Results (416)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | Assembly Type | Manufacturer Package | Lighting Colour | Luminous Intensity Max. | Viewing Angle | (Uf) Forward Voltage | (If) Forward Current | Peak Emission Wavelength | Dominant Wavelength Max. | Lens Colour | Lens Tranparency | Lens Shape | Packaging | Operating Temperature, min. (TA) | Operating Temperature, max. (TA) | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
151 |  | Manufacturers Part No. HSMD-C190(HSMD-C190) Broadcom SMD/SMT LED orange diffuse rectangular 8mcd 170° 2,2V 0603 | Customer Part No. Customer Project No. | 3.100 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Broadcom | SMD/SMT | 0603 | orange | 8.0 mcd | 170.0 ° | 2.2 V | 20.0 mA | 605.0 nm | 604.0 nm | diffuse | rectangular | Reel | -40.0 °C | 85.0 °C | |||||||
152 | | Manufacturers Part No. LTST-C190KRKT(LTST-C190KRKT) Lite-On SMD/SMT LED red clear rectangular 80mcd 130° 2V 0603 TOP | Customer Part No. Customer Project No. | 49.100 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Lite-On | SMD/SMT | 0603 | red | 80.0 mcd | 130.0 ° | 2.0 V | 20.0 mA | 639.0 nm | 631.0 nm | colorless | clear | rectangular | Reel | -30.0 °C | 85.0 °C | ||||||
153 | | Manufacturers Part No. LTST-C171KRKT(LTST-C171KRKT) Lite-On SMD/SMT LED red clear rectangular 54mcd 130° 2,0V 0805 | Customer Part No. Customer Project No. | 10.300 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Lite-On | SMD/SMT | 0805 | red | 54.0 mcd | 130.0 ° | 2.0 V | 20.0 mA | 639.0 nm | 631.0 nm | colorless | clear | rectangular | Reel | -55.0 °C | 85.0 °C | ||||||
154 | | Manufacturers Part No. LTST-C193KSKT-5A(LTST-C193KSKT-5A) Lite-On SMD/SMT LED yellow clear rectangular 45mcd 130° 2V 0603 | Customer Part No. Customer Project No. | 16.600 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Lite-On | SMD/SMT | 0603 | yellow | 45.0 mcd | 130.0 ° | 2.0 V | 5.0 mA | 591.0 nm | 587.0 nm | colorless | clear | rectangular | Reel | -30.0 °C | 85.0 °C | ||||||
155 | | Manufacturers Part No. LTST-C21KGKT(LTST-C21KGKT) Lite-On SMD/SMT LED green clear Dome 180mcd 70° 2,1V | Customer Part No. Customer Project No. | 7.500 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Lite-On | SMD/SMT | green | 180.0 mcd | 70.0 ° | 2.1 V | 20.0 mA | 574.0 nm | 567.5 nm | colorless | clear | Dome | Reel | -55.0 °C | 85.0 °C | |||||||
156 | | Manufacturers Part No. 24-21SURC/S530-A2/TR8(EL24-21SURC/S53) Everlight SMD/SMT LED red clear round 39mcd 130° 2,0V 1206 | Customer Part No. Customer Project No. | 3.500 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Everlight | SMD/SMT | 1206 | red | 39.0 mcd | 130.0 ° | 2.0 V | 20.0 mA | 632.0 nm | 624.0 nm | colorless | clear | round | Reel | -40.0 °C | 85.0 °C | ||||||
157 | | Manufacturers Part No. 23-22BUSRSYGC/S530-A5/E3/TR8(EL23-22BUSRSYGC) Everlight SMD/SMT LED red, yellow-green clear rectangular 60mcd/24mcd
130°/130°
2V/2V | Customer Part No. Customer Project No. | 5.800 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Everlight | SMD/SMT | red, yellow-green | colorless | clear | rectangular | Reel | -40.0 °C | 85.0 °C | |||||||||||||
