MWMD15EU/6XC
Minwa Wall Mount Power Supply 24W 24V 0,5A Plug Adapter
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
465 Pcs. in stock
Planned delivery time
Ø 22 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 100 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Package/Case
- Wall Mount Power Supply
- Output Power
- 24 W
- Output voltage
- 24 V
- Output current
- 0.500 A
- Connection type, output
- Plug Adapter
- RoHS-Conform
Specifications
Open all
Operating conditions
- MTBF
- 30,000 h
- Operating Temperature Min.
- 0 °C
- Operating Temperature Max.
- 25 °C
- Storage Temperature Min.
- -20 °C
- Storage Temperature Max.
- 60 °C
Input
- Mains frequency min.
- 50 Hz
- Mains frequency max.
- 60 Hz
- Input voltage min. AC
- 100 V
- Input voltage max. AC
- 240 V
- Efficiency (at 10% load)
- 76.2 %
- Average efficiency
- 86.2 %
- No load power, less than
- 0.1 W
- Power factor correction (PFC)
- Connection type, input
- Euro Plug
Output
- Number of outputs
- 1
- Output Power
- 24 W
- Output voltage
- 24 V
- Selectable output voltage
- Selectable DC output voltages (V)
- 3; 4,5; 5; 6; 7; 5; 9; 12
- Output current
- 0.500 A
- Overload protection
- Short-circuit protection
- Overvoltage protection
- Overtemperature protection
- Connection type, output
- Plug Adapter
- Cable length, output
- 180 cm
Safety/Certifications
- Protection class
- II
- Isolation voltage I/P-O/P
- 3,000 V
- Energy level
- (EU) 2019/1782 + Level VI
- Approvals
- CE
- EN
- Standards (EMC)
- EN 61204-3
- Standards (safety)
- EN 61558-2-16
