Results (918)
Not discontinued
In stock
RoHS compliant
Datasheet
New
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | Assembly Type | Rated voltage AC | Rated voltage DC | Switching current | Switching capacity (VA) | contacts | Contact material | Coil resistance | Dimension: Length | Dimension: Width | Dimension: Height | Protection class RT | Operating Temperature Min. | Operating Temperature Max. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
676 | Manufacturers Part No. 5-1415899-4(RZ031C3D012) TE Connectivity Power relay RZ THT SPDT 16A 12VDC 360Ohm 29mmx12,7mmx15,7mm RTII | Customer Part No. Customer Project No. | 80 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | Power relay | TE Connectivity | THT | 12.0 V DC | 16.0 A | 4000.0 VA | SPDT | AgSnO2 | 360.0 Ohm | 29.0 mm | 12.7 mm | 15.7 mm | RTII | -40.0 °C | 85.0 °C | |||||||
677 | Manufacturers Part No. 4-1393224-6(RYII012) TE Connectivity Power relay RYII THT SPDT 8A 12VDC 627Ohm 28,5mmx10,1mmx12,3mm TOP | Customer Part No. Customer Project No. | 3.820 Pcs. Available (from stock) | (at least 20 or mul. of 20) | Power relay | TE Connectivity | THT | 12.0 V DC | 8.0 A | 2000.0 VA | SPDT | AgNi | 627.0 Ohm | 28.5 mm | 10.1 mm | 12.3 mm | -40.0 °C | 70.0 °C | ||||||||
678 | Manufacturers Part No. 4-1393224-9(RYII024) TE Connectivity Power relay RYII THT SPDT 8A 24VDC 2.350Ohm 28,5mmx10,1mmx12,3mm TOP | Customer Part No. Customer Project No. | 5.960 Pcs. Available (from stock) | (at least 20 or mul. of 20) | Power relay | TE Connectivity | THT | 24.0 V DC | 8.0 A | 2000.0 VA | SPDT | AgNi | 2350.0 Ohm | 28.5 mm | 10.1 mm | 12.3 mm | -40.0 °C | 70.0 °C | ||||||||
679 | Manufacturers Part No. 2-1393225-6(RY612012) TE Connectivity Power relay RYII THT SPDT 8A 12VDC 627Ohm 28,5mmx10,1mmx12,3mm RTIII | Customer Part No. Customer Project No. | 440 Pcs. Available (from stock) | (at least 20 or mul. of 20) | Power relay | TE Connectivity | THT | 12.0 V DC | 8.0 A | 2000.0 VA | SPDT | AgNi/Au | 627.0 Ohm | 28.5 mm | 10.1 mm | 12.3 mm | RTIII | -40.0 °C | 70.0 °C | |||||||
680 | Manufacturers Part No. 2-1393225-9(RY612024) TE Connectivity Power relay RYII THT SPDT 8A 24VDC 2.350Ohm 28,5mmx10,1mmx12,3mm RTIII | Customer Part No. Customer Project No. | 600 Pcs. Available (from stock) | (at least 20 or mul. of 20) | Power relay | TE Connectivity | THT | 24.0 V DC | 8.0 A | 2000.0 VA | SPDT | AgNi/Au | 2350.0 Ohm | 28.5 mm | 10.1 mm | 12.3 mm | RTIII | -40.0 °C | 70.0 °C | |||||||
681 | Manufacturers Part No. G5Q-1A4-EL2-HA DC12(G5Q-1A4-EL2-HADC12) Omron Power relay G5Q-EL2 THT SPST-NO 10A 12VDC 360Ohm 20mmx10mmx15,5mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 20 or mul. of 20) | Power relay | Omron | THT | 12.0 V DC | 10.0 A | 277.0 VA | SPST-NO | Ag alloy | 360.0 Ohm | 20.0 mm | 10.0 mm | 15.5 mm | -40.0 °C | 85.0 °C | ||||||||
