GACSHPM1.23-KSKU-W3
Osram SMD/SMT LED amber 150 ° 2,1 V
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
450 Pcs. in stock
Planned delivery time
--- Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
EOL 16.10.2020
Discontinued by manufacturer without replacement
Data Sheet
ECAD Model
Prices
Manufacturer bundle 600 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 10 or multiple of 10)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Type
- LED
- Lighting Colour
- amber
- Viewing Angle
- 150 °
- (Uf) Forward Voltage
- 2.1 V
- (If) Forward Current
- 350 mA
- Peak Emission Wavelength
- 625 nm
- Dominant Wavelength Max.
- 617 nm
- RoHS-Conform
Specifications
Open all
Operating conditions
- Operating Temperature, min. (TA)
- -40 °C
- Operating Temperature, max. (TA)
- 125 °C
- Barrier Layer Temperature, max. (TJ)
- 135 °C
- Storage Temperature Min.
- -40 °C
- Storage Temperature Max.
- 125 °C
Electrical Properties
- (Uf) Forward Voltage
- 2.1 V
- (If) Forward Current
- 350 mA
- (Ur) Reverse Voltage
- 1.2 V
- Lighting Colour
- amber
- Viewing Angle
- 150 °
- Dominant Wavelength Max.
- 617 nm
- Peak Emission Wavelength
- 625 nm
- Lens Tranparency
- clear
- Lens Shape
- Dome
