SPWM-150-12MA

MEAN WELL AC/DC LED power supply unit CV 150W 12V 12,5A Matter

SPWM-150-12MA
NEW
Manufacturer Part No.
SPWM-150-12MA
Schukat Part No.
SPWM-150-12MA
Manufacturer
MEAN WELL
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

0 Pcs. in stock

Planned delivery time
Ø 99 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available (from stock)
Replacement / Follow-up View entire series
Data Sheet
Open PDF
ECAD Model
Downloads

Prices

Manufacturer bundle 30 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Notice
Cross-references:
Here you will find suitable surge protection devices.
Here you will find suitable inrush current limiters.
Here you will find suitable EMC & noise suppression components.
Here you will find suitable PWM dimmers and controllers.
Here you will find suitable cables/wires.
Operating mode
CV
Output Power
150 W
Output voltage
12 V
Output current
12.500 A
Interfaces
Matter
RoHS-Conform

Specifications

Close all

General

Manufacturer
  • MEAN WELL
Series
  • SPWM-150-MA
Product group
  • L4737
Application
  • Lighting
Operating mode
  • CV
Package/Case
  • Enclosed Plastic
Dimension: Length
  • 340 mm
Dimension: Width
  • 38 mm
Dimension: Height
  • 28.5 mm
Weight
  • 380 g
Label
  • MM-Zeichen; SELV
Dimmable
Interfaces
  • Matter
Manufacturer's warranty (years)
  • 5
Product description
  • The SPWM-150-MA series consists of 150-W AC/DC LED drivers with constant-voltage operation and PWM output. These drivers maintain color temperature and brightness uniformity when driving all types of LED strips. The SPWM-150-MA operates in the range of 100 to 305 VAC and is available in models with various nominal voltages ranging from 12 V to 24 V. Thanks to its high efficiency of up to 93% and fanless design, the entire series can be operated at a housing temperature of -20 to +80 °C with free air circulation. The SPWM-150-MA is equipped with various functional options, such as dimming via a dimmer, to provide optimal design flexibility for LED lighting systems.
Features
  • Adjustable output voltage
  • DC compatible
  • Emergency Lighting Unit
  • Flicker Free
  • Independent Control Gear
Notice

Operating conditions

MTBF
  • 158,100 h
Operating Temperature Min.
  • -20 °C
Operating Temperature Max.
  • 80 °C
Storage Temperature Min.
  • -40 °C
Storage Temperature Max.
  • 80 °C

Input

Mains frequency min.
  • 47 Hz
Mains frequency max.
  • 63 Hz
Input voltage min. AC
  • 100 V
Input voltage max. AC
  • 305 V
Input voltage min. DC
  • 156 V
Input voltage max. DC
  • 410 V
Input current
  • 1 A
Efficiency
  • 92 %
No load power, less than
  • 0.5 W
Power consumption in networked standby mode (Pnet), less than
  • 0.5 W
Leakage current, max.
  • 0.25 mA
Inrush current, max.
  • 55 A
Max. number on B16 circuit breaker
  • 5
Max. number on C16 circuit breaker
  • 8
Power factor correction (PFC)
Power factor
  • 0.95
Connection type, input
  • Screw Terminal

Output

Number of outputs
  • 4
Output Power
  • 150 W
Output voltage
  • 12 V
Output voltage, channel 2
  • 12 V
Output voltage, channel 3
  • 12 V
Output voltage, channel 4
  • 12 V
Output current
  • 12.500 A
Output current, channel 2
  • 12.500 A
Output current, channel 3
  • 12.500 A
Output current, channel 4
  • 12.500 A
Overload protection
Short-circuit protection
Overvoltage protection
Overtemperature protection
Connection type, output
  • Screw Terminal

Safety/Certifications

Protection class
  • II
Isolation voltage I/P-O/P
  • 3,750 V
Approvals
  • CCC
  • CE
  • EAC
  • EN
  • ENEC
  • UKCA
Standards (EMC)
  • EN 55015
Standards (safety)
  • EN 61347-1
  • EN 61347-2-13

Documents

Enclosed_Type_GE.pdf
Download (pdf, 973 KB)
MEAN_WELL_Katalog_Industrie_2026.pdf
Download (pdf, 48.955 KB)
MEAN_WELL_Katalog_LED.pdf
Download (pdf, 53.159 KB)
SPWM-75,150,240-E.pdf
Download (pdf, 6.930 KB)