158 | | Manufacturers Part No. 25-21SURC/S530-A2/TR8(EL25-21SURC/S53) Everlight SMD/SMT LED red clear Dome 43mcd 60° 2,0V 1206 | Customer Part No. Customer Project No. | 10.600 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Everlight | SMD/SMT | 1206 | red | 43.0 mcd | 60.0 ° | 2.0 V | 20.0 mA | 632.0 nm | 624.0 nm | colorless | clear | Dome | Reel | -40.0 °C | 85.0 °C | ||||||
159 | | Manufacturers Part No. LTST-C235KGKRKT(LTST-C235KGKRKT) Lite-On SMD/SMT LED red, green clear rectangular 45mcd/35mcd
130°/130°
2V/2V
1210 | Customer Part No. Customer Project No. | 17.200 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Lite-On | SMD/SMT | 1210 | red, green | colorless | clear | rectangular | Reel | -30.0 °C | 85.0 °C | ||||||||||||
160 | | Manufacturers Part No. 19-226SURSYGCS530A3E(EL19-226SURSYGC) Everlight SMD/SMT LED red, green clear rectangular 55mcd/30mcd
120°/120°
2V/2V
0605 | Customer Part No. Customer Project No. | 6.600 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 50 or mul. of 50) | LED | Everlight | SMD/SMT | 0605 | red, green | colorless | clear | rectangular | Reel | -40.0 °C | 85.0 °C | ||||||||||||
161 | | Manufacturers Part No. 19-22SURSYGC/S530-A3(EL19-22SURSYGC) Everlight SMD/SMT LED red, green clear rectangular 45mcd/34mcd
130°/130°
2V/2V
0806 | Customer Part No. Customer Project No. | 13.350 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 50 or mul. of 50) | LED | Everlight | SMD/SMT | 0806 | red, green | colorless | clear | rectangular | Reel | -40.0 °C | 85.0 °C | ||||||||||||
162 | | Manufacturers Part No. LTST-C195KGJRKT(LTST-C195KGJRKT) Lite-On SMD/SMT LED red, green clear rectangular 25mcd/35mcd
130°/130°
2V/2V
0606 | Customer Part No. Customer Project No. | 5.000 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Lite-On | SMD/SMT | 0606 | red, green | colorless | clear | rectangular | Reel | -55.0 °C | 85.0 °C | ||||||||||||
163 | | Manufacturers Part No. LTST-C155GYKT(LTST-C155GYKT) Lite-On SMD/SMT LED yellow, green clear rectangular 6mcd/6mcd
130°/130°
2,1V/2,1V
1210 | Customer Part No. Customer Project No. | 8.400 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Lite-On | SMD/SMT | 1210 | yellow, green | colorless | clear | rectangular | Reel | -55.0 °C | 85.0 °C | ||||||||||||
164 | | Manufacturers Part No. B1001SURWA/S530-A2(ELB1001SURWA/S53) Everlight LED Light Bar red diffuse 13,8mcd 2,0V DIP-20 | Customer Part No. Customer Project No. | 456 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 19 or mul. of 19) | LED Light Bar | Everlight | THT | DIP-20 | red | 13.8 mcd | 2.0 V | 25.0 mA | 632.0 nm | diffuse | Tube | -40.0 °C | 85.0 °C | ||||||||||
165 | | Manufacturers Part No. 19-237/R6GHBHC-A01/2T(EL19-237/R6GHBHC) Everlight SMD/SMT LED red, green, blue (RGB) clear rectangular 100mcd/180mcd/50mcd
120°/120°/120°
3,3V/3,3V/3,3V | Customer Part No. Customer Project No. | 1.820 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 10 or mul. of 10) | LED | Everlight | SMD/SMT | red, green, blue (RGB) | colorless | clear | rectangular | Reel | -40.0 °C | 85.0 °C | |||||||||||||
166 | | Manufacturers Part No. 19-337/R6GHBHC-A01/2T(EL19-337/R6GHBHC) Everlight SMD/SMT LED red, green, blue (RGB) clear rectangular 100mcd/180mcd/50mcd
120°/120°/120°
