Results (443)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | Display-Technology | Screen Diagonal | Resolution (Pixel) | Touch Panel | Display Interface | Supply Voltage Min. | Supply Voltage Max. | Backlight Type | Backlight Colour | (Uf) Forward Voltage | (If) Forward Current | Backlight Brightness | Operating Temperature Min. | Operating Temperature Max. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
426 |  EOL 25.11.2023 | Manufacturers Part No. VGG128004-5TSLWA(VGG128004-5TSLWA) Evervision LCD Graphic Module TFT 1280x800 LED white 550 cd/m2 | Customer Part No. Customer Project No. | 1 Pcs. Cancelled by manufacturer without replacement | (at least 1 or mul. of 1) | LCD Graphic Module | Evervision | TFT | 10.1 '' | 1280x800 | No Touch | LVDS | 2.3 V | 2.7 V | LED | white | 9.3 V | 260.0 mA | 550.0 cd/m2 | 0.0 °C | 50.0 °C | |||||
427 | EOL 25.11.2023 | Manufacturers Part No. VGG128004-5TSLWG(VGG128004-5TSLWG) Evervision LCD Graphic Module TFT 1280x800 LED white 550 cd/m2 | Customer Part No. Customer Project No. | 1 Pcs. Cancelled by manufacturer without replacement | (at least 1 or mul. of 1) | LCD Graphic Module | Evervision | TFT | 10.1 '' | 1280x800 | No Touch | LVDS | 3.0 V | 3.6 V | LED | white | 550.0 cd/m2 | 0.0 °C | 50.0 °C | |||||||
428 | EOL 01.08.2023 | Manufacturers Part No. DEM640480ETMX-PW-N(DEM640480ETMX-PWN) Display Elektronik LCD Graphic Module TFT 640x480 LED white 900cd/m2 % | Customer Part No. Customer Project No. | 16 Pcs. Article discontinued | (at least 1 or mul. of 1) | LCD Graphic Module | Display Elektronik | TFT | 5.7 '' | 640x480 | No Touch | 18-Bit-RGB | 3.0 V | 3.6 V | LED | white | 9.6 V | 200.0 mA | 900.0 cd/m2 | -30.0 °C | 85.0 °C | |||||
429 | EOL 01.08.2023 | Manufacturers Part No. DEM640480ATMH-PW-N(DEM640480ATMH-PWN) Display Elektronik LCD Graphic Module TFT 640x480 LED white 200cd/m2 % | Customer Part No. Customer Project No. | 3 Pcs. Article discontinued | (at least 1 or mul. of 1) | LCD Graphic Module | Display Elektronik | TFT | 5.7 '' | 640x480 | No Touch | 8-Bit-MCU | 3.1 V | 3.5 V | LED | white | 5.0 V | 380.0 mA | 200.0 cd/m2 | -20.0 °C | 70.0 °C | |||||
430 | EOL 01.08.2023 | Manufacturers Part No. DEM480272F1TMH-PW-N(DEM480272F1TMH-PWN) Display Elektronik LCD Graphic Module TFT 480x272 LED white 500 cd/m2 % | Customer Part No. Customer Project No. | 12 Pcs. Cancelled by manufacturer without replacement | (at least 1 or mul. of 1) | LCD Graphic Module | Display Elektronik | TFT | 4.3 '' | 480x272 | No Touch | 24-Bit-RGB | 3.0 V | 3.6 V | LED | white | 22.4 V | 20.0 mA | 500.0 cd/m2 | -20.0 °C | 70.0 °C | |||||
