XDR-960E-48

MEAN WELL AC/DC industrial power supply unit DIN Rail 960W 48V 20A

XDR-960E-48
Manufacturer Part No.
XDR-960E-48
Schukat Part No.
XDR-960E-48
Manufacturer
MEAN WELL
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

28 Pcs. in stock

Planned delivery time
Ø 14 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available (from stock)
Replacement / Follow-up View entire series
Data Sheet
Open PDF
ECAD Model
Downloads

Prices

Manufacturer bundle 6 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Package/Case
DIN Rail
Output Power
960 W
Output voltage
48 V
Output current
20.000 A
Efficiency
95.5 %
RoHS-Conform

Specifications

Close all

General

Manufacturer
  • MEAN WELL
Series
  • XDR-960E
Product group
  • L3236
Application
  • ITE
  • Industry
  • MSR/Laboratory
Package/Case
  • DIN Rail
Dimension: Width
  • 96 mm
Dimension: Height
  • 125.2 mm
Dimension: Depth
  • 132 mm
Weight
  • 1,930 g
Label
  • TÜV
Manufacturer's warranty (years)
  • 3
Product description
  • The XDR-960E series is an economical and ultra-slim industrial 960W AC/DC DIN rail power supply. The main features of this series include a slim 96mm housing that saves installation space in the end system. The maximum efficiency of 95.5% and low standby power consumption of <3.6W ensure energy savings and carbon reduction. It features built-in constant current output, fanless design, wide operating temperature range from -40 to +70°C (up to +50°C at full load); OVCIII compliance; parallel function capability up to 3840W; built-in DC OK signal. With comprehensive protection features, full safety certifications and a 3-year warranty, the XDR-960E series is a compact, powerful and highly reliable DIN rail power supply.
Features
  • Adjustable Output Voltage
  • DC compatible
  • DC-OK-Signal
  • Parallel Function

Operating conditions

Operating Temperature Min.
  • -40 °C
Operating Temperature Max.
  • 70 °C
Storage Temperature Min.
  • -40 °C
Storage Temperature Max.
  • 85 °C

Input

Mains connection/phases
  • I
Mains frequency min.
  • 47 Hz
Mains frequency max.
  • 63 Hz
Input voltage min. AC
  • 180 V
Input voltage max. AC
  • 264 V
Input voltage min. DC
  • 254.5 V
Input voltage max. DC
  • 370 V
Input current
  • 4.5 A
Efficiency
  • 95.5 %
No load power, less than
  • 3.6 W
Leakage current, max.
  • 3.5 mA
Inrush current, max.
  • 30 A
Power factor correction (PFC)
Power factor
  • 0.95
Connection type, input
  • Screw Terminal

Output

Number of outputs
  • 1
Output Power
  • 960 W
Output voltage
  • 48 V
Output voltage tolerance
  • -1.1 %
Ripple & Noise
  • 150 mVp-p
Output current
  • 20.000 A
Overload protection
Type of overload protection
  • Constant Current Limitting
Short-circuit protection
Overvoltage protection
Overtemperature protection
Connection type, output
  • Screw Terminal

Safety/Certifications

Protection class
  • I
Isolation voltage I/P-O/P
  • 4,000 V
Isolation voltage I/P-FG
  • 2,000 V
Isolation voltage O/P-FG
  • 1,500 V
Overvoltage category
  • 3
Approvals
  • AS/NZ
  • BSMI
  • CCC
  • CE
  • EAC
  • EN
  • IEC
  • RCM
  • UKCA
  • UL
Standards (EMC)
  • EN 55032
  • EN 55032 Class B
  • EN 61204-3
Standards (safety)
  • EN 61010-1
  • EN 61558-1
  • EN 61558-2-16
  • EN 62368-1
  • IEC 61010-1
  • IEC 61558-1
  • IEC 62368-1
  • UL 61010-1

Documents

MEAN_WELL_Katalog_Industrie_2026.pdf
Download (pdf, 48.955 KB)
MEAN_WELL_Katalog_LED.pdf
Download (pdf, 53.159 KB)
XDR-E_EN.pdf
Download (pdf, 1.055 KB)