3,25V/3,25V/3,25V | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 10 or mul. of 10) | LED | Everlight | SMD/SMT | red, green, blue (RGB) | colorless | clear | rectangular | Reel | -40.0 °C | 85.0 °C | |||||||||||||
167 | | Customer Part No. Customer Project No. | 3.500 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Lite-On | THT | 5mm | orange | 700.0 mcd | 30.0 ° | 2.05 V | 20.0 mA | 611.0 nm | 605.0 nm | colorless | clear | Dome | Boxed | -40.0 °C | 85.0 °C | |||||||
168 | | Manufacturers Part No. LTL1CHKGKNN(LTL1CHKGKNN) Lite-On THT LED green clear Dome 320mcd 45° 2,05V 3mm | Customer Part No. Customer Project No. | 900 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Lite-On | THT | 3mm | green | 320.0 mcd | 45.0 ° | 2.05 V | 20.0 mA | 575.0 nm | 572.0 nm | colorless | clear | Dome | Boxed | -40.0 °C | 100.0 °C | ||||||
169 | | Manufacturers Part No. 334-15/T2C2-6VXB/EU(EL334-15/T2C2-6VXB) Everlight THT LED white clear round 22.500mcd 20° 3,2V 5mm | Customer Part No. Customer Project No. | 760 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 10 or mul. of 10) | LED | Everlight | THT | 5mm | white | 22500.0 mcd | 20.0 ° | 3.2 V | 20.0 mA | colorless | clear | round | Boxed | -40.0 °C | 85.0 °C | ||||||||
170 | | Manufacturers Part No. 1383UYD/S530-A3(EL1383UYD/S53) Everlight THT LED orange diffuse round 800mcd 25° 2,0V 5mm | Customer Part No. Customer Project No. | 2.100 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Everlight | THT | 5mm | orange | 800.0 mcd | 25.0 ° | 2.0 V | 20.0 mA | 591.0 nm | 589.0 nm | orange | diffuse | round | Boxed | -40.0 °C | 85.0 °C | ||||||
171 | | Manufacturers Part No. LTL-307Y-012(LTL307Y-012) Lite-On THT LED yellow diffuse round 29mcd 50° 2,1V 5mm | Customer Part No. Customer Project No. | 11.900 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Lite-On | THT | 5mm | yellow | 29.0 mcd | 50.0 ° | 2.1 V | 20.0 mA | 585.0 nm | 588.0 nm | yellow | diffuse | round | Boxed | -55.0 °C | 100.0 °C | ||||||
172 | | Manufacturers Part No. LTL-4251NLC(LED3GE2MA) Lite-On THT LED yellow diffuse Dome 1,1mcd 60° 1,8V 3mm | Customer Part No. Customer Project No. | 45.800 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Lite-On | THT | 3mm | yellow | 1.1 mcd | 60.0 ° | 1.8 V | 2.0 mA | 585.0 nm | 588.0 nm | yellow | diffuse | Dome | Boxed | -55.0 °C | 100.0 °C | ||||||
173 | | Customer Part No. Customer Project No. | 1.700 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Lite-On | THT | 3mm | green | 40.0 mcd | 45.0 ° | 2.1 V | 20.0 mA | 565.0 nm | 573.0 nm | green | clear | round | Boxed | -55.0 °C | 100.0 °C | |||||||
174 | | Customer Part No. Customer Project No. | 11.100 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Lite-On | THT | 5mm | green | 60.0 mcd | 40.0 ° | 2.1 V | 20.0 mA | 565.0 nm | 569.0 nm | green | clear | round | Boxed | -55.0 °C | 100.0 °C | |||||||
175 | | Manufacturers Part No. 204-10UYD/S530-A3(EL204-10UYD/S53) Everlight THT LED yellow diffuse round 200mcd 60° 2,0V 3mm | Customer Part No. Customer Project No. | 14.300 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 100 or mul. of 100) | LED | Everlight | THT | 3mm | yellow | 200.0 mcd | 60.0 ° | 2.0 V | 20.0 mA | 591.0 nm | 589.0 nm | yellow | diffuse | round | Boxed | -40.0 °C | 85.0 °C |