431 | EOL 19.01.2026 | Manufacturers Part No. DEM480272A2TMH-PW-N(DEM480272A2TMH-PWN) Display Elektronik LCD Graphic Module TFT 480x272 LED white 500 cd/m2 | Customer Part No. Customer Project No. | 3 Pcs. Cancelled by manufacturer without replacement | (at least 1 or mul. of 1) | LCD Graphic Module | Display Elektronik | TFT | 4.3 '' | 480x272 | No Touch | 8-Bit-MCU | 3.0 V | 3.6 V | LED | white | 22.4 V | 20.0 mA | 500.0 cd/m2 | -20.0 °C | 70.0 °C | |||||
432 | EOL 17.10.2025 | Manufacturers Part No. DEM480272A2TMH-PW-N(A-TOUCH)(DEM480272A2TMHPWNT) Display Elektronik LCD Graphic Module TFT 480x272 LED white 400 cd/m2 % | Customer Part No. Customer Project No. | 60 Pcs. Cancelled by manufacturer without replacement | (at least 1 or mul. of 1) | LCD Graphic Module | Display Elektronik | TFT | 4.3 '' | 480x272 | 8-Bit-MCU | 3.0 V | 3.6 V | LED | white | 22.4 V | 20.0 mA | 400.0 cd/m2 | -20.0 °C | 70.0 °C | ||||||
433 | EOL 18.09.2024 | Manufacturers Part No. DEM480272E1TMH-PW-N(A-TOUCH)(DEM480272E1TMHPWNT) Display Elektronik LCD Graphic Module TFT 480x272 LED white 240 cd/m2 % | Customer Part No. Customer Project No. | 3 Pcs. Cancelled by manufacturer without replacement | (at least 1 or mul. of 1) | LCD Graphic Module | Display Elektronik | TFT | 4.3 '' | 480x272 | 24-Bit-RGB | 3.0 V | 3.6 V | LED | white | 22.4 V | 20.0 mA | 240.0 cd/m2 | -20.0 °C | 70.0 °C | ||||||
434 | EOL 01.08.2023 | Manufacturers Part No. DEM480272F1TMH-PW-N(A-TOUCH)(DEM480272F1TMHPWNT) Display Elektronik LCD Graphic Module TFT 480x272 LED white 400 cd/m2 % | Customer Part No. Customer Project No. | 10 Pcs. Cancelled by manufacturer without replacement | (at least 1 or mul. of 1) | LCD Graphic Module | Display Elektronik | TFT | 4.3 '' | 480x272 | 24-Bit-RGB | 3.0 V | 3.6 V | LED | white | 22.4 V | 20.0 mA | 400.0 cd/m2 | -20.0 °C | 70.0 °C | ||||||
435 | EOL 01.08.2023 | Manufacturers Part No. DEM480272ITMH-PW-N(A-TOUCH)(DEM480272ITMH-PWNT) Display Elektronik LCD Graphic Module TFT 480x272 LED white 220 cd/m2 % | Customer Part No. Customer Project No. | 31 Pcs. Cancelled by manufacturer with replacement | (at least 1 or mul. of 1) | LCD Graphic Module | Display Elektronik | TFT | 4.3 '' | 480x272 | 18-Bit-RGB 24-Bit-RGB | 3.0 V | 3.6 V | LED | white | 22.4 V | 20.0 mA | 220.0 cd/m2 | -20.0 °C | 70.0 °C | ||||||
436 | EOL 04.08.2026 | Manufacturers Part No. DEM128160A1TMH-PW-N(DEM128160A1TMH-PWN) Display Elektronik LCD Graphic Module TFT 128x160 LED white 350 cd/m2 | Customer Part No. Customer Project No. | 1.672 Pcs. Cancelled by manufacturer with replacement | (at least 1 or mul. of 1) | LCD Graphic Module | Display Elektronik | TFT | 1.8 '' | 128x160 | No Touch | 16-Bit-MCU | 2.5 V | 3.7 V | LED | white | 3.1 V | 30.0 mA | 350.0 cd/m2 | -20.0 °C | 70.0 °C | |||||