682 | Manufacturers Part No. 7-1393224-9(RY531012) TE Connectivity Power relay RYII THT SPST-NO 8A 12VDC 627Ohm 28,5mmx10,1mmx12,3mm RTII | Customer Part No. Customer Project No. | 60 Pcs. Available (from stock) | (at least 20 or mul. of 20) | Power relay | TE Connectivity | THT | 12.0 V DC | 8.0 A | 2000.0 VA | SPST-NO | AgNi | 627.0 Ohm | 28.5 mm | 10.1 mm | 12.3 mm | RTII | -40.0 °C | 70.0 °C | |||||||
683 | Manufacturers Part No. 2-1393225-3(RY612005) TE Connectivity Power relay RYII THT SPDT 8A 5VDC 112Ohm 28,5mmx10,1mmx12,3mm RTIII | Customer Part No. Customer Project No. | 980 Pcs. Planned Delivery Time Ø 55 Weeks Available (from stock) | (at least 20 or mul. of 20) | Power relay | TE Connectivity | THT | 5.0 V DC | 8.0 A | 2000.0 VA | SPDT | AgNi/Au | 112.0 Ohm | 28.5 mm | 10.1 mm | 12.3 mm | RTIII | -40.0 °C | 70.0 °C | |||||||
684 | Manufacturers Part No. G5Q-1A4-EL3-HA DC12(G5Q-1A4-EL3-HADC12) Omron Power relay G5Q-EL3 THT SPST-NO 10A 12VDC 360Ohm 20mmx10mmx15,5mm | Customer Part No. Customer Project No. | 900 Pcs. Planned Delivery Time Ø 26 Weeks Available (from stock) | (at least 20 or mul. of 20) | Power relay | Omron | THT | 12.0 V DC | 10.0 A | 277.0 VA | SPST-NO | Ag alloy | 360.0 Ohm | 20.0 mm | 10.0 mm | 15.5 mm | -40.0 °C | 85.0 °C | ||||||||
685 | Manufacturers Part No. G5Q-1A4-EL3-HA DC24(G5Q-1A4-EL3-HADC24) Omron Power relay G5Q-EL3 THT SPST-NO 10A 24VDC 1.440Ohm 20mmx10mmx15,5mm | Customer Part No. Customer Project No. | 860 Pcs. Planned Delivery Time Ø 26 Weeks Available (from stock) | (at least 20 or mul. of 20) | Power relay | Omron | THT | 24.0 V DC | 10.0 A | 277.0 VA | SPST-NO | Ag alloy | 1440.0 Ohm | 20.0 mm | 10.0 mm | 15.5 mm | -40.0 °C | 85.0 °C | ||||||||
686 | Manufacturers Part No. 2-1393225-1(RY611024) TE Connectivity Power relay RYII THT SPDT 8A 24VDC 2.350Ohm 28,5mmx10,1mmx12,3mm RTIII | Customer Part No. Customer Project No. | 3.140 Pcs. Planned Delivery Time Ø 55 Weeks Available (from stock) | (at least 20 or mul. of 20) | Power relay | TE Connectivity | THT | 24.0 V DC | 8.0 A | 2000.0 VA | SPDT | AgNi | 2350.0 Ohm | 28.5 mm | 10.1 mm | 12.3 mm | RTIII | -40.0 °C | 70.0 °C | |||||||
687 | Manufacturers Part No. G5Q-1A4-EL2-HA DC5(G5Q-1A4-EL2-HADC5) Omron Power relay G5Q-EL2 THT SPST-NO 10A 5VDC 63Ohm 20mmx10mmx15,5mm | Customer Part No. Customer Project No. | 240 Pcs. Planned Delivery Time Ø 26 Weeks Available (from stock) | (at least 20 or mul. of 20) | Power relay | Omron | THT | 5.0 V DC | 10.0 A | 277.0 VA | SPST-NO | Ag alloy | 63.0 Ohm | 20.0 mm | 10.0 mm | 15.5 mm | -40.0 °C | 85.0 °C | ||||||||
