372-1-014-T-KT0
Binder MPE IDC pin header 372-1 Pin Box Header 2-row horizontal 14 Pole Pitch1,27mm red 230VDC
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
891 Pcs. in stock
Next Stock Receipt
Week 32/2026
5.022 Pcs.
5.022 Pcs.
Planned delivery time
Ø 17 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 27 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 27 or multiple of 27)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Contact Type
- Pin
- Type
- IDC pin header
- Connector Contact
- IDC
- Series
- 372-1
- Colour
- red
- Housing material
- Thermoplast (TP)
- Housing
- 2-row
- Design
- Box Header
- Number of poles
- 14
- Pitch
- 1.27 mm
- Class of Inflammability
- UL 94 V-0
- Locking
- no
- Alignment
- horizontal
- Operating Temperature Max.
- 105 °C
- Rated current
- 1 A
- Rated voltage DC
- 230 V DC
- Operating Temperature Min.
- -40 °C
- RoHS-Conform
Specifications
Open all
Dimensions and Weights
- Dimension: Length
- 21.15 mm
- Dimension: Width
- 5 mm
- Dimension: Height
- 5.1 mm
- Pitch
- 1.27 mm
- Conductor cross-section (AWG), min.
- 28 AWG
Operating conditions
- Operating Temperature Min.
- -40 °C
- Operating Temperature Max.
- 105 °C
Technical Features
- Rated current
- 1 A
- Rated voltage DC
- 230 V DC
- Breakdown voltage
- 500 V RMS / min.
- Solderability
- 230 °C / 5 s °C / s
Mechanical Features
- Housing material
- Thermoplast (TP)
- Contact Surface Input
- verzinnt
Safety/Certifications
- Class of Inflammability
- UL 94 V-0
