822-2C-24DSE(AZ822-2C-24DSE) Zettler Signal relay DIP DIL AZ822 THT DPDT 2A 24VDC 2.880Ohm 20mmx9,8mmx12mm | Customer Part No. Customer Project No. | 350 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Signal relay DIP DIL | Zettler | THT | 24.0 V DC | 2.0 A | 125.0 VA | DPDT | AgPd/Au | 2880.0 Ohm | 20.0 mm | 9.8 mm | 12.0 mm | -55.0 °C | 90.0 °C | ||||||||
123 | Manufacturers Part No. HFD4/24(HFD4-24) Hongfa Signal relay HFD4 THT DPDT 2A 24VDC 2.880Ohm 10mmx6,5mmx5,4mm | Customer Part No. Customer Project No. | 1.625 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 5 or mul. of 5) | Signal relay | Hongfa | THT | 24.0 V DC | 2.0 A | 62.5 VA | DPDT | AgNi/Au | 2880.0 Ohm | 10.0 mm | 6.5 mm | 5.4 mm | -40.0 °C | 85.0 °C | ||||||||
124 | Manufacturers Part No. AZ8521S-12(AZ8521S-12) Zettler Signal relay AZ8521 SMD DPDT 2A 12VDC 1.028Ohm 10mmx6,5mmx5,65mm | Customer Part No. Customer Project No. | 790 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock) | (at least 10 or mul. of 10) | Signal relay | Zettler | SMD | 12.0 V DC | 2.0 A | 62.5 VA | DPDT | AgNi/Au | 1028.0 Ohm | 10.0 mm | 6.5 mm | 5.65 mm | -40.0 °C | 85.0 °C | ||||||||
125 | Manufacturers Part No. AZ8521S-4.5TR(AZ8521S-4.5TR) Zettler Signal relay AZ8521 SMD DPDT 2A 4,5VDC 145Ohm 10mmx6,5mmx5,65mm | Customer Part No. Customer Project No. | 900 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock) | (at least 10 or mul. of 10) | Signal relay | Zettler | SMD | 4.5 V DC | 2.0 A | 62.5 VA | DPDT | AgNi/Au | 145.0 Ohm | 10.0 mm | 6.5 mm | 5.65 mm | -40.0 °C | 85.0 °C |