688 | Manufacturers Part No. 1-1393225-7(RY611005) TE Connectivity Power relay RYII THT SPDT 8A 5VDC 112Ohm 28,5mmx10,1mmx12,3mm RTIII | Customer Part No. Customer Project No. | 1.400 Pcs. Planned Delivery Time Ø 55 Weeks Available (from stock) | (at least 20 or mul. of 20) | Power relay | TE Connectivity | THT | 5.0 V DC | 8.0 A | 2000.0 VA | SPDT | AgNi | 112.0 Ohm | 28.5 mm | 10.1 mm | 12.3 mm | RTIII | -40.0 °C | 70.0 °C | |||||||
689 | Manufacturers Part No. G5Q-1A4-EL3-HA DC5(G5Q-1A4-EL3-HADC5) Omron Power relay G5Q-EL3 THT SPST-NO 10A 5VDC 63Ohm 20mmx10mmx15,5mm | Customer Part No. Customer Project No. | 500 Pcs. Planned Delivery Time Ø 26 Weeks Available (from stock) | (at least 20 or mul. of 20) | Power relay | Omron | THT | 5.0 V DC | 10.0 A | 277.0 VA | SPST-NO | Ag alloy | 63.0 Ohm | 20.0 mm | 10.0 mm | 15.5 mm | -40.0 °C | 85.0 °C | ||||||||
690 | Manufacturers Part No. 8-1393224-2(RY531024) TE Connectivity Power relay RYII THT SPST-NO 8A 24VDC 2.350Ohm 28,5mmx10,1mmx12,3mm RTII | Customer Part No. Customer Project No. | 140 Pcs. Available (from stock) | (at least 20 or mul. of 20) | Power relay | TE Connectivity | THT | 24.0 V DC | 8.0 A | 2000.0 VA | SPST-NO | AgNi | 2350.0 Ohm | 28.5 mm | 10.1 mm | 12.3 mm | RTII | -40.0 °C | 70.0 °C | |||||||
691 | Manufacturers Part No. G5Q-1A4-EL2-HA DC24(G5Q-1A4-EL2-HADC24) Omron Power relay G5Q-EL2 THT SPST-NO 10A 24VDC 1.440Ohm 20mmx10mmx15,5mm | Customer Part No. Customer Project No. | 500 Pcs. Planned Delivery Time Ø 26 Weeks Available (from stock) | (at least 20 or mul. of 20) | Power relay | Omron | THT | 24.0 V DC | 10.0 A | 277.0 VA | SPST-NO | Ag alloy | 1440.0 Ohm | 20.0 mm | 10.0 mm | 15.5 mm | -40.0 °C | 85.0 °C | ||||||||
692 | Manufacturers Part No. 1-1393225-9(RY611012) TE Connectivity Power relay RYII THT SPDT 8A 12VDC 627Ohm 28,5mmx10,1mmx12,3mm RTIII | Customer Part No. Customer Project No. | 300 Pcs. Planned Delivery Time Ø 55 Weeks Available (from stock) | (at least 20 or mul. of 20) | Power relay | TE Connectivity | THT | 12.0 V DC | 8.0 A | 2000.0 VA | SPDT | AgNi | 627.0 Ohm | 28.5 mm | 10.1 mm | 12.3 mm | RTIII | -40.0 °C | 70.0 °C | |||||||
693 | Manufacturers Part No. 2-1393225-2(RY611048) TE Connectivity Power relay RYII THT SPDT 8A 48VDC 9.391Ohm 28,5mmx10,1mmx12,3mm RTIII | Customer Part No. Customer Project No. | 60 Pcs. Planned Delivery Time Ø 55 Weeks Available (from stock) | (at least 20 or mul. of 20) | Power relay | TE Connectivity | THT | 48.0 V DC | 8.0 A | 2000.0 VA | SPDT | AgNi | 9391.0 Ohm | 28.5 mm | 10.1 mm | 12.3 mm | RTIII | -40.0 °C | 70.0 °C | |||||||