437 | EOL 01.08.2023 | Manufacturers Part No. EAEDIP320J-8LATP(EAEDIP320J-8LATP) DISPLAY VISIONS LCD Graphic Module FSTN 320x240 LED Amber | Customer Part No. Customer Project No. | 1 Pcs. Cancelled by manufacturer without replacement | (at least 1 or mul. of 1) | LCD Graphic Module | DISPLAY VISIONS | FSTN | 320x240 | I2C RS232 SPI | 5.0 V | LED | Amber | -20.0 °C | 70.0 °C | |||||||||||
438 | EOL 01.10.2025 | Manufacturers Part No. DEM640480CTMH-PW-N(DEM640480CTMH-PWN) Display Elektronik LCD Graphic Module TN 640x480 LED white 380cd/m2 % | Customer Part No. Customer Project No. | 5 Pcs. Cancelled by manufacturer without replacement | (at least 1 or mul. of 1) | LCD Graphic Module | Display Elektronik | TN | 5.7 '' | 640x480 | No Touch | 18-Bit-RGB | 3.6 V | 3.6 V | LED | white | 380.0 cd/m2 | -20.0 °C | 70.0 °C | |||||||
439 | EOL 19.06.2026 | Manufacturers Part No. DEM096096AVMH-PW-N(DEM096096AVMH-PWN) Display Elektronik LCD Graphic Module TFT 96x96 LED white 440 cd/m2 New | Customer Part No. Customer Project No. | 10 Pcs. Cancelled by manufacturer without replacement | (at least 1 or mul. of 1) | LCD Graphic Module | Display Elektronik | TFT | 1.1 '' | 96x96 | No Touch | SPI | 2.5 V | 3.7 V | LED | white | 9.3 V | 15.0 mA | 440.0 cd/m2 | -20.0 °C | 70.0 °C | |||||
440 | EOL 23.05.2025 | Manufacturers Part No. EATFT050-84BTS(EATFT050-84BTS) DISPLAY VISIONS LCD Graphic Module TFT 800x480 LED white 750 cd/m2 | Customer Part No. Customer Project No. | 1 Pcs. Cancelled by manufacturer without replacement | (at least 1 or mul. of 1) | LCD Graphic Module | DISPLAY VISIONS | TFT | 5.0 '' | 800x480 | Projective Touch | I2C | 3.0 V | 3.6 V | LED | white | 30.0 V | 40.0 mA | 750.0 cd/m2 | -20.0 °C | 70.0 °C | |||||
441 | EOL 19.09.2025 | Manufacturers Part No. DEM240128D1SBH-PW-N(DEM240128D1SBH-PWN) Display Elektronik LCD Graphic Module STN 240x128 LED white % | Customer Part No. Customer Project No. | 18 Pcs. Article discontinued | (at least 1 or mul. of 1) | LCD Graphic Module | Display Elektronik | STN | 4.8 '' | 240x128 | No Touch | 8-Bit-MCU | 4.7 V | 5.3 V | LED | white | -20.0 °C | 70.0 °C | ||||||||
442 | EOL 25.11.2023 | Manufacturers Part No. VGG804849-6UFLWA(VGG804849-6UFLWA) Evervision LCD Graphic Module TFT 800x480 LED white 500 cd/m2 | Customer Part No. Customer Project No. | 9 Pcs. Cancelled by manufacturer without replacement | (at least 1 or mul. of 1) | LCD Graphic Module | Evervision | TFT | 7.0 '' | 800x480 | 3.0 V | 3.6 V | LED | white | 3.6 V | 105.0 mA | 500.0 cd/m2 | -20.0 °C | 70.0 °C | |||||||
443 | EOL 25.11.2023 | Manufacturers Part No. VGG644824-6UFLWE(VGG644824-6UFLWE) Evervision LCD Graphic Module TFT 640x480 LED 350 cd/m2 | Customer Part No. Customer Project No. | 60 Pcs. Cancelled by manufacturer without replacement | (at least 1 or mul. of 1) | LCD Graphic Module | Evervision | TFT | 5.7 '' | 640x480 | 18-Bit-RGB Parallel | 3.0 V | 3.6 V | LED | 9.9 V | 140.0 mA | 350.0 cd/m2 | -20.0 °C | 70.0 °C |
