PIC18F248-I/SP
Microchip 8-Bit Microcontroller 16KB 22I/O 40MHz 0,768KB PIC18 SPDIP-28
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
51 Pcs. in stock
Planned delivery time
Ø 2 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 15 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Type
- 8-Bit Microcontroller
- Supply Voltage Min.
- 4.2 V
- Supply Voltage Max.
- 5.5 V
- CPU clock frequency Max.
- 40 MHz
- CPU Core
- PIC18
- Program Memory Size
- 16 KB
- Memory Size
- 0.768 KB
- EEPROM
- 256 Byte
- Number of I/O Pins
- 22 I/O
- Manufacturer Package
- SPDIP-28
- RoHS-Conform
Specifications
Open all
Operating conditions
- Operating Temperature Min.
- -40 °C
- Operating Temperature Max.
- 85 °C
Electrical properties
- CPU Core
- PIC18
- CPU clock frequency Max.
- 40 MHz
- Databus Width
- 8 bit Bit
- Supply Voltage Min.
- 4.2 V
- Supply Voltage Max.
- 5.5 V
- Real-Time Clock
- Number of ADC Channels
- 5
- ADC Resolution
- 10 bit Bit
- Program Memory Size
- 16 KB
- Memory Size
- 0.768 KB
- Number of I/O Pins
- 22 I/O
- EEPROM
- 256 Byte