694 | Manufacturers Part No. RWH-SS-112D(RWH-SS-112D) GoodSky Power relay RWH THT SPDT 15A 12VDC 400Ohm 19mmx15,4mmx15mm | Customer Part No. Customer Project No. | 490 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Power relay | GoodSky | THT | 12.0 V DC | 15.0 A | 3000.0 VA | SPDT | AgSnO2 | 400.0 Ohm | 19.0 mm | 15.4 mm | 15.0 mm | -30.0 °C | 85.0 °C | ||||||||
695 | Manufacturers Part No. RWH-SS-124D(RWH-SS-124D) GoodSky Power relay RWH THT SPDT 15A 24VDC 1.600Ohm 19mmx15,4mmx15mm | Customer Part No. Customer Project No. | 590 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 10 or mul. of 10) | Power relay | GoodSky | THT | 24.0 V DC | 15.0 A | 3000.0 VA | SPDT | AgSnO2 | 1600.0 Ohm | 19.0 mm | 15.4 mm | 15.0 mm | -30.0 °C | 85.0 °C | ||||||||
696 | Manufacturers Part No. 40.62.9.012.0000(F4062-12) Finder Power relay 40.62 THT DPDT 10A 12VDC 220Ohm 29mmx12,4mmx25mm RTII | Customer Part No. Customer Project No. | 30 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 10 or mul. of 10) | Power relay | Finder | THT | 12.0 V DC | 10.0 A | DPDT | AgNi | 220.0 Ohm | 29.0 mm | 12.4 mm | 25.0 mm | RTII | -40.0 °C | 85.0 °C | ||||||||
697 | Manufacturers Part No. 40.62.9.012.4000(F4062-12C) Finder Power relay 40.62 THT DPDT 10A 12VDC 220Ohm 29mmx12,4mmx25mm RTII | Customer Part No. Customer Project No. | 50 Pcs. Planned Delivery Time Ø 7 Weeks Available (from stock) | (at least 10 or mul. of 10) | Power relay | Finder | THT | 12.0 V DC | 10.0 A | DPDT | AgSnO2 | 220.0 Ohm | 29.0 mm | 12.4 mm | 25.0 mm | RTII | -40.0 °C | 85.0 °C | ||||||||
698 | Manufacturers Part No. 40.62.9.024.0000(F4062-24) Finder Power relay 40.62 THT DPDT 10A 24VDC 900Ohm 29mmx12,4mmx25mm RTII | Customer Part No. Customer Project No. | 170 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 10 or mul. of 10) | Power relay | Finder | THT | 24.0 V DC | 10.0 A | DPDT | AgNi | 900.0 Ohm | 29.0 mm | 12.4 mm | 25.0 mm | RTII | -40.0 °C | 85.0 °C | ||||||||
699 | Manufacturers Part No. 40.62.9.024.4000(F4062-24C) Finder Power relay 40.62 THT DPDT 10A 24VDC 900Ohm 29mmx12,4mmx25mm RTII TOP | Customer Part No. Customer Project No. | 50 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 10 or mul. of 10) | Power relay | Finder | THT | 24.0 V DC | 10.0 A | DPDT | AgSnO2 | 900.0 Ohm | 29.0 mm | 12.4 mm | 25.0 mm | RTII | -40.0 °C | 85.0 °C | ||||||||
700 | Manufacturers Part No. 6-1393234-7(RP421-12) TE Connectivity Power relay RPII/2 THT DPDT 8A 12VDC 270Ohm 29mmx12,6mmx25,5mm RTII | Customer Part No. Customer Project No. | 400 Pcs. Planned Delivery Time Ø 22 Weeks Available (from stock) | (at least 20 or mul. of 20) | Power relay | TE Connectivity | THT | 12.0 V DC | 8.0 A | 2000.0 VA | DPDT | AgNi | 270.0 Ohm | 29.0 mm | 12.6 mm | 25.5 mm | RTII | -40.0 °C | 70.0 °C |
